Wednesday, April 04, 2018

Aircraft Structural Failure: Piper PA-28R-201 Arrow III, N106ER; fatal accident occurred April 04, 2018 near Daytona Beach International Airport (KDAB), Volusia County, Florida









The National Transportation Safety Board traveled to the scene of this accident.

Additional Participating Entities:
Federal Aviation Administration / Flight Standards District Office; Orlando, Florida
Federal Aviation Administration Accident Investigation and Prevention; Fort Worth, Texas
Piper Aircraft; Vero Beach, Florida
Embry-Riddle Aeronautical University; Daytona, Florida

Aviation Accident Final Report - National Transportation Safety Board:
https://app.ntsb.gov/pdf

Investigation Docket - National Transportation Safety Board:  https://dms.ntsb.gov/pubdms

http://registry.faa.gov/N106ER

Location: Daytona Beach, FL
Accident Number: ERA18FA120
Date & Time: 04/04/2018, 0953 EDT
Registration: N106ER
Aircraft: PIPER PA28R
Aircraft Damage: Destroyed
Defining Event: Aircraft structural failure
Injuries: 2 Fatal
Flight Conducted Under: Part 91: General Aviation - Instructional

Analysis

An airline transport pilot and a private pilot were performing commercial pilot checkride maneuvers, which included a touch-and-go landing. After the landing and during the climb, the airplane's left wing separated near the wing root and the airplane collided with terrain. The airplane's radar-derived ascent and heading profile following the touch-and-go maneuver was consistent with the airplane maneuvering in a manner that wouldn't reasonably be expected to produce airframe loading that would result in an in-flight structural failure. The airplane was operating under the maximum allowable gross weight and within its center-of-gravity limits at the time of the accident. According to automatic-dependent surveillance broadcast data, the airplane's radar target was last recorded at an altitude of 900 ft mean sea level (msl) and a groundspeed of 80 knots. Witnesses within 1/4 mile of the accident site reported that the airplane climbed "normally" on a westerly heading when they saw the wing separate from the fuselage.

Metallurgical examination of the accident airplane's left-wing main spar lower cap found that it exhibited fracture features consistent with fatigue through more than 90% of the cross-section, reducing its residual strength capabilities almost completely. The examination identified three fatigue cracks in the left-wing main spar lower cap (see figure 1). One fatigue crack initiated near the lower forward corner of the outboard forward wing attachment bolt hole (designated as bolt hole LC-1) and propagated forward to the forward edge of the cap. A second fatigue crack initiated near the lower aft corner of bolt hole LC-1 and propagated aft toward the lower aft wing attachment bolt hole (designated as bolt hole LD-1) and up the cap web almost to the edges. A third fatigue crack initiated near the lower aft corner of bolt hole LD-1 and propagated aft almost to the aft edge of the cap. Fatigue cracks also originated in the forward and aft doublers from both sides of the bolt holes (see figure 2).


Figure 1. Close view of the fracture surfaces in the left-wing main spar lower cap. Unlabeled arrows indicate fatigue origin areas and dashed lines indicate approximate fatigue boundaries

Figure 2. Close views of the fracture surfaces in the aft (left) and forward (right) doublers. Unlabeled arrows indicate fatigue origin areas and dashed lines indicate approximate fatigue boundaries

A small fatigue crack was also identified in the accident airplane's right-wing main spar lower cap; however, that crack had not progressed to the point of failure. Examination of the left-wing main spar of another Piper PA-28R-201 owned and operated by the same operator as the accident airplane; manufactured in the same year with a serial number two previous to the accident airplane; and with similar hours, cycles, and operational exposure found a similar fatigue crack that initiated near the lower forward corner of hole LC-1.

The accident airplane was manufactured about 10 years before the accident and had been used solely for flight instructor and commercial pilot training by the flight school operator. The airplane had accumulated 7,690.6 hours and 33,276 landing cycles before the accident flight, which equates to 4.33 landing cycles per hour of flight time. According to operator personnel, the commercial flight lesson times averaged 1.4 to 1.8 hours; most of that time the airplane was being operated in the airport traffic pattern, performing takeoffs, landings, and power-off 180ยบ maneuvers. While in the airport traffic pattern, the airplane operated between 1,000 ft agl and ground level. On longer flights, necessitating the need to operate in the practice area, maneuvering typically took place between 2,500 and 3,000 ft msl before returning to the airport.

A review of the operator's airframe discrepancy log for the life of the airplane and flight crew safety reporting system for the 24 months preceding the accident found some reported flap extension overspeed, gear extension overspeed, and hard landing events. In each case, the events resulted in airframe examinations during which no defects were noted by maintenance personnel. Interviews with flight instructors did not yield any safety of flight issues or critical airframe or loading exceedances caused by pilot operation that would be expected to precipitate cracking.

The operator's maintenance program alternated between 50-hour and annual inspections that included airframe manufacturer-recommended inspection items. The annual inspection detailed in the airframe manufacturer's maintenance manual includes a specific line item to inspect the wing attachment bolts and brackets that was included in the operator's inspection. There were no specific instructions from the airplane manufacturer or additional steps from the operator for a detailed inspection of the wing main spar lower caps in the area where the fracture occurred. A review of the maintenance logbook for the entire life of the airplane found no indications of airplane damage, major repairs, or significant nonstandard maintenance concerning the wing structure.

About 31 years before this flight training accident, in response to a pipeline patrol accident in which the left wing separated from a PA-28-181 airplane, the airframe manufacturer issued Service Bulletin (SB) 886 recommending a visual and dye penetrant inspection of the wing main spar on certain PA-28, PA-28R, and PA-32 model airplanes. The initial and recurrent inspection intervals recommended by the SB were calculated based on an accounting of the affected airplanes' lifetime usage, which the SB categorized into four usage classes: normal, severe, extreme, and unknown. Based on the SB criteria for the normal usage class, which included normal flight training operations, the accident airplane was not due for an initial inspection for another 23,000 flight hours (the SB recommended an initial inspection of the wing main spar at 30,600 hours).

Considering the absence of anomalies in materials or construction of the examined wing spars from N106ER and N104ER, the disparity between the failure time of the accident wing spar and the inspection threshold time in the SB likely derives from the differences between normal usage (as analyzed after the pipeline patrol accident that prompted the SB) and the actual flight training usage experienced by the accident airplane. The Piper PA-28R-201 and other similar airplanes were type certificated under Part 3 of the Civil Air Regulations, which only required that design details avoid stress concentrations; thus, this airplane model and others similar to it was not subject to the more robust fatigue analysis requirements under Title 14 Code of Federal Regulations (CFR) Part 23. In 2005, the FAA published Advisory Circular (AC) 23-13A with information and guidance for performing fatigue, fail-safe, and damage tolerance evaluations of metallic airplane structures developed under Part 23 regulations.

AC 23-13A provides flight and ground load information for various types of flight operations. AC 23-13A includes detailed information on the flight gust and maneuver loads, load factors for taxi movements, and landing sink rate data that can be used to determine flight and ground loads for the various types of operations for single-engine airplanes. These flight and ground loads drive the aging and fatigue of metallic airplane structures. The NTSB's investigation referenced this information to evaluate the flight and ground loads that the accident airplane was likely exposed to over its operational life in the flight training environment. This evaluation found that the maneuver loads experienced by the accident airplane were likely similar to the maneuver loads for basic instruction published in AC 23-13A, which are slightly higher than for personal use. The gust loads in the accident airplane flight training environment could also be higher than in the personal use environment (in the personal use environment airplanes are typically operated at higher altitudes, and gust loads are generally more severe and frequent at lower altitudes for any given airspeed). However, the gust loads for basic instruction are presented as identical to personal use in AC 23-13A. Loads associated with taxi movements for the accident airplane were likely similar to those of other operations other than agricultural application as shown in AC 23-13A. Landing impact loads for the accident airplane were likely higher and more frequent than other types of operations. Sink rates for basic instruction use as published in AC 23-13A are higher than that of other uses including the pipeline survey use and normal use analyzed for SB 886, and higher sink rates correspond to higher landing impact loads.

The NTSB concludes that, due to flight training maneuvers, significant operation at low altitudes, and frequent landing cycles, the accident airplane (and its sister airplane in the operator's fleet) likely experienced landing, gust, and maneuver loads that were more severe than expected for training aircraft when SB 886 was developed. Therefore, the low-altitude flight training and frequent landing environment likely resulted in the accident airplane accumulating damaging stress cycles at a faster rate than a personal use airplane.

After the accident, 16 airplanes from 4 flight schools (including ERAU) were examined using eddy-current inspection of the outboard attachment holes. Times in service ranged from 2,777.5 to 10,301.5 hours, and estimated landing cycles ranged from 8,841 to 39,000 cycles. Among the inspected airplanes, a crack was found in one wing of ERAU airplane N104ER, which had a time in service of 7,660.7 hours and 33,288 landing cycles. No additional cracks were detected in the remaining airplanes, including four airplanes with higher estimated landing cycles. However, due to the limited sample size and the expected variability in fatigue crack initiation times, the absence of detected cracks in airplanes with more cycles and/or hours than N106ER and 104ER does not eliminate the risk of fatigue cracking due to loads associated with a more severe training environment.

The location of the fatigue cracking observed on the accident airplane's left-wing main spar lower cap would have prevented visible detection from the interior or exterior of the airplane. Evidence of the presence of a crack would only have been visible after cracking had begun in the doubler and grown past the bolt head to a significant length. The only reliable method to detect the fatigue cracking in the wing main spar, as installed, would have been a nondestructive inspection procedure, such as a high frequency eddy current bolt hole inspection. The FAA issued a notice of proposed rulemaking 8 months after the accident proposing to require such an inspection for all Piper PA-28 series airplanes, except the PA-28-201T and PA-28-236 model airplanes; all Piper PA-28R model airplanes; and all Piper PA-32-260 and PA-32-300 model airplanes. In the NTSB's February 15, 2019, comments to the FAA, we expressed our support of the proposed AD's inspection requirements but urged the FAA to reexamine the proposed AD's applicability to certain airplanes based on airplane usage. As of the date of this report, the FAA has not published an AD for inspection of the accident airplane type and other similar types, especially those operated in the flight training environment.

Probable Cause and Findings

The National Transportation Safety Board determines the probable cause(s) of this accident to be:
Extensive fatigue cracking in the left-wing main spar lower cap and doublers, which resulted in the in-flight separation of the left wing. The fatigue cracks initiated and grew to a critical size due to flight and ground loads associated with flight-training involving flight-training maneuvers, significant operation at low altitudes and frequent landing cycles. Previously established inspection criteria were insufficient to detect the fatigue crack before it grew to a critical size.

Findings

Aircraft
Spar (on wing) - Fatigue/wear/corrosion (Cause)
Spar (on wing) - Failure (Cause)
Spar (on wing) - Capability exceeded (Factor)
Spar (on wing) - Inadequate inspection

Factual Information

History of Flight

Initial climb
Aircraft structural failure (Defining event)

Uncontrolled descent
Aircraft structural failure

On April 4, 2018, about 0953 eastern daylight time, a Piper PA-28R-201, N106ER, collided with terrain following an in-flight separation of the left wing near the wing root during climb after a touch-and-go maneuver at Daytona Beach International Airport (DAB), Daytona Beach, Florida. The airline transport pilot and private pilot were fatally injured, and the airplane was destroyed. The airplane was registered to and operated by Embry-Riddle Aeronautical University (ERAU) under the provisions of Title 14 Code of Federal Regulations (CFR) Part 91 as an instructional flight. Day visual meteorological conditions prevailed at the time of the accident, and no flight plan was filed for the local flight.

The private pilot was conducting a practical test to obtain a commercial pilot certificate with an airplane single-engine land rating, and the airline transport pilot was acting as a designated pilot examiner (DPE). Radar and voice communication data provided by the Federal Aviation Administration (FAA) and automatic-dependent surveillance broadcast (ADS-B) data provided by the operator revealed that the private pilot began the training flight by departing runway 25L about 0927. The airplane then turned southbound and climbed to about 3,000 ft mean sea level (msl) at a groundspeed of 100 knots. The airplane flew about 14 miles to the south of DAB, and several climbing and descending turns occurred between 1,300 and 3,000 ft. About 0940 the airplane leveled off at an altitude about 2,200 ft and airspeed of 112 knots on an easterly ground track before turning northbound toward DAB.

The airplane tracked parallel to the coastline about 5 miles inland at 2,200 ft and 115 knots before descending gradually to enter the DAB traffic pattern. About 0940, the private pilot contacted the DAB south arrival radar controller and advised he was inbound to DAB for "closed traffic" (that is, he stated his intention to perform successive operations in the airport traffic pattern) and had automatic terminal information service "Yankee." The controller issued a transponder squawk code, which the private pilot acknowledged.

About 1 minute later, the controller informed the pilot that the airplane was in radar contact and assigned the pilot the ROSE 25 arrival. (The ROSE 25 arrival is used by local aircraft inbound to DAB from the south.) At 0945:00, the pilot advised the DAB tower controller that he was on the ROSE 25 arrival. The DAB tower controller instructed the pilot to follow a Cessna Skyhawk and to maintain 1,500 ft, which the pilot acknowledged. About 0947, the tower controller cleared the pilot to descend to the traffic pattern altitude and join the downwind leg while continuing to follow the Cessna.

About 0948, the DAB tower controller cleared the pilot to land on runway 25, which the pilot acknowledged, stating "we're uh cleared for uh closed traffic." The DAB tower controller responded that the pilot was "cleared for the option"—that is, at the pilot's discretion— which the pilot acknowledged. The pilot subsequently performed a touch-and-go maneuver on runway 25.

During the airplane's initial climb after the touch-and-go maneuver, the DAB tower controller advised the pilot at 0951:44 to continue upwind until advised when to turn crosswind. At 0952:28, the controller instructed the pilot to squawk one two zero four, which the pilot read back. At 0952:47, the pilot asked the DAB tower controller, "…can we turn crosswind." The controller replied, ",,,negative, continue upwind," which was not acknowledged. There were no further communications from the accident airplane. According to ADS-B data, the airplane's radar target was lost about 0953; it was last recorded about 2 miles beyond the departure end of runway 25L at an altitude of 900 ft and a groundspeed of 80 knots.

Witnesses within 1/4 mile of the accident site reported the airplane climbed "normally" on a westerly heading when they saw a wing separate from the fuselage. The wing appeared to "float" down and the airplane descended in a steep spiral before it impacted a field.

Flight Instructor Information

Certificate: Airline Transport; Flight Instructor
Age: 61, Male
Airplane Rating(s): Multi-engine Land; Single-engine Land
Seat Occupied: Right
Other Aircraft Rating(s): None
Restraint Used: 3-point
Instrument Rating(s): Airplane
Second Pilot Present: Yes
Instructor Rating(s): Airplane Multi-engine; Airplane Single-engine; Instrument Airplane
Toxicology Performed: Yes
Medical Certification: Class 2 With Waivers/Limitations
Last FAA Medical Exam: 04/05/2017
Occupational Pilot: Yes
Last Flight Review or Equivalent:
Flight Time: (Estimated) 27600 hours (Total, all aircraft)

Pilot Information

Certificate:Private
Age:25, Male
Airplane Rating(s): Single-engine Land
Seat Occupied: Left
Other Aircraft Rating(s):None
Restraint Used: 3-point
Instrument Rating(s): Airplane
Second Pilot Present: Yes
Instructor Rating(s): None
Toxicology Performed: Yes
Medical Certification: Class 2 Without Waivers/Limitations
Last FAA Medical Exam: 06/17/2016
Occupational Pilot: No
Last Flight Review or Equivalent: 08/31/2017
Flight Time:  218.2 hours (Total, all aircraft), 26.8 hours (Total, this make and model), 115 hours (Pilot In Command, all aircraft), 26.5 hours (Last 90 days, all aircraft), 7 hours (Last 30 days, all aircraft), 0 hours (Last 24 hours, all aircraft)

The pilot, age 25, held a private pilot certificate with ratings for airplane single-engine land and instrument airplane. He was issued an FAA second-class airman medical certificate on June 17, 2016, with no limitations. Review of the pilot's logbook revealed that he had accrued 218.2 total hours of flight experience of which 26 hours were in the accident airplane make and model.

According to FAA records, the DPE, age 61, held an airline transport pilot certificate with ratings for airplane-single engine land and airplane multiengine land. He held a flight instructor certificate with ratings for airplane single-engine, airplane multiengine, and instrument airplane. The DPE was issued an FAA second-class medical certificate on April 5, 2017. He reported 27,600 hours total hours of flight experience of which 400 hours were flown during the 6 months before receiving the medical certificate. The DPE's logbooks were not recovered.

Aircraft and Owner/Operator Information

Aircraft Make: PIPER
Registration: N106ER
Model/Series: PA28R 201
Aircraft Category: Airplane
Year of Manufacture:
Amateur Built: No
Airworthiness Certificate: Normal
Serial Number: 2844137
Landing Gear Type: Retractable - Tricycle
Seats: 4
Date/Type of Last Inspection: 03/21/2018, Annual
Certified Max Gross Wt.: 2750 lbs
Time Since Last Inspection: 28 Hours
Engines: 1 Reciprocating
Airframe Total Time: 7662.3 Hours as of last inspection
Engine Manufacturer: Lycoming
ELT: C91 installed, not activated
Engine Model/Series: IO-360-C1C6
Registered Owner: Embry-Riddle Aeronautical University
Rated Power: 200 hp
Operator: Embry-Riddle Aeronautical University
Operating Certificate(s) Held: Pilot School (141)

The PA-28R-201 airplane, commonly referred to as the "Arrow," has been widely used by flight schools for complex airplane (meaning an airplane that has a retractable landing gear, flaps, and a controllable pitch propeller) flight training. According to FAA airworthiness and operator records, the accident airplane (serial number 2844137) was manufactured on September 17, 2007, and was issued a standard airworthiness certificate in the normal category. It was a single-engine, low-wing, four-place airplane equipped with a 200-horsepower, Lycoming IO-360-C1C6 four-cylinder engine that drove a McCauley two-blade, constant-speed propeller.

ERAU purchased the airplane new (with 5.8 hours accrued) from Piper on September 25, 2007, and subsequently sold it to a leasing company, AVN Air, LLC, on September 28, 2007. ERAU leased the airplane from AVN until September 4, 2015, when it purchased the airplane back from the lessor. The airplane registration number was changed from N712ER to N106ER on July 10, 2014. ERAU was the only operator for the entire operational life of the airplane, which had only been used for flight instructor and commercial pilot training and was never used for initial flight training.

The airframe had accumulated 7,690.6 hours of operation before the accident flight, and 28.3 hours since its most recent annual inspection, which was completed on March 21, 2018. Before the accident flight, the total landing cycles were 33,276 based on ERAU information documented in its education and training administration program.

Maintenance

Examination of the airframe maintenance logbook for the life of the accident airplane found that the airframe was inspected every 50 hours alternating between the ERAU 50-hour and ERAU annual inspection. The accident airplane's most recent inspection was an annual inspection completed on March 22, 2018, at an airframe time of 7,662.3 hours. Between March 28 and April 3, 2018, 12 flight instructors operated the accident airplane, and none reported any anomalies or flight operational safety issues with the airplane. One instructor noted "some side load on one landing" in the discrepancy log. There were no reported hard landings during this period, and all maneuvers were reported as "normal."

The ERAU annual inspection contained all the provisions in the Piper recommended annual inspection with some items added by ERAU. According to chapter 5 of the Piper Airplane Maintenance Manual (AMM), the 100-hour inspection was a complete inspection of the airplane and was identical in scope to an annual inspection. The 100-hour inspection was divided into several major groups, including a wing group. Item 13 in the wing group stated, "inspect wing spar to fuselage attachment bolts and brackets" and indicated a recommended interval of 100 hours. According to ERAU, the accomplishment of this item involved removing the small plastic covers over the main spar attach bolts on the lower wing surface to ensure the torque striping on the nuts was not broken. The ERAU inspection would not normally look at the head of the bolts inside the center section even though the airplane interior would be removed from the airplane.

All inspection items for the annual inspection were endorsed by a mechanic and/or inspector, including the wing spar-to-fuselage attachment bolts and brackets. There were no discrepancies pertaining to the wing spars. Examination of an airworthiness directive (AD) compliance list for the airplane revealed that all applicable ADs were in compliance.

The most recent 50-hour inspection occurred on February 27, 2018, at an airframe time of 7,613.4 hours. All the items in the inspection list were endorsed by a mechanic. There were no discrepancies pertaining to the wing spars.

Procedures for a detailed inspection of the wing spars were included in section 57-10-00 of the AMM. The procedures defined airplane usage classes of normal, severe, extreme, and unknown. The normal usage class encompassed most aircraft and included airplanes operated in normal flight training operations, such as the accident airplane. The recommended inspection involved removing the wings from the airplane, visually inspecting the main spar lower caps with a 10-power magnifying glass and performing a dye-penetrant inspection of the spar caps. The special inspections section of the AMM (5-30-00) recommended for airplanes in the normal usage class that the wing spar inspection in 57-10-00 be performed beginning at 30,600 hours, and every 3,000 hours thereafter.

The accident airplane's airframe maintenance logbook indicated four entries for hard landing inspections, dated February 17, August 24, November 11, and November 14, 2011. These four dates corresponded with hard landing entries in the airplane's discrepancy log. The discrepancy log also indicated 14 additional hard landing events including five hard landing events in the 24 months preceding the accident. In each case, maintenance personnel conducted an inspection in accordance with chapter 5-50-00 of the AMM, section 3, which provides instructions for unscheduled maintenance checks.

For reported hard landings, these procedures included inspecting the landing gear, attach points, wheel wells, and fuel tank for damage, as well as internal and external inspections of the wings. These procedures also called for inspecting for popped, cracked, and loose rivets, the wing attach bolts for slippage, damage, and overstress, and the wing skin for wrinkles. Access plates should be removed to inspect for internal damage to ribs, stringers and sparwebs. For each of the hard landing reports, resulting maintenance action determined that no defects were noted with any of the inspection items.

A logbook entry dated July 15, 2014, stated that the airplane was stripped and repainted coincident with the registration change to N106ER. Logbook entries on March 31, 2015, and January 9, February 13, April 25, and July 11, 2017, detailed maintenance to replace rivet nuts, covers, or screws on the lower wing main spar bolt covers. No indications of airplane damage, major repairs, or other significant nonstandard maintenance were noted in the logbook.

Wing Main Spar

Each wing main spar on a Piper-28R-201 airplane is attached to the center wing box with 8 attachment bolts through the main spar upper cap and 10 through the main spar lower cap. As shown in figure 1, the locations on the lower spar cap forward of the spar web are identified as C-1 through C-5, and the locations on the main spar lower cap aft of the spar web are identified as D-1 through D-5 (later in this report, we use L [for the left wing] or R [for the right wing] in addition to the spar cap location identifiers where appropriate [for example, LC-1]). Doublers are riveted to the forward and aft sides of the spar at the attachment location and outboard beyond the bend in the spar that forms the wing dihedral. Flanges for the doublers extend over the main spar upper and lower caps at the forward side of the spar and over the lower cap at the aft side of the spar.


Courtesy of Piper Aircraft, Inc. Arrow Wing Installation Drawings


Figure 1. Diagram showing forward and aft side of wing main spars and associated attachment bolt designator map

Weight and Balance

The airplane was weighed after manufacture and had not been weighed since. The most recent calculated weight and balance report for the airplane listed an empty weight of 1,842.14 lb with a CG position at 86.28 inches. Airplane weight and balance computations and some performance data for the accident flight were recovered at the scene. The airplane's maximum gross takeoff weight (GTW) was indicated as 2,750 lb; the GTW, including occupants, baggage, and fuel, was indicated as 2,524.71 lb, which was 225.29 lb under maximum GTW and the CG was within limits at 86.94 inches.

Previous In-flight Wing Separations on Piper PA-28 Series Airplanes

On March 30, 1987, about 1257 central standard time, a Piper PA-28-181, N8191V, was destroyed when it collided with the ground following an in-flight left-wing separation while in low-level cruise flight near Marlin, Texas (NTSB case number FTW87FA088). The airplane was performing a pipeline patrol flight when the accident occurred. The investigation found fatigue cracking in the left-wing main spar lower cap near attachment bolt hole LC-1. The fatigue cracking initiated on the lower surface of the main spar lower cap and intersected the outboard edge of attachment bolt hole LC-1. The fatigue cracking had progressed from the hole forward through the forward flange and aft about halfway through the main spar lower cap.

On April 10, 1987, the NTSB issued Urgent Safety Recommendations A-87-40 through -42 to the FAA as a result of our preliminary evaluations from the investigation. The recommendations asked for an AD to immediately inspect the main spar lower caps on certain PA-28-series airplanes (A-87-40), a recurrent inspection interval (A-87-41), and a study to determine other Piper airplanes with a similar spar design (A-87-42). The recommendations were respectively classified Closed—Acceptable Action, Closed—Unacceptable Action, and Closed—Acceptable Alternate Action between November 1988 and October 1989. See FAA Actions in Response to Wing Separations in the Additional Information section for more information.

On August 24, 1993, at 2234 eastern daylight time, a Piper PA-28-181, N2093A, was destroyed when it collided with a vehicle and a tree following an in-flight right-wing separation while circling at low level near Provincetown, Massachusetts (NTSB case number NYC93FA140). The airplane was maneuvering in clouds after the non-instrument-rated pilot entered instrument meteorological conditions after takeoff. The investigation found fatigue cracking in the right-wing main spar lower cap near attachment bolt hole RC-1. The fatigue cracking initiated on the lower surface of the main spar lower cap slightly aft and outboard of the edge of hole RC-1 but did not intersect the hole. Several other cracks were noted in the lower surface of the spar cap parallel to the fatigue zone near both attachment bolt holes RC-1 and RD-1. The investigation also found that the nuts used on the wing attachment bolts were incorrect.

Meteorological Information and Flight Plan

Conditions at Accident Site: Visual Conditions
Condition of Light: Day
Observation Facility, Elevation: DAB, 34 ft msl
Distance from Accident Site: 1 Nautical Miles
Observation Time: 0953 EDT
Direction from Accident Site:
Lowest Cloud Condition: Few / 25000 ft agl
Visibility:  10 Miles
Lowest Ceiling: None
Visibility (RVR):
Wind Speed/Gusts: 7 knots /
Turbulence Type Forecast/Actual:
Wind Direction: 260°
Turbulence Severity Forecast/Actual:
Altimeter Setting: 30.03 inches Hg
Temperature/Dew Point: 24°C / 19°C
Precipitation and Obscuration: No Obscuration; No Precipitation
Departure Point: Daytona Beach, FL (DAB)
Type of Flight Plan Filed: None
Destination: Daytona Beach, FL (DAB)
Type of Clearance: None
Departure Time: 0927 EDT
Type of Airspace: Class C

About 0953, reported weather at DAB indicated wind from 260° at 7 knots, 10 statute miles (sm) visibility, and few clouds at 25,000 ft. The temperature was 24°C, the dew point was 19°C, and the altimeter setting was 30.03 inches of mercury. There were no current turbulence or in-flight weather advisories for the area.

Airport Information

Airport: DAYTONA BEACH INTL (DAB)
Runway Surface Type: Asphalt
Airport Elevation: 34 ft
Runway Surface Condition: Dry
Runway Used: 25L
IFR Approach: None
Runway Length/Width: 3195 ft / 100 ft
VFR Approach/Landing: Touch and Go

DAB is 3 miles southwest of Daytona Beach, Florida at 4.1 ft elevation. The airport has three intersecting runways: two parallel runways oriented east/west (7L/25R and 7R/25L), and one oriented north/south (16/34), which was not in use at the time of the accident. Runway 25L is 3,195 ft long,100 ft wide, and constructed of asphalt. Landing traffic for runway 25L operates in a left traffic pattern.

Wreckage and Impact Information

Crew Injuries: 2 Fatal
Aircraft Damage: Destroyed
Passenger Injuries: N/A
Aircraft Fire: None
Ground Injuries: N/A
Aircraft Explosion: None
Total Injuries: 2 Fatal
Latitude, Longitude: 29.158611, -81.085000

The debris path was about 570 ft long and began about 2 sm southwest of the departure end of runway 25L. The first items discovered along the debris path were a rubber wing root seal and fractured window plexiglass; the left wing was discovered 270 ft farther southwest adjacent to a road and tree line. About 200 ft from the wing on a magnetic heading of about 230°, the main wreckage rested in an adjacent field on the opposite side of the road (see figure 2).


Figure 2. Photograph (looking toward the southwest) showing the separated left wing in foreground and main wreckage in background

The forward portion of the fuselage, including the engine, exhibited significant impact-related damage. A strong odor of fuel was present at the site, and a 30-ft-long swath of grass surrounding the wreckage was brown and discolored, which was consistent with the breached right fuel tank and subsequent spillage. The right wing remained attached to the fuselage. The right-wing leading-edge surface was crushed aft uniformly along the span of the wing, and a corresponding impression of the right-wing leading edge was observed in the ground. The flap and aileron of the right wing remained attached. The right landing gear was in the down and locked position.

The vertical stabilizer, rudder, horizontal stabilator, and trim tab control surfaces remained attached. Rudder control continuity was confirmed from the rudder to the rudder pedals. Elevator control cable continuity was established from the control column to the elevator control surface. Aileron control continuity was confirmed from the right aileron to the control column. Continuity of the left aileron control cables was traced from the control column through fracture features, which were consistent with tensile overload separation, to the aileron.

The left wing separated from the fuselage near the wing root and exhibited mid-span buckling of the surface skin. The left-wing flap and aileron remained connected and moved freely with little resistance. The left-wing fuel tank remained intact and contained about 15 gallons of fuel. The left main landing gear was in the down and locked position.

On-scene visual examination of the left-wing main spar found indications of a significant fatigue crack. Further analysis at the NTSB's Materials Laboratory found that more than 90% of the main spar lower cap and portions of the forward and aft spar web doublers exhibited fracture features consistent with metal fatigue (see figure 3). The remainder of the main spar lower cap, spar web doublers, and upper spar cap displayed fracture features consistent with overstress fracture. The fatigue features originated at or near the outboard forward wing main spar attachment bolt holes LC-1 and LD-1.

Figure 3. Left-wing main spar lower cap inboard side of the fracture (left frame) and outboard side of the fracture (right frame) with red arrows highlighting areas visually inspected on scene that showed fatigue regions

Medical And Pathological Information

The Office of the Medical Examiner, Daytona Beach, Florida, performed autopsies of the pilot and DPE and determined the cause of death for both to be multiple blunt force injuries.

The FAA Forensic Sciences Laboratory performed toxicological testing on the pilot and DPE; the tests yielded negative results for the presence of drugs and alcohol.

Tests And Research

N106ER Wing Main Spar Examinations

The left-wing main spar lower cap (shown in figure 4) had a fracture that intersected holes for attachment bolts LC-1 and LD-1. Portions of the fracture surface had relatively smooth features in a transverse plane, which is consistent with fatigue fracture. Crack arrest lines were visible on the fracture surfaces of the main spar lower cap and on the forward and aft doublers, also consistent with fatigue fracture. The upper spar cap displayed rough matte gray features consistent with ductile overstress fracture. Deformation associated with the fracture in the upper spar cap was observed, consistent with an upward bending load.

In the doublers, fatigue origins were noted on the lower sides of the doublers both forward and aft of the attachment holes. The fatigue region in the forward doubler was larger than in the aft doubler, extending to the forward edge of the doubler and upward about 1.25 inches from the aft side of the hole. In the aft doubler, the fatigue regions extended from each side of the hole to where they were about 0.88 inch apart.


Figure 4. Photographs showing pieces of the accident left-wing main spar lower cap and doublers before (left) and after (right) sectioning and rivet removal to facilitate examination.

The left-wing main spar lower cap was examined using a scanning electron microscope (SEM). SEM images of the origin areas at the forward and aft sides of attachment bolt hole LC-1 are shown in figure 5. Arrows indicate local directions of fatigue crack propagation based on available fracture features in the images. Fracture features appeared to emanate from origins at the lower surface of the spar cap adjacent to attachment bolt hole LC-1.


Figure 5. SEM images of fracture features at the aft side of hole LC-1 with a view of the origin area shown at higher magnification (lower image). Unlabeled arrows indicate local directions of fatigue crack propagation

Hardness and conductivity measurements of pieces of the left-wing main spar lower cap were consistent with the specified material. Measured thickness was within the allowable thickness range specified in the engineering drawing. Tensile tests and chemical analysis also showed that mechanical properties and chemistry conformed to specified material requirements.

The right-wing main spar was partially fractured through the outboard attachment bolt holes, and the outboard end of the piece was deflected forward. The right-wing main spar lower cap piece was further examined using an SEM, and the results showed that a portion of the main spar lower cap fracture surface had striations consistent with a fatigue region on the lower aft side of hole RC-1. Fatigue features emanated from an origin area located at the hole surface, extending up to 0.047 inch aft of the hole and 0.038 inch upward from the lower surface of the spar cap.

The overstress fracture at the forward side of hole RC-1 was located outboard of the transverse plane intersecting the hole center. A crack was observed at the forward edge of hole RC-1 where it intersected the lower surface. Smooth fracture features with curving crack arrest lines were observed consistent with fatigue fracture. Ratchet marks were also observed, consistent with multiple fatigue origins.

Postaccident Inspection of Sister Airplane N104ER

Immediately following the accident, ERAU conducted a visual inspection of the wing main spar caps of another PA-28R-201 in its fleet, N104ER, manufactured in 2007 with a serial number (S/N 2844135) two less than the accident airplane. No visual indications of cracking were noted. In addition, two hard landing inspections were recorded in the aircraft logbooks with no discrepancies noted. On April 9, 2018, N104ER, which had accrued 7,660.7 hours time-in-service (29.9 hours less than the accident airplane) and 33,288 landings (12 more than the accident airplane) was subjected to nondestructive inspection by a local FAA-approved repair station.

Specifically, the repair station performed a high frequency eddy current (HFEC) bolt hole inspection of N104ER's left and right lower outboard wing attachment bolt holes (holes C-1 and D-1) with the wings installed, and there were no abnormal findings. The wings were then removed and a follow-up inspection was conducted by the NTSB structures group, an American Society for Nondestructive Testing level III nondestructive testing engineer, and a level II certified ultrasonic testing inspector. Using an HFEC surface probe, this inspection revealed a crack indication on the forward side of attachment bolt hole LC-1. No cracks were discovered on the remaining bolt holes or spar caps.

The NTSB structures group proposed that the wings be reinstalled on N104ER by the same personnel and inspectors to help Piper and FAA evaluate an HFEC inspection procedure developed by Piper that would use a bolt hole probe instead of the surface probe used in the previous examination. The inspection confirmed the crack indication in attachment bolt hole LC-1. The inboard portion of the left-wing main spar was cut from the wing of N104ER and sent to the NTSB Materials Laboratory for additional examination. As shown in figure 6, a crack feature was visible under optical magnification (the bracket in figure 6 indicates the location of a crack feature extending from the forward side of attachment bolt hole LC-1). No crack features were detected under optical magnification at the aft side of attachment bolt hole LC-1.


Figure 6. Magnified image showing a faintly visible crack feature extending from the forward side of attachment bolt hole LC-1

SEM examination of a sectioned piece of the fractured left-wing main spar from N104ER found the crack fracture surface had relatively smooth features with curving crack arrest lines, which are features consistent with fatigue. The fatigue region extended up to 0.126 inch forward from the hole surface and up to 0.115 inch upward from the lower surface. Where the fatigue region intersected the lower surface, the length from the hole surface to the fatigue boundary was 0.119 inch. A closer view of the fatigue origin area showed ratchet marks indicating multiple fatigue origins in the area located within the corner radius between the bore of attachment bolt hole LC-1 and main spar lower surface.

Another ERAU Piper PA-28R-201 airplane, N102ER (S/N 2844081, manufactured in March 2012 and with 5,864.6 hours [1,826 less than the accident airplane] and 15,808 cycles [17,468 less than the accident airplane]), was inspected. The right and left lower outboard wing attachment bolts (C-1 and D-1) were removed for inspection by HFEC surface probe, and no indications of cracking were found. The maintenance records weren't examined for N102ER.

Piper Aircraft, Inc., personnel, observed by the NTSB structures group, performed HFEC inspections on the remaining five ERAU PA-28R-201 airplanes (N108ER, N110ER, N115ER, N116ER and N117ER) using a bolt hole probe instead of a surface probe (the maintenance records for these airplanes weren't examined). These inspections revealed no cracking on any of the remaining fleet airplanes (for more information, see the NTSB Structures Group Chairman's Factual Report in the public docket for this investigation).

Inspections of Piper PA-28R-201 Airplanes at Other Training Facilities

The flight training facilities in the following table submitted various numbers of Piper PA-28R-201 airplanes to HFEC bolt hole probe inspection by Piper in conjunction with the NTSB structures group. Brief descriptions of the airplanes' operational lives and inspection findings are also provided (for more information about these airplanes and the inspections, see the NTSB Structures Group Chairman's Factual Report in the docket for this accident investigation).



Evaluation of Exposure to Severe Weather

While investigating additional potential sources of the damage observed on the accident airplane, the structures group considered the possible impact of severe weather. Since 2007, the ERAU campus in Daytona Beach, Florida, has been impacted by two hurricanes: Hurricane Matthew in October 2016 and Hurricane Irma in September 2017. In October 2016, the ERAU fleet was moved to Auburn University Regional Airport (AUO) in Auburn, Alabama, in accordance with ERAU's Emergency Response Plan, which indicates that ERAU aircraft that can fly will be evacuated to a safe location before storm arrival. In September 2017, part of the ERAU fleet was moved to AUO while the Piper PA-28R-201 airplanes, including N106ER and N104ER, were moved to Birmingham-Shuttlesworth International Airport, Birmingham, Alabama. None of the Piper-28-201 airplanes were damaged during Hurricane Irma because the storm tracked closer to Auburn and spared Birmingham (two of the Cessna airplanes at AUO were damaged).

Inspection of New Wing Main Spar Pieces

Piper Aircraft provided pieces from three different lots of recently purchased main spar extrusions for examination. Hardness and conductivity measurements were made on the lower caps of each new spar piece, and results were consistent with expected values for the specified material. The grain structure was comparable to the microstructure from the accident airplane's main spar lower cap.

US Air Force (USAF) Examination

Due to their technical expertise in aging aircraft and metal fatigue, members of the USAF A-10 Aircraft Structural Integrity Program (ASIP) were invited to participate in the NTSB's investigation as part of the structures group. The USAF participants were asked to perform an independent analysis of the accident airplane failure using the methods they have perfected for use on the A-10 airplane.

The USAF first examined the historical usage of N106ER (the accident airplane) and N104ER (its sister airplane) to develop a load spectrum based on the information contained in a report prepared by the Lockheed Georgia Company for Piper as part of the 1987 wing-separation accident investigation. A preliminary crack growth analysis was then performed to validate the assumptions, load spectrum, and stress levels. A finite element model of the main spar lower cap was created and validated for use in obtaining the internal stresses in the lower cap. The USAF then used the Broad Application for Modeling Fracture (BAMF) to join the preliminary crack growth analysis and finite element model and provide a 3-D structural representation of the main spar lower cap. The BAMF analysis was run several times to examine the effect of initial flaw size and the fastener fit on the fatigue crack growth in the lower cap. The model results were then compared to the evidence from N106ER and N104ER.

Combining the average flight time between landings for both N106ER and N104ER (14.2 minutes for the life of the airplanes) with the normal climb and descent rates for the PA-28R- 201 showed that both airplanes spent most of their lives operating below 2,500 ft agl in normal operation; therefore, since peak gust velocities are inversely proportional to altitude, these airplanes remained in a more severe gust environment for their operational life than a personal use airplane. The BAMF analysis assumed a severe gust environment similar to the pipeline patrol gust environment detailed in the Lockheed report, but maneuvering loads for the flight training mission were less severe. A full load spectrum was developed and included taxi, gust, maneuver (severity reduced from pipeline patrol in the Lockheed report), and landing loads.

The accident airplane had three separate fatigue cracks in the left wing main spar lower cap that all initiated at or near the lower corner of a fastener hole. The NTSB was unable to determine which crack initiated first. The results of the USAF analyses, which were performed with varying initial flaw sizes at each location and with an open or filled hole configuration, showed that the initial flaw size has a significant effect on the fatigue life, the crack growth rate increases significantly once the crack size reaches about 0.050 inch, and the filled hole provides a life improvement on the order of 1.5.

The USAF also examined the damage tolerance of the lower cap. There is an unknown portion of the spar cap's fatigue life before fatigue crack initiation and propagation to a detectable size. Detectable size limits differed depending on the type of nondestructive inspection using HFEC: manual right-angle probe, a manual bolt hole probe, or a semi-automated bolt hole probe. The USAF has not accepted the use of manual HFEC bolt hole inspection because the method reduces the probability of detection due to its reduced sensitivity and human factor variables.

The data indicate that the detectable crack size for an HFEC inspection with a semi-automated bolt hole probe is 0.050 inch and if using a manual probe, the assumed detectable crack size would be 0.250 inch. Using the crack growth data and the detectable crack size for a manual probe showed that a significant portion of the fatigue life is gone before the crack becomes detectable. The USAF estimated that the sister airplane's wing, with a fatigue crack measured at 0.18 inch, was less than 2,000 hours from failure.

Organizational And Management Information

ERAU Commercial Flight Program

ERAU operated as a 14 CFR Part 141 flight school. Unlike pilot training conducted under 14 CFR Part 61, Part 141 flight schools are required to use a structured training program and syllabus. For this accident investigation, the review of ERAU commercial flight program objectives was limited to commercial pilot flight operations pertinent to airplane single-engine land (ASEL) training.

According to the ERAU commercial pilot ASEL flight training course syllabus, the flight training course outline was for private pilots with airplane single-engine land and instrument airplane ratings seeking to attain an FAA commercial pilot certificate with a rating for airplane single-engine land. The syllabus contained 38 commercial lessons consisting of 9 oral lessons, 5 flight-training device lessons, 15 non-complex flight lessons (conducted in a Cessna 172), and 9 lessons in the complex category using a PA-28R-201 airplane. The suggested lesson time for the complex flight training was 14.7 hours.

ERAU Flight Instructor Interviews

Three front-line commercial instructors were interviewed at the ERAU Daytona Beach campus regarding flight operations and their experience in the PA-28R-201 and its usage. The instructors were independently questioned and each relayed corroborating statements.

According to the instructors, the PA-28R-201 was used for complex operations only and accounted for about one-third of the commercial flight training.

Typically, each flight lesson was about 1.5 to 1.8 hours; of that, 1.2 hours were spent in the airport traffic pattern, and between five and eight takeoffs and landings were conducted per flight. Of those, over half were simulated emergency approach and landings, also known as "power-off 180s." As described, the maneuver involved reducing the engine power to idle to simulate a loss of engine power while in the airport traffic pattern on downwind. The student attempted to land on a specific point of the runway using normal stabilized maneuvers and control input. The instructors stated the landings were "firm" and that this maneuver was "where most pilots get behind the airplane."

When questioned about emergency descents, all the instructors stated that the maximum G- load was no higher than perceived 1.5 Gs, with the objective to descend the airplane as rapidly as possible while maintaining operational limitations. The instructors described the maneuver as moderate and stated that they had never experienced excessive G loads or airframe limitations during the maneuver. They stated that most airspeed exceedances occurred during flap extension and for landing gear operation and that most occurred during gusty conditions though typically only by a "couple of knots" over a short duration.

Six additional flight instructors were interviewed later, and, according to them, the PA-28R- 201 was used only for commercial or flight instructor training. The block time was scheduled for 2.3 hours but the average flight time per flight is between 1.5 to 2.0 hours. They operate between 2,500 to 3,000 ft msl for maneuvers in the practice area. If they were conducting emergency descents, they may climb up to 5,000 ft msl briefly, however, they spent most of their time between the surface and pattern altitude (about 1,000 feet agl) practicing takeoff and landings.

ERAU Maintenance

ERAU's maintenance facility operated under 14 CFR Part 145 as a certified repair station, and its maintenance program was certified by the FAA. All ERAU airplanes, including engines, systems, and appliances, were maintained in a continuous state of airworthiness by a program of preventive and corrective maintenance. The ERAU maintenance and quality department was responsible for the airworthiness, maintenance, servicing, alteration, and inspection of ERAU airplanes, as well as the maintenance or alterations performed on ERAU aircraft by other organizations.

ERAU Safety Reporting

The ERAU Aviation Safety Department has an established system in place for flight crews and maintenance personnel to voluntarily identify and report safety and operational concerns. The collected information was reviewed and analyzed to facilitate early detection and improved awareness of operational deficiencies and adverse trends.

There were two primary methods to report safety issues: an aviation safety action program (ASAP) for employees to voluntarily identify and reduce possible flight safety concerns and a flight operations general safety reporting system for employees to voluntarily identify safety and operational deficiencies within their respective departments.

A review of limited and redacted PA-28R-201 ASAP data covering the 24 calendar months preceding the accident found one tailstrike event involving the accident airplane, but no damage occurred. The rest of the data showed nothing across the entire fleet of PA-28R-201s that appeared to be a safety of flight issue or reported damage or issues with the wing(s) or wing main spar as the result of an in-flight airframe exceedance, high G-load, or hard landing event.

A review of PA-28R-201 general safety reporting system data from April 1, 2016, to just before the accident found no known flight operation events that indicated damage to the wing main spar of the accident airplane. According to the ERAU flight crew safety reporting system, all of the hard landing events reported in the 24 months before the accident resulted in "no defects noted" and were captured in the maintenance discrepancy log. There were no additional reported events across the fleet that indicated a safety of flight issue or damage or issues with the wing(s) or wing main spar as the result of an exceedance, high G-load, or hard landing event.

Additional Information

Fatigue Certification Requirements and Guidance

The Piper PA-28R-201 was type certificated under Part 3 of the Civil Air Regulations (CAR), according to Type Certificate Data Sheet 2A13. The only fatigue requirements in CAR 3 effective for the airplane were that the design details should avoid stress concentrations.

In contrast to the relative lack of fatigue requirements when the Piper PA-28R-201 was type- certificated, guidance in Advisory Circular (AC) 23-13A (released on September 29, 2005) provides an acceptable means of compliance with the Part 23 regulations for fatigue, fail-safe, and damage-tolerance evaluations of metallic airplane structure. The AC contains approved gust and maneuver loads for the various types of operations of single-engine airplanes; see the NTSB Structures Group Chairman Report for more information.

FAA Actions in Response to Wing Separations

In response to Urgent Safety Recommendation A-87-40, the FAA issued emergency AD 87-08-08 in April 1987, to require the inspection of the wing main spar lower caps on all PA-28, PA-32-260, and PA-32-300 model airplanes. The AD required removal of the wings, a visual inspection with a 10-power magnifying glass, and dye penetrant inspection of the main spar lower caps "from the wing skin line, outboard of the outboard row of wing attach bolt holes to an area midway between the second and third row of bolt holes from the outboard row" for both wings. The AD required the replacement of any wing spars found to be cracked, as well as the visual inspection of the upper wing skins for cracks.

In August 1987, the FAA issued revised AD 87-08-08R1, which removed Piper PA-28-201T airplanes from the group of affected airplanes because they had a different spar design. In September 1987, the FAA issued revised AD 87-08-08R2, which suspended the effectivity of the AD while the issue was reevaluated and additional data were examined. In May 1989, the FAA issued revised AD 87-08-08R3, which rescinded the original AD and revisions R1 and R2.

In the discussion published for the rescission, the FAA reported that its inspection results from about 560 airplanes showed only two Piper PA-32-300 airplanes with spar cracks. The cracks were discovered in airplanes that were operated overweight, in "severe" environments, and had documented damage and repairs. Based on its examination of fatigue test data from Piper and a fracture mechanics analysis, the FAA concluded that the cracks found on the two airplanes were isolated occurrences and not likely to exist or develop in other PA-28 and PA-32 series airplanes operated in a normal usage class environment.

The FAA maintained in the rescission that instructions provided in FAA-approved Piper Service Bulletin (SB) 886, which was published in conjunction with AD 87-08-08, would address the inspection of the wing spars for those PA-28 and PA-32 series airplanes that were operated in a severe usage class environment. Based on additional fatigue analysis work done by Piper and Lockheed after the 1987 accident, SB 886 contained instructions for determining the usage class of affected airplanes and inspecting the wing spars at prescribed times.

In response to the preliminary findings from the NTSB's investigation of the April 4, 2018, accident, the FAA issued a notice of proposed rulemaking (NPRM) for a new AD applicable to most Piper PA-28, all PA-28R, and most PA-32 series airplanes. The proposed AD would require calculating the factored service life for the wing main spar, eddy current inspection of the main spar lower outboard attachment bolt holes for cracks at a specified time, and replacing any cracked wing main spars. In the NTSB's comments submitted to the FAA on February 15, 2019, we expressed our support of the proposed AD's inspection requirements for all PA-28R and most PA-32 airplanes but noted that the risks associated with disturbing the joint to complete the required inspection may outweigh the risk of fatigue cracking in all affected PA-28 series airplanes other than the PA-28-235 and urged the FAA to reexamine the proposed AD's applicability.

Airframe Manufacturer's Information

Maintenance information for the PA-28R-201 in chapter 4 of the AMM specifies that "No limitations, related to fatigue life of the airplane and its components, have been established for the PA-28R-201 Arrow airplane" and there are no mandatory structural inspection intervals.

Piper published Service Letter (SL) 997 in May 1987 to supplement AD 87-08-08. The SL provided instructions for the removal and reinstallation of the wings on all PA-28, PA-28R, and PA-32 series airplanes. Warnings were included in the SL to use extreme care when removing and reinstalling the wing attachment hardware to preclude damaging the holes.

Piper published SB 886 in June 1988 after the original issuance of AD 87-08-08 and the subsequent revisions of the AD to provide instructions for inspecting the wing main spar on certain PA-28, PA-28R, and PA-32 model airplanes. Piper considered the FAA-approved SB instructions mandatory. The SB divided the airplanes into two groups and defined four usage classes, A through D (see figure 7) based on an accounting of the lifetime usage to determine the inspection compliance times. The SB provided instructions for calculating a factored service life for airplanes that had a mixture of Class A and B usage. The SB also provided a table to specify the initial inspection time and recurring inspection interval once the airplane group and usage class were determined.

Figure 7. Excerpt of Service Bulletin 886 from 1988 showing usage categories

Class A airplanes had an initial inspection time of 30,600 hours or 62,900 hours depending on the group. Class B or mixed Class A and B airplanes had an initial inspection time of 1,800 factored hours or 3,700 factored hours depending on the group. Class C and D airplanes had an initial inspection time within 50 hours' time-in-service from the issuance of the SB. In August 1999, Piper published SB-978A, which was identical to SB 886 but added additional PA-28 and PA-28R series airplanes that were not manufactured at the time SB 886 was published.

Many of the Piper PA-28 series airplanes have the same or very similar spar configuration as the PA-28R-201 accident airplane at the wing attach location. The spar configuration for the following airplanes is identical to the accident airplane:

· PA-28-140/-150/-151/-160/-161/-180/-181/-235;
· PA-28R-180/-200/-201T;
· PA-28RT-201/-201T; and
· PA-32-260/-300 airplanes

The spar configuration on the remaining unlisted PA-28, PA-32, PA-34, and PA-44 series airplanes, while similar, uses additional structural elements and/or different fasteners that differentiate the spar configuration.

In late 2018, the Piper Aircraft engineering group performed analysis work to assess the risk of wing-spar fatigue within the PA-28 airplane fleet using FAA data published in AC-23-13A. This proprietary analysis determined that an airplane in the flight training environment has higher loads than personal use that increase the risk of fatigue at the wing main spar lower outboard attachment bolt hole.

Piper's comparison of each of the airplane models above with an identical spar configuration to the accident airplane showed that PA-28R-180/-200/-201T, the PA-28RT-201/-201T, and PA-32-260/-300 airplanes have similar loads and fatigue lives to the PA-28R-201 and warrant further consideration for applicability under the proposed AD, especially if operated in the training environment. Piper's analysis for all PA-28 (fixed landing gear) airplanes, except for PA-28-235/-236 airplanes, showed that the loads were less and the resulting fatigue lives were higher than the PA-28R-201. Piper's analysis for PA-28-235/-236 airplanes indicated that the fatigue lives when operated in the training environment are similar to the PA-28R-201. However, Piper maintains that these airplanes are unlikely to be operated in this environment due to their higher operational costs.

Zachary Michael Capra



Lawrence McCarter
Investigator In Charge


Location: Daytona Beach, FL
Accident Number: ERA18FA120
Date & Time: 04/04/2018, 0953 EDT
Registration: N106ER
Aircraft: PIPER PA28R
Injuries: 2 Fatal
Flight Conducted Under:  Part 91: General Aviation - Instructional

On April 4, 2018, at 0953 eastern daylight time, a Piper PA-28R-201, N106ER, collided with terrain following an in-flight breakup shortly after takeoff from Daytona Beach International Airport (DAB), Daytona Beach, Florida. The airline transport pilot and private pilot were fatally injured, and the airplane was destroyed. The airplane was registered to and operated by Embry-Riddle Aeronautical University and operated under the provisions of 14 Code of Federal Regulations Part 91 as an instructional flight. Day visual meteorological conditions prevailed at the time of the accident, and no flight plan was filed for the local flight, which departed DAB at 0927.

According to the operator, the private pilot was conducting his commercial pilot single-engine land practical test, and the airline transport pilot was acting as a designated pilot examiner (DPE).

Preliminary radar and voice communication data provided by the Federal Aviation Administration (FAA) revealed that the airplane flew to the southeast after departure; after maneuvering, it returned to DAB. The airplane entered the airport traffic pattern and performed a touch-and-go landing. While climbing out after the takeoff from runway 25L, air traffic control issued the pilot a discrete transponder code, and shortly after, the pilot asked if they could make a left turn to the crosswind leg of the traffic pattern. The controller responded by telling the pilot to continue upwind. Radar data indicated that the airplane climbed to 900 ft mean sea level at a groundspeed of 80 knots on a heading of 240° before radar contact was lost.

According to multiple witnesses, all located within 2,500 ft of the accident site, they saw the airplane flying normally, then watched as the left wing separated from fuselage. The fuselage impacted a field, while the wing descended separately and landed in an adjacent field.

According to FAA records, the pilot, age 25, held a private pilot certificate with ratings for airplane single-engine land and instrument airplane. His most recent FAA second-class medical certificate was issued on June 17, 2016. He reported 201 hours of flight experience as of his most recent logbook entry on March 19, 2018.

According to FAA records, the DPE, age 61, held an airline transport pilot certificate with ratings for airplane single- and multiengine land. In addition, he held a flight instructor certificate with ratings for airplane single- and multiengine and instrument airplane. His most recent FAA second-class medical certificate was issued on April 5, 2017. At that time, he reported 27,600 total hours of flight experience.

According to FAA airworthiness and operator records, the airplane was manufactured on September 17, 2007 and was issued a standard airworthiness certificate in the normal category. It was a single-engine, low-wing, four-place airplane with a 200-horsepower, Lycoming IO-360-C1C6 four-cylinder engine and a McCauley two-blade, constant-speed propeller. The airframe had accumulated 7,690.6 hours of operation at the time of the accident, and 28.3 hours since its most recent annual inspection, which was completed on March 21, 2018.

A surface observation weather report taken at DAB at 0953 indicated the wind was from 260° at 7 knots, the visibility was 10 statute miles, and few clouds at 25,000 ft. The temperature and dew point were 24°C and 19°C, respectively, and the altimeter setting was 30.03 inches of mercury.

The debris path was about 450 ft long, and the debris path began about 2 statute miles southwest of the departure end of runway 25L. The first items along the debris path included a rubber wing root seal and small pieces of window plexiglass, followed shortly thereafter by the left wing. The main wreckage impacted the adjacent field about 200 ft from the wing on a magnetic heading about 230°.

The forward portion of the fuselage, including the engine, exhibited significant impact-related damage. There was a strong odor of fuel at the site, and a large area of grass surrounding the wreckage was discolored. The right wing remained attached to the fuselage. An impression of the right wing leading edge was observed in the ground, and the right wing leading edge surface was crushed aft to the wing spar along the entire span of the wing. The flap and aileron of the right wing remained attached. The right landing gear was in the down and locked position.

The vertical stabilizer, rudder, horizontal stabilator, and trim tab control surfaces remained attached. Rudder control continuity was confirmed from the rudder to the rudder pedals. Elevator control cable continuity was established through cuts made to facilitate the wreckage recovery from the control column to the elevator control surface. Aileron control continuity was confirmed from the right aileron to the control column. Continuity of left aileron control cables was traced from the control column through fracture features consistent with tensile overload separation to the aileron.

The left wing separated from the fuselage near the wing root and exhibited mid-span buckling of the surface skin. The left wing flap remained connected and moved freely with no resistance. The left main landing gear was in the down and locked position. The left wing fuel tank remained intact and contained about 15 gallons of fuel.

The fractured left wing main spar portions, along with the box assembly and attached inboard end of the right wing main spar, were forwarded to the NTSB Materials Laboratory for detailed examination. Preliminary examination of the left wing main spar revealed that more than 80% of the lower spar cap and portions of the forward and aft spar web doublers exhibited fracture features consistent with metal fatigue (see figure 1).


Figure 1 - Left wing main spar lower cap fracture surface.

The remainder of the lower spar cap, spar web doublers, and upper spar cap displayed fracture features consistent with overstress fracture. The fatigue features originated at or near the outboard forward wing spar attachment bolt hole (see figure 2). None of the surfaces exhibited visible evidence of corrosion or other preexisting damage. The right wing also exhibited fatigue cracks in the lower spar cap at the same hole location extending up to 0.047-inch deep.



Figure 2 – Exploded view of left wing spar assembly and attachment bolts.

The wreckage was retained for further examination.

Aircraft and Owner/Operator Information

Aircraft Manufacturer: PIPER
Registration: N106ER
Model/Series: PA28R 201
Aircraft Category: Airplane
Amateur Built: No
Operator: Embry-Riddle Aeronautical University
Operating Certificate(s) Held: Pilot School (141)

Meteorological Information and Flight Plan

Conditions at Accident Site: Visual Conditions
Condition of Light: Day
Observation Facility, Elevation: DAB, 34 ft msl
Observation Time: 0953 EDT
Distance from Accident Site: 0 Nautical Miles
Temperature/Dew Point: 24°C / 19°C
Lowest Cloud Condition: Few / 25000 ft agl
Wind Speed/Gusts, Direction: 7 knots, 260°
Lowest Ceiling: None
Visibility: 10 Miles
Altimeter Setting: 30.03 inches Hg
Type of Flight Plan Filed: None
Departure Point: Daytona Beach, FL (DAB)
Destination: Daytona Beach, FL (DAB)

Wreckage and Impact Information

Crew Injuries: 2 Fatal
Aircraft Damage: Destroyed
Passenger Injuries: N/A
Aircraft Fire: None
Ground Injuries: N/A
Aircraft Explosion: None
Total Injuries: 2 Fatal
Latitude, Longitude: 29.158611, -81.085000



https://youtu.be/-D5vCoWKgII
Roy Williams of Airframe Components shows how to inspect the Piper Aircraft aft wing attach fittings, in Service Bulletin 1244B.

 https://youtu.be/7WHNw289csE
Service bulletin 1006 talks about replacing fuel tanks in the Piper Aircraft wings. Airframe Components shows you how to check your wings to find out if you need this repair.

















DAYTONA BEACH — The family of an Embry-Riddle Aeronautical University student killed in a plane crash along with a federal examiner last year when a wing detached from the airplane is suing Piper Aircraft alleging it knew of structural failures in that model since 1987 but failed to warn pilots and owners, or require testing that could have saved lives.

Zack Capra, a 25-year-old Navy veteran who was taking his commercial pilot license exam, and Federal Aviation Administration pilot examiner John Shahriar Azma, a father of four, were killed on April 4, 2018, when the left wing came off the Piper PA-28 as they flew west of Daytona Beach International Airport.

In the April crash, the plane had climbed to 900 feet when radar contact was lost. It crashed in a cow pasture along Tomoka Farms Road near the Daytona Flea & Farmer’s Market.

“The horror and fear of impending death for pilots from an in-flight breakup of their aircraft cannot be overstated as it is a pilot’s worst nightmare come true,” according to the wrongful death lawsuit filed by Capra’s father, John Charles Capra, who is administrator of his son’s estate.

John Capra had posted on his Facebook page recent tattoos in honor of his son. One showed an eagle with a scroll with the words “Tailwinds of hope.” The other tattoo was a drawing of the blue and white Piper his son was flying compete with its registration, N106ER. Above the plane were the letters “RIP ZMC JSA” and below it were a latitude and longitude.

Investigators found cracks consistent with metal fatigue beginning at or near an attachment bolt hole on the left wing spar, a metal piece that bears the load of the wing, according to the National Transportation Safety Board’s preliminary report. The right wing also had fatigue cracks at the same location.

After the crash the investigators found another Piper PA-28 at the university with a similar crack to the one in the deadly crash. The second plane had just over 7,600 hours of flight time. FAA records showed the plane was registered to the university. The college grounded its fleet of about a half-dozen Piper PA-28s.

Jacqueline Carlon, spokeswoman for Vero Beach-based Piper, said the company had just received the lawsuit and declined to comment.

“This is a pending lawsuit, we can’t respond,” Carlon adding it would be addressed the “normal litigation channels.”

The Piper in the deadly crash had been built in 2007 and also had more than 7,600 hours. It was used exclusively for flight training and had undergone its annual inspection on March 21, 2018, two weeks before the crash.

The Piper was being used in a demanding training environment in Florida which is known for rapid development of cumulus clouds that can create turbulence for planes, the lawsuit states, which makes inspections of the planes all the more important.

The Piper had endured “no less than seven separate ‘hard landing’ reports,” each requiring a Piper-specified inspection, the lawsuit states, and each time the plane was inspected.

But the types of inspections needed to detect the crack in the Piper’s wing spar were not done. Such tests were not required despite Piper knowing about the flaw, said Arthur Alan Wolk, of the Wolk Law Firm in Philadelphia which specializes in representing plaintiffs in aircraft crashes, in a phone interview. Wolk is the lead attorney in the case while Jeffrey Bigman is the local counsel.

He said Piper models PA-32, a single-engine type like the PA-28, and the PA-34, a twin-engine, also have similar problems.

Wolk said that the problem was identified in 1987 but Piper asked the FAA to withdraw an airworthiness directive requiring an inspection to detect the problem without fixing the flaw in the plane.

“Well, if nobody does the inspection then nobody finds the problem,” Wolk said. “If nobody finds the problem then somebody else is going to die.”

He added that there were several non-destructive tests that Piper could have required to catch the problem before a wing fell off and pilots and passengers got killed.

“For years prior to 1987, Piper knew that more than a hundred PA-28 aircraft had suffered in-flight structural failures resulting in the loss of life of hundreds of occupants,” according to the lawsuit.

Piper spokeswoman Carlon declined also to respond to the allegations that hundreds had died.

Wolk said that the NTSB and Piper about two weeks ago again inspected the wreckage of the Piper in the ERAU crash. He said he hopes that will lead to a new FAA directive to address the problem.

The FAA in December published in the federal registry a notice about a proposed air worthiness directive for inspections of the main wing spar on some Piper models “to address the unsafe condition on these products.”

The deadline for comments was last month and the FAA is reviewing them to determine the next step, wrote FAA spokeswoman Kathleen Bergen. The inspections would be based on service hours and cover PA-28 and PA-32 aircraft.

The lawsuit accuses Piper of negligence, fraudulent misrepresentation, fraudulent concealment, negligent failure to warn and other violations. The company lobbied the FAA to withdraw the directive for expensive inspections of the plane, the lawsuit states.

By doing so, Piper ignored continuing in-flight failures and “it decided unilaterally that some people would have to die if the inspections were not made especially in high time aircraft operated in harsh environments,” the lawsuit states.

Piper was aware of the crash in 1987 in which the wing fell of a plane doing pipeline patrol, killing the pilot, the lawsuit states. That crash was caused by a crack emanating from a bolt in the wing attachment fitting in a plane with about 7,500 flight hours, the lawsuit stated.

The FAA then issued an air worthiness directive for the planes based on conditions which could likely result in structural failure and death.

Inspections were conducted on 500 Piper aircraft and the cracks were found on two additional planes. Afterward, Piper lobbied the FAA to withdraw its directive which the FAA did, the lawsuit states. Piper also withdrew its own service bulletin.

The lawsuit accuses Piper of knowing pilots were being killed due to problems with the plane.

The lawsuit said the fatigue crack in the crash of the ERAU PA-28, also known as Piper Arrows, emanated from the same bolt and location as in the 1987 crash.

The lawsuit accuses Piper of “hiding the truth behind wing failures in the PA-28 aircraft” from pilots, owners and operators by requiring confidentiality in litigation. It also accuses the company of violating the public trust by being dishonest about the structural integrity of its aircraft.

Had the appropriate effective inspections been recommended by Piper and followed the crack would have been located and he wing repaired and replaced, the lawsuit states.

ERAU spokeswoman Ginger Pinholster said the college no longer flies the Pipers.

The Pipers were used because they were considered “complex” type aircraft to train on retractable landing gear. But three weeks after the crash, the FAA said pilots need not need to fly a complex type plane for their initial commercial pilot’s license.

“Last year, the FAA changed its pilot certification standards, which had previously required flight students to work with two particular classes of aircraft. The FAA rule change to the commercial pilot airman certification standards allowed us to remove the “complex” type of aircraft from our curriculum and streamline our overall fleet,” she wrote.

The FAA notice dated April 24, 2018, does not refer to the crash but it states that requiring a complex type aircraft, a class that includes retractable landing gears and other features, had become cost prohibitive for flight schools.

ERAU has 82 aircraft at its campuses in Daytona Beach and Arizona with 66 of those planes being Cessnas. The other planes are Diamonds and American Champion Decathlons. ​WASHINGTON (May 15, 2018) — The National Transportation Safety Board issued Tuesday an investigative update on its investigation of the April 4, 2018, crash of a Piper PA-28R-201 near Daytona Beach, Florida.

Two people suffered fatal injuries following an in-flight separation of the airplane’s left wing shortly after takeoff. The airplane subsequently collided with terrain and was destroyed. The airplane was registered to and operated by Embry-Riddle Aeronautical University as an instructional flight under the provisions of Title 14, Code of Federal Regulations, Part 91.

The preliminary report for this accident was published April 16. Parties to this investigation include the FAA, Piper Aircraft and Embry-Riddle Aeronautical University.

Initial examination of the left wing main spar at the NTSB Materials Laboratory revealed more than 80 percent of the lower spar cap and portions of the forward and aft spar web doublers exhibited fracture features consistent with metal fatigue. The fatigue features originated at or near the outboard forward wing spar attachment bolt hole.

None of the surfaces exhibited visible evidence of corrosion or other preexisting damage. The right wing also exhibited fatigue cracks in the lower spar cap at the same hole location extending up to 0.047-inch deep. The remainder of the lower spar cap, spar web doublers, and upper spar cap displayed fracture features consistent with overstress.

The structures group of the NTSB’s investigation conducted an inspection of another Piper PA-28R-201 April 18 and 19. The plane inspected had a similar number of total airframe hours and cycles and was used exclusively for flight training of students. That inspection revealed a crack indication at the left lower outboard forward wing spar attachment bolt hole. The crack measured about 0.040-inch long and deep. The airplane’s wings were subsequently reinstalled and examined using new inspection procedures developed by Piper Aircraft. A bolt-hole eddy current inspection probe was used to confirm the location and size of the previously identified crack.

Nine additional PA-28R-201 airplanes have been inspected using ECI techniques under NTSB supervision. No crack indications were detected in these nine inspections.

The NTSB investigative team is examining corrective actions taken in response to the March 30, 1987, Piper PA-28-181 in-flight wing separation which resulted in three recommendations to the FAA and a subsequent Airworthiness Directive, which has since been rescinded.

The NTSB’s investigation of this crash is ongoing and as such, no conclusions about probable cause should be drawn from this investigative update or the preliminary report. Additional information will be provided as warranted.

The complete investigative update is available at https://www.ntsb.gov

https://www.ntsb.gov

The National Transportation Safety Board traveled to the scene of this accident.

Additional Participating Entities:
Federal Aviation Administration / Flight Standards District Office; Orlando, Florida
Federal Aviation Administration Accident Investigation and Prevention; Fort Worth, Texas
Piper Aircraft; Vero Beach, Florida
Embry-Riddle Aeronautical University; Daytona, Florida

Aviation Accident Preliminary Report - National Transportation Safety Board:  https://app.ntsb.gov/pdf

http://registry.faa.gov/N106ER

Aviation Accident Preliminary Report - National Transportation Safety Board

Location: Daytona Beach, FL
Accident Number: ERA18FA120
Date & Time: 04/04/2018, 0953 EDT
Registration: N106ER
Aircraft: PIPER PA28R
Injuries: 2 Fatal
Flight Conducted Under:  Part 91: General Aviation - Instructional

On April 4, 2018, at 0953 eastern daylight time, a Piper PA-28R-201, N106ER, collided with terrain following an in-flight breakup shortly after takeoff from Daytona Beach International Airport (DAB), Daytona Beach, Florida. The airline transport pilot and private pilot were fatally injured, and the airplane was destroyed. The airplane was registered to and operated by Embry-Riddle Aeronautical University and operated under the provisions of 14 Code of Federal Regulations Part 91 as an instructional flight. Day visual meteorological conditions prevailed at the time of the accident, and no flight plan was filed for the local flight, which departed DAB at 0927.

According to the operator, the private pilot was conducting his commercial pilot single-engine land practical test, and the airline transport pilot was acting as a designated pilot examiner (DPE).

Preliminary radar and voice communication data provided by the Federal Aviation Administration (FAA) revealed that the airplane flew to the southeast after departure; after maneuvering, it returned to DAB. The airplane entered the airport traffic pattern and performed a touch-and-go landing. While climbing out after the takeoff from runway 25L, air traffic control issued the pilot a discrete transponder code, and shortly after, the pilot asked if they could make a left turn to the crosswind leg of the traffic pattern. The controller responded by telling the pilot to continue upwind. Radar data indicated that the airplane climbed to 900 ft mean sea level at a groundspeed of 80 knots on a heading of 240° before radar contact was lost.

According to multiple witnesses, all located within 2,500 ft of the accident site, they saw the airplane flying normally, then watched as the left wing separated from fuselage. The fuselage impacted a field, while the wing descended separately and landed in an adjacent field.

According to FAA records, the pilot, age 25, held a private pilot certificate with ratings for airplane single-engine land and instrument airplane. His most recent FAA second-class medical certificate was issued on June 17, 2016. He reported 201 hours of flight experience as of his most recent logbook entry on March 19, 2018.

According to FAA records, the DPE, age 61, held an airline transport pilot certificate with ratings for airplane single- and multiengine land. In addition, he held a flight instructor certificate with ratings for airplane single- and multiengine and instrument airplane. His most recent FAA second-class medical certificate was issued on April 5, 2017. At that time, he reported 27,600 total hours of flight experience.

According to FAA airworthiness and operator records, the airplane was manufactured on September 17, 2007 and was issued a standard airworthiness certificate in the normal category. It was a single-engine, low-wing, four-place airplane with a 200-horsepower, Lycoming IO-360-C1C6 four-cylinder engine and a McCauley two-blade, constant-speed propeller. The airframe had accumulated 7,690.6 hours of operation at the time of the accident, and 28.3 hours since its most recent annual inspection, which was completed on March 21, 2018.

A surface observation weather report taken at DAB at 0953 indicated the wind was from 260° at 7 knots, the visibility was 10 statute miles, and few clouds at 25,000 ft. The temperature and dew point were 24°C and 19°C, respectively, and the altimeter setting was 30.03 inches of mercury.

The debris path was about 450 ft long, and the debris path began about 2 statute miles southwest of the departure end of runway 25L. The first items along the debris path included a rubber wing root seal and small pieces of window plexiglass, followed shortly thereafter by the left wing. The main wreckage impacted the adjacent field about 200 ft from the wing on a magnetic heading about 230°.

The forward portion of the fuselage, including the engine, exhibited significant impact-related damage. There was a strong odor of fuel at the site, and a large area of grass surrounding the wreckage was discolored. The right wing remained attached to the fuselage. An impression of the right wing leading edge was observed in the ground, and the right wing leading edge surface was crushed aft to the wing spar along the entire span of the wing. The flap and aileron of the right wing remained attached. The right landing gear was in the down and locked position.

The vertical stabilizer, rudder, horizontal stabilator, and trim tab control surfaces remained attached. Rudder control continuity was confirmed from the rudder to the rudder pedals. Elevator control cable continuity was established through cuts made to facilitate the wreckage recovery from the control column to the elevator control surface. Aileron control continuity was confirmed from the right aileron to the control column. Continuity of left aileron control cables was traced from the control column through fracture features consistent with tensile overload separation to the aileron.

The left wing separated from the fuselage near the wing root and exhibited mid-span buckling of the surface skin. The left wing flap remained connected and moved freely with no resistance. The left main landing gear was in the down and locked position. The left wing fuel tank remained intact and contained about 15 gallons of fuel.

The fractured left wing main spar portions, along with the box assembly and attached inboard end of the right wing main spar, were forwarded to the NTSB Materials Laboratory for detailed examination. Preliminary examination of the left wing main spar revealed that more than 80% of the lower spar cap and portions of the forward and aft spar web doublers exhibited fracture features consistent with metal fatigue (see figure 1).


Figure 1 - Left wing main spar lower cap fracture surface.

The remainder of the lower spar cap, spar web doublers, and upper spar cap displayed fracture features consistent with overstress fracture. The fatigue features originated at or near the outboard forward wing spar attachment bolt hole (see figure 2). None of the surfaces exhibited visible evidence of corrosion or other preexisting damage. The right wing also exhibited fatigue cracks in the lower spar cap at the same hole location extending up to 0.047-inch deep.



Figure 2 – Exploded view of left wing spar assembly and attachment bolts.

The wreckage was retained for further examination.

Aircraft and Owner/Operator Information

Aircraft Manufacturer: PIPER
Registration: N106ER
Model/Series: PA28R 201
Aircraft Category: Airplane
Amateur Built: No
Operator: Embry-Riddle Aeronautical University
Operating Certificate(s) Held: Pilot School (141)

Meteorological Information and Flight Plan

Conditions at Accident Site: Visual Conditions
Condition of Light: Day
Observation Facility, Elevation: DAB, 34 ft msl
Observation Time: 0953 EDT
Distance from Accident Site: 0 Nautical Miles
Temperature/Dew Point: 24°C / 19°C
Lowest Cloud Condition: Few / 25000 ft agl
Wind Speed/Gusts, Direction: 7 knots, 260°
Lowest Ceiling: None
Visibility: 10 Miles
Altimeter Setting: 30.03 inches Hg
Type of Flight Plan Filed: None
Departure Point: Daytona Beach, FL (DAB)
Destination: Daytona Beach, FL (DAB)

Wreckage and Impact Information

Crew Injuries: 2 Fatal
Aircraft Damage: Destroyed
Passenger Injuries: N/A
Aircraft Fire: None
Ground Injuries: N/A
Aircraft Explosion: None
Total Injuries: 2 Fatal
Latitude, Longitude: 29.158611, -81.085000

Zachary Michael Capra

John's Obituary

John S. Azma, age 61, passed away in Daytona Beach, Florida on Wednesday, April 4th, 2018. John was a devoted husband, father, and brother. Professionally, John was an FAA Designated Pilot Examiner and the founder of Azma FLT Inc., an Orlando-based flight school providing training in jet aircraft around the world. As an FAA Designated Pilot Examiner for over twenty years, John was known and respected throughout the aviation community.

John was a highly decorated pilot; his experience included flying the F-4 Phantom. John conducted thousands of FAA Practical Tests for many flight schools in the central Florida area, and was known for his calm, professional demeanor.

John was one of the most accomplished Pilot Examiners in the country, qualified to conduct FAA Practical Tests in over forty different jet aircraft. As the founder of Azma FLT Inc., John had a strong desire to share his wealth of knowledge and experience with his clients both during and after their training. John was an invaluable resource and made it a point to offer his assistance to anyone, at any time. He was just a phone call away, day or night.

John frequently made use of both humorous and serious sayings. One serious saying he often used was, "We don't take shortcuts". It was John's policy in his personal, as well as his professional life, to do what was best for others and never cut corners. He would spare no effort or expense to live up to that standard. John's legacy continues through his wife, Isabelle, and his sons.

A memorial service is scheduled for noon, Saturday, April 21st at St. Margaret Mary Catholic Church, 526 North Park Avenue, Winter Park, FL 32789. A Celebration of Life is scheduled from 1:30pm to 5:00pm, Saturday, April 21st at Sheltair Hangar 15, 2948 East Livingston Street, Orlando, FL 32803.

Zachary Michael Capra, 25, of Thornton, Colorado, passed away April 4, 2018, in Daytona Beach, Florida.

Zachary was born February 22, 1993 and raised in Thornton, Colorado. He had a passion for sports growing up, playing golf, lacrosse and hockey. Zachary's love of travel began with hockey tournaments both in and out of the United States. Zachary graduated from Mountain Range High School in Westminster, Colorado in 2011. Zachary enjoyed flying, traveling and hiking.

He enlisted in the United States Navy in July 2012 and served thru 2016 as an Aviation Boatswain's Mate aboard the USS Harry S. Truman and was deployed twice to the Persian Gulf. Zachary enjoyed the traveling the Navy afforded him, which ultimately led him to his next adventure in August 2016, when he started college at Embry Riddle Aeronautical University in Daytona Beach, Florida. Zachary was awarded a posthumous degree of Bachelor of Science in Aeronautics from Embry Riddle Aeronautical University. Zachary passed away doing what he loved.

Zachary is survived by his father, John (Patsy) Capra; mother, Janet Swink; siblings, Jennifer (Aaron) Bloom, Caylen (Jenessa) Hunter, Brenna Hunter, and Candice Martinez; nieces and nephews, Gabriella Martinez, Kayden Martinez, and Eila Bloom; grandparents and a number of cousins, uncles, and aunt. Zachary is preceded in death by his grandparents, MaryAnn and Michael Capra.

A Prayer Service honoring Zachary will be Tuesday, April 17, 2018, beginning at 11:00 AM, at Immaculate Heart of Mary Catholic Church, 11385 Grant Drive, in Northglenn, Colorado 80233. Committal Services with Military Honors will be Wednesday, April 18, 2018, 11:30 AM, at Fort Logan National Cemetery, gathering at Staging Area "B", 3698 South Sheridan Boulevard, Denver, Colorado 80235.

In lieu of flowers, memorial contributions may be made to:

Embry Riddle Honor a Fallen Eagle - Zachary M. Capra Memorial Scholarship Fund in Zachary's name at http://givingto.erau.edu/

ON APRIL 21, 2018 IT WOULD BE MY HONOR TO HAVE YOU JOIN US TO REMEMBER AND CELEBRATE THE LIFE OF

JOHN S. AZMA

MEMORIAL SERVICE
12:00PM
St. Margaret Mary Catholic Church
526 North Park Avenue
Winter Park, FL 32789

Following the service we will be gathering to share our favorite memories and stories over food and drinks.

CELEBRATION OF LIFE
1:30PM – 5:00PM
Sheltair Hangar 15
2948 East Livingston Street
Orlando, FL 32803

DAYTONA BEACH — Zach Capra was doing what so many people never do. He was living his dream.

Capra’s Facebook page is painted with photos from all over the world. There are shots of him standing on majestic mountaintops, and others of breathtaking sunsets in far away places. He had been to the Persian Gulf, Dubai, Croatia, Monaco, Spain and Hawaii.

After four years in the Navy, and two years at Embry-Riddle Aeronautical University, the 25-year-old was on course to become a commercial airline pilot. He was set to graduate May 7, and then if all went well it was off to Atlanta or Alaska to begin a career of floating above the clouds.

It all ended in a mangled pile of wreckage Wednesday morning, when the small plane Capra and an instructor were flying in Daytona Beach suddenly catapulted into the ground.

“This was his last flight to get his license,” his stunned father, John Capra, said in a phone interview Thursday from his Colorado home. “That was his dream and his passion. He wanted to travel the world. He was just starting his adventure.”

Capra and a Federal Aviation Administration pilot examiner were practicing routine take-offs and landings when one of the aircraft’s wings fell off, causing the catastrophic crash that killed them, a federal investigator said Thursday. That teacher was John S. Azma, an experienced pilot examiner and father of four sons. Azma was the founder of AZMA Flt Inc. of Orlando.

Azma’s wife, Isabelle, posted on Facebook Thursday afternoon that “few details are known at this time. As information becomes available, we will inform you.”

The plane — a Piper PA-28 aircraft, better known as an Arrow — crashed sometime around 9:45 a.m. Wednesday in a cow field along Tomoka Farms Road near the Daytona Flea & Farmers Market. Witnesses said they saw the wing detach before the crash.

Aaron McCarter, an air safety investigator with the National Transportation Safety Board, said the Piper Arrow is a commonly used aircraft.

“There is no reason to think there are any holistic problems” with the plane, McCarter said during a news conference Thursday morning about a quarter-mile from the crash site.

McCarter also said that a wing detaching from a plane in mid-air is “very uncommon.” He emphasized the maintenance records for that particular plane will be reviewed.

The pair was working on “touch-and-go maneuvers,” which basically means the student was practicing how to take off and land the aircraft, McCarter said. The wing fell off the plane during the “cruise climb” following take off, he added.

The wreckage was still on the scene Thursday morning, but McCarter said he anticipated removing it later in the day and taking it to an indoor facility in Jacksonville where a “closer examination” could be conducted.

A preliminary report is expected to be finished within 10 days. A full report takes about 18 months to complete, McCarter said.

Flight operations at Embry-Riddle resumed Thursday for all of the school’s planes except the Piper Arrow, the model involved in Wednesday’s crash, said Ginger Pinholster, assistant vice president for news and research communications. Those planes will remain tied down until full inspections can be conducted, which will probably take at least a week.

Embry-Riddle President P. Barry Butler confirmed the identities of the two people who lost their lives in the crash in an email sent across the campus about 3 p.m. Thursday, saying he was “deeply saddened” to share the news of the “tragic aircraft accident.”

Butler wrote that Capra had planned to graduate with a bachelor’s degree in aeronautics. He was a member of Embry-Riddle’s Student Veterans Organization, having transferred to the university following his service in the Navy from 2012 to 2016. Capra had been an aviation boatswain’s mate on the USS Harry S. Truman.

Capra graduated from Mountain Range High School in Westminster, Colo., and he attended Adam State University in 2011. Butler said Capra was an aspiring pilot who was described by a friend as “someone who smiled often and never hesitated to provide encouragement to others.”

Butler said in his written statement that Azma “was well known and respected by many in the Embry-Riddle community. He was a highly decorated FAA-designated pilot examiner as well as a pilot proficiency examiner and a flight instructor. John had at least 20 years of flight experience and nearly a dozen unique jet aircraft-type ratings. His proficiencies encompassed many aircraft, from single-engine piston aircraft to multi-engine turbine powered jets. He was known for his calm professionalism in the cockpit.”

Butler said the NTSB is conducting an in-depth investigation, and the school is working closely with authorities “to support their efforts in any way we can.”

“We will provide additional information on an ongoing basis, as soon as we possibly can,” Butler said. “We have all been shocked and devastated by this tragedy.”

He said campus members in need of support are encouraged to contact the Counseling Center or the chaplain’s office.

John Capra said there will be a memorial service on campus at noon Monday. He’ll be there along with his, wife, Patsy. She was Zach Capra’s stepmother, and had been in his life since he was 8 years old. His birthmother is Janet Swink of Colorado. He had one brother and three sisters.

John and Patsy Capra will fly to Daytona Beach on Friday to bring home their son’s remains. They had already purchased other plane tickets to come for the graduation ceremony next month, and they were trying to decide on a gift. John Capra said it doesn’t fully seem real.

“Being so far away, there’s not the finality of it yet,” he said.

The 54-year-old father said his nightmare began Wednesday morning when he was at work and happened to look at ERAU’s website. He saw a post about the crash, so he texted his son. He waited for a reply, and he waited some more.

When he heard nothing back, he contacted the school. About 30 minutes later, a chaplain called back. It’s been a surreal blur since.

He’s thinking back to the quiet little boy who always had a smile and a hunger for adventure. The talented athlete who loved hockey and lacrosse. The teenager who spent his life in Denver, enlisted in the Navy, and trained in Chicago and Pensacola.

John Capra said his son “cared about other people more than himself.”

“He inspired and he pushed people to do what he did, achieve his dreams,” he said.

A memorial to Zach posted on John Capra’s Facebook page holds some words of encouragement: “Follow your hopes and dreams. Don’t let anyone keep you from doing what you have been determined to accomplish. There might be difficult times when you could think about giving up, but just keep pushing and reach your set goals.”

Original article ➤ http://www.news-journalonline.com





DAYTONA BEACH — Federal investigators are working to determine what caused a small plane’s wing to fall off mid-air, resulting in a crash that killed an Embry-Riddle Aeronautical University student and his instructor, a Federal Aviation Administration pilot examiner.

Witnesses, which included air traffic controllers, said that following takeoff the plane’s wing “departed the aircraft,” causing it to spin out of control and then slam into a cow field about a half mile from Daytona Beach International Airport on Wednesday morning, said Aaron McCarter, an air safety investigator with the National Transportation Safety Board.

“With the wing departure, we are focusing our efforts initially on that part right now,” he said during a news conference Thursday.

“We are looking at the engineering, and any kind of maintenance records.”

Maintenance records for the plane — a Piper PA-28R-201 aircraft, better known as an Arrow — have already been provided by the school, he said. The student and instructor, he said, were working on “touch-and-go maneuvers,” which basically means the student was practicing how to take off and land the aircraft. The wing fell off the plane during the “cruise climb” following takeoff, he added.

Determining what caused the plane’s wing to fall off will take an investigation lasting between 18 months to two years, which is the typical length of time it takes for the NTSB to reach a conclusion about what caused a plane to crash.

The investigation into the crash will include metallurgists examining the plane’s wreckage, McCarter said. He said that a wing detaching from a plane in mid-air is “very uncommon” and that “there is no reason to think there are any holistic problems” with the plane. A search of NTSB records examining crashes involving Piper planes found no mentions of a wing detaching.

A 2015 FAA bulletin, however, warned that the plane’s model has the “potential for corrosion on the wing rear spar at the fuselage attach fitting.” There were also two separate bulletins in 2011 that said there is the the potential for corrosion “on the wing front spar at the fuselage attach fitting” and “on the “aileron hinge fitting.”

All three bulletins say variables increasing the potential for corrosion include age, incompatible materials, and certain environmental conditions, such as “high moisture or salt water.”

The FAA makes clear on its website that Special Airworthiness Information Bulletins are “an information tool that alerts, educates and makes recommendations to the aviation community” and that they do not require mandatory actions. The 2015 bulletin recommends that all Piper PA-28 models and others receive inspections and take certain steps if damage is found.

Jacqueline Carlon, senior director of marketing and communications at Piper Aircraft, said that the company is working with the NTSB in its investigation but can not comment on the accident. Flight operations at Embry-Riddle resumed Thursday for all of the school’s planes except the Piper Arrow, the model involved in Wednesday’s crash, said Ginger Pinholster, assistant vice president for news and research communications. Those planes will remain tied down until full inspections can be conducted, which will probably take at least a week.

Two YouTube videos published last month show Roy Williams of Airframe Components in Indiana going over how to inspect a Piper plane’s main wing spar and aft wing attach fittings for corrosion. Both inspections require a hole be cut in the plane’s wing to allow for the insertion of a camera scope to see the wing’s interior.

In the video for the aft fittings, he shows corrosion on the rear spar at the attach plate.

“This is an extreme case, with so much corrosion that we actually have deformation of the rear spar and also metal missing,” he says in the video.

He goes on to explain how the “most dangerous situation” is when corrosion is hidden between the outside steel plate and the aluminum spar.

“Where the problem lies is the mating surface,” he says. Williams could not be reached Thursday.

Brian Willis, director of aviation safety with the University of North Dakota John D. Odegard School of Aerospace Sciences, said that Piper planes are commonly used in flight training. He said that the aviation program there has more than 30 of them and that the single-engine planes with retractable landing gear are used in training pilots of varied experience, from those seeking their private pilot license to those looking for commercial training.

He said maintenance standards are strictly regulated by the government and that routine annual inspections would have examined for corrosion.

“We look at our planes all the time,” he said. “We pride ourselves on maintenance, and I know Embry Riddle would do the same on what they are putting out.”

News of the deadly crash had already filtered through much of the tight-knit community involved in aviation training, Willis said.

“We have been in contact with Piper and been in touch with Riddle,” he said. “We understand what they are going through, and any way we can be of assistance we are willing to do it.”

Original article ➤ http://www.news-journalonline.com



DAYTONA BEACH, Fla. - The National Transportation Safety Board Federal continued its investigation Thursday into an airplane crash in Daytona Beach that killed an Embry-Riddle Aeronautical University student, identified as Zach Capra, a 2011 Mountain Range High School graduate and U.S. Navy veteran, and a Federal Aviation Administration examiner, officials said.

The plane owned by Embry-Riddle crashed Wednesday on Tomoka Farms Road near the Daytona Flea and Farmers Market in Volusia County.

Officials said the plane was accomplishing a touch-and-go landing at the time of the crash.

“There are thousands of this airplane out there. Today, we are looking at this airplane and this airplane alone and their maintenance practices,” said an NTSB official.

The NTSB said the wreckage from the Piper PA-28 will be taken to a controlled environment in Jacksonville, where it will be examined further.

No distress call was made from the people aboard the Piper PA-28 plane, Volusia County Sheriff Mike Chitwood said.

"The wing flew off, and all of a sudden, we thought it was going to hit us, and then all of a sudden, it just fell, and the airplane went straight down," said an eyewitness who chose to remain anonymous.

Chitwood said it appears the plane broke apart in midair because the tail of the plane was found 100-200 feet from the wreckage.

"It could have been a lot worse. Fortunately for us, the plane crashed in a field. All you see behind us is cows, but a quarter of a mile to the north, and you are in the flea market and the campground," Chitwood said.

It's not clear where the plane was headed, but Chitwood said a preliminary investigation revealed it was on a training flight from Daytona Beach International Airport.

Embry-Riddle Aeronautical University officials are providing counseling to students and staff, and have grounded the planes for the time being.

Original article can be found here ➤ https://www.wftv.com


https://youtu.be/-D5vCoWKgII
Roy Williams of Airframe Components shows how to inspect the Piper Aircraft aft wing attach fittings, in Service Bulletin 1244B.

https://youtu.be/7WHNw289csE
Service bulletin 1006 talks about replacing fuel tanks in the Piper Aircraft wings. Airframe Components shows you how to check your wings to find out if you need this repair.




The Volusia-Flagler county area is among the busiest civilian flight training centers in the country, thanks to the temperate weather.

Training flights account for 60 to 80 percent of the local airport traffic, with more than a dozen local flight schools. Embry-Riddle Aeronautical University is the largest local flight training operation, with roughly 400 flights departing and arriving daily, according to the university’s website.

Of the 99 aircraft incidents reported in the two-county area since 2006, about a third involved instructional flights. That includes four fatal crashes.

It isn’t known whether any of the 32 instructional flight incidents involved aircraft or students from Embry-Riddle.

In total, two airports account for about half the crashes, with eight incidents involving instructional flights at Daytona Beach International Airport and eight at Ormond Beach Municipal Airport. No airport was listed in six of the incidents.

A Cessna aircraft was involved in more than half the incidents, 18 of the 32. A Piper aircraft was involved in six of the incidents.

Fatal Embry-Riddle Plane Crashes

Wednesday’s accident was the first fatal crash this century involving an Embry-Riddle plane. Between 1990 and 1999, 15 people died in crashes involving school plans and other aircraft. Here are details of those incidents.

December 1999: Four people were killed when an Embry-Riddle plane collided with a plane from Phoenix East Aviation near DeLand Municipal Airport. An instructor and student aboard the Embry-Riddle plane and an instructor and commercial pilot aboard the Phoenix East plane were killed. The NTSB faulted both pilots for not looking out enough for other planes.

July 1996: Embry-Riddle student died when his small plane crashed in a wooded area off State Road 44 and east of Hunting Camp Road during a practice flight. The student had rented Cessna 152 at a flight center.

March 1996: A midair collision involving an Embry-Riddle student and a Phoenix East Aviation plane killed six people when the planes slammed into each other and burst into flames off the coast of Flagler County. The Embry-Riddle student and three of his friends were in a single-engine plane while the Phoenix East plane carried an instructor and a pilot. The NTSB found that the pilots did not see each other in time to avoid the crash.

Original article ➤ http://www.news-journalonline.com



A Federal Aviation Administration pilot examiner and a student pilot were killed when an Embry-Riddle Aeronautical University plane crashed during a training flight Wednesday shortly after takeoff from Daytona Beach International Airport, officials said.

The plane crashed about 25 yards west of Tomoka Farms Road, near the Daytona Flea & Farmers Market. Emergency calls came in at 9:54 a.m. with witnesses saying they saw a wing fall off a plane before it crashed. The wing was across Tomoka Farms, to the east and 150-200 yards from the rest of the mangled fuselage.

The identity of the student and the examiner were not being released pending confirmation of their identifications, officials said. The victims’ families had been notified.

“We are devastated by today’s tragic aircraft accident that has taken the lives of one of our students as well as another member of the aviation family, an FAA-designated pilot examiner,” ERAU spokesperson Ginger Pinholster said in an email statement. “We are devoting every ounce of our energy to learning the details of what happened, and we are working closely with authorities to do so. ... Our entire community is heart-broken. Our deepest sympathies go out to all those affected by this devastating loss.”

National Transportation Safety Board investigator Dan Boggs said at the scene that a press briefing will be at 9 a.m. Thursday near the crash scene.

Boggs said the Piper Arrow airplane is well built and he hadn’t heard of another losing a wing in flight.

Two 9-1-1 callers said they saw a wing or a piece of the plane come off the aircraft before it crashed across from the flea market.

A dispatcher asked one caller whether the plane had crashed or landed. The man said the wing had fallen on the other side of the road.

“Unfortunately it crashed very badly,” the caller said. “It looked like the wing, it looked like the wing just pulled off and then the fuselage kept on going past the road. And it crashed. I mean it’s crashed. I hope the people survived. I don’t know.”

Another caller said he was on his way to his jobsite when he saw the crash.

“I saw a piece become detached and the plane crashed in a field,” he said.

The dispatcher asked if he saw anyone get out of the plane.

“No I’m there right now,” the caller said. “But I don’t see how anybody survived this.”

Embry-Riddle students were gathering at the scene late Wednesday morning.

“My information is that it was a training flight that took off from Daytona Beach,” Volusia County Sheriff Mike Chitwood said. No distress call was received before the plane went down.

The FAA said in an email that it was investigating the crash of the plane it identified as a Piper PA-28. The Piper PA-28 is a small single-engine aircraft with low-mounted wings.

Embry-Riddle reports 400 training flights departing and arriving daily at Daytona Beach International Airport. The school’s website reports the students fly four kinds of aircraft: Cessna 172 Skyhawk, Piper Arrow, Diamond DA42 L-360 and one ACA Super Decathlon.

Given the amount of ERAU planes are airborne, the university’s accident rate was comparatively low, Pinholster said.

“We have had 10 minor accidents in our last 1.25 million hours. Those 10 accidents were hard landings and bird strikes with no injuries,” she said. “The industry average is 5 accidents for every 100,000 hours flown. Our record is more than 5x better than the industry average.”

This is the first fatal crash involving an ERAU in nearly two decades.

From 1990 to 1999 there were 15 people killed in crashes involving Embry-Riddle planes, FAA records show. Those include ERAU students and those killed in other aircraft, including six deaths in a 1996 mid-air collision. In one of those incidents, in 1998, a student stole an ERAU airplane and purposely crashed it in an act of suicide. Another ERAU student died in a crash involving a private plane in 1996.

Original article ➤  http://www.news-journalonline.com




DAYTONA BEACH, Fla. - An Embry-Riddle Aeronautical University student pilot and an instructor were killed Wednesday after a small plane crashed near the Daytona Beach Flea and Farmers Market, officials with the Volusia County Sheriff's Office said.

The plane crashed at 9:54 a.m. near 1496 Tomoka Farms Road, deputies said. Witnesses said the plane lost a wing before crashing south of West International Speedway Boulevard.

"The wing fell off some 150 to 200 yards away from where the plane finally rests in this field behind us," said Volusia County Sheriff Mike Chitwood standing in front of the wreckage.

Embry-Riddle Aeronautical University officials said the two on board were a student pilot and a passenger.

"It is with profound sadness that I must inform you of an aircraft accident today that resulted in the loss of one of our student pilots as well as a passenger who was a designated pilot examiner with the U.S. Federal Aviation Administration," university president Dr. P. Barry Butler said in a statement.

The two people were the only ones on board the Piper PA-28 Cherokee aircraft. They have not been identified.

National Transportation Safety Board and the Federal Aviation Administration officials are en route to investigate the crash. Embry-Riddle officials said they are cooperating with authorities.

"The witnesses that we're interviewing say this happened very quickly," Chitwood said. "No distress call was sent out as we can tell right now."

Original article can be found here ➤  https://www.clickorlando.com
















VOLUSIA COUNTY, Fla. - Two people have died in a plane crash in Volusia County, deputies said.

The crash happened at 9:54 a.m. Wednesday at 1496 Tomoka Farms Road, near the Daytona Flea and Farmers Market.

Volusia County Sheriff Mike Chitwood said no distress call was made from the people inside the plane.

The identities of neither the passengers nor the owner of the plane have been released.

Chitwood said it appears the plane broke apart mid-air because the wing of the plane was found 100 to 200 feet from the wreckage.

"It could have been a lot worse. Fortunately for us, the plane crashed in a field. All you see behind us is cows, but a quarter of a mile to the north, and you are in the flea market and the campground," Chitwood said.

It's not clear where the plane was headed, but Chitwood said preliminary investigation revealed it was on a training flight from Daytona Beach International Airport.

40 comments:

  1. I wonder if the plane struck a tree on takeoff which knocked the wing off and caused the crash. Otherwise, if the wing fell off on takeoff we should be grounding PA-28R's until the cause is found. I fly one of these and wouldn't want this to happen to me!

    ReplyDelete
    Replies
    1. There are no trees at Daytona Beach airport.

      Delete
    2. I have seen Piper Arrows in the maintenance hangar before with the wings separated from the fuselage for transportation on a truck. There are at least 15 to 20 bolts that hold the wings to the fuselage on each side. This airplane possibly suffered prior unreported wing damage in order for the wing to fall off like that.

      Delete
  2. You don’t need the FAA to ground you. That can be a personal choice. Ground yourself and this won’t happen to you.

    There will be something structurally terribly wrong with this wing and plane and/or a messed up reassembly after an inspection.

    ReplyDelete
  3. I used to flight instruct in these. Great airplanes. These flight school aircraft deal with a great deal of abuse. This person was on some sort of check ride requiring a complex aircraft so I’m assuming commercial or CFI. Some of those maneuvers are aggressive I.e. steep spiral, Chandelles or 8’s on pylons. Getting low, high. Or off in general could make a candidate react aggressively to recover the maneuver to pass the checkride. This in a aging aircraft could result in structural failure. I’m no expert and these are all of course ideas. The final report will state the truth. Maybe some AD’s or urgent maintenance bulletins will be the result. Sad stuff.

    ReplyDelete
  4. Departed left wing has a replacement aileron installed (unpainted) See last photo
    Likely not properly balanced, flutter developed and tore wing off.
    A real screw up for ERAU

    ReplyDelete
  5. I fly a 1971 PA-28R for instrument training and I thought there was an AD awhile back requiring inspection holes to be cut in the wing to check for corrosion of the wing spar. I'm wondering if since this plane lived in a highly corrosive environment of sea salt it suffered more severe corrosion? What a sad way to go. RIP fellow aviators.

    ReplyDelete
  6. I think the above comment hit it on the head. Look at the FlightAware track for this flight on 4-4-18 from takeoff from DAB (0927) to near landing at DAB (0952) and you can see some maneuvers with some wild changes in groundspeed and altitude. I'm wondering if they did an inadvertent spin and structurally damaged the airframe during recovery. The FAA registration shows the plane was a 2007 model so I would assume that corrosion wouldn't have been an issue yet. I wonder what the total time was on the airframe?

    ReplyDelete
  7. According to Flightaware records this aircraft was a 2007 model (not exactly ancient)and was a Danbury Conneticut airplane up until 2015 when Embry Riddle bought it per registration data. Wings just don't fly off as there are a lot of classic/legacy aircraft still soldiering on, it will be interesting to see what is found out.

    ReplyDelete
  8. >Look at the FlightAware track for this flight on 4-4-18 from takeoff from DAB (0927) to near landing at DAB (0952) and you can see some maneuvers with some wild changes in groundspeed and altitude.

    Given that one of the individuals on board was a designated pilot examiner, this was almost certainly a checkride, during which such maneuvers would be normal/expected.

    ReplyDelete
  9. Listening to the tower communication, they were doing a touch and go. Tower gave Squawk info and about 5 seconds later, directed a crosswind turn. Subsequently, when vehicular traffic spotted the aircraft, the aircraft was already in an unusual attitude (wings vertical) and low, less than 200-300' AGL when the witness stated "wing came off" and the remaining fuselage only traveling 450' hitting a pine tree and spinning to a stop. I was not there and not in the cockpit, but it would seem possible, more likely, that it may have been a stall 1st and then the air-frame stress possibly shearing the wing. Changing squawk code a distraction, with flaps adjustment for climb, maybe not full throttle (?) adding tower direction for a left crosswind turn and an examiner sitting next to you watching every move? Tremendous amount of stress on a new, young pilot. I can see how it could happen more easily than a "wing falling off" in controlled flight. If the wing came off unaffected by pilot input, at 1000' while turning crosswind, I would think there should have been much greater separation of the debris and less of a direct line impact.

    ReplyDelete
  10. >Anonymous said...
    Departed left wing has a replacement aileron installed (unpainted) See last photo
    Likely not properly balanced, flutter developed and tore wing off.
    A real screw up for ERAU<

    It is almost impossible to get a piper aileron to be out of balance limits, short of removing the weight, which there is no need to do, unless you are building a aileron out of parts. There are Arrows flying with tens of thousands of hours on the airframe, lets wait and see what the wreckage tells us.

    ReplyDelete
  11. Just to add a little more specific info. They were 2 miles, 10,000+ lf from the end of 25 L, When turning crosswind. Crash site is only 1,800 lf off of the centerline of 25 L. Should have been at TPA of 1,000 +/- that far from runway. It is a very sad loss of life, regardless of the reason.

    ReplyDelete
  12. Hopefully, NTSB investigator Boggs can school himself before making further stupid comments. ‘Boggs said the Piper Arrow airplane is well built and he hadn’t heard of another losing a wing in flight.’ In fact, there have been several.
    NO ONE knows the cause yet but investigation will no doubt take into account long history of spar corrosion ADs (and new one proposed just last fall - see discussion: https://www.pilotsofamerica.com/community/threads/new-piper-pa-28-ad.106837/ )
    My heart goes out to the victims and families.

    ReplyDelete
  13. https://youtu.be/-D5vCoWKgII

    https://youtu.be/7WHNw289csE


    ReplyDelete
  14. What is Mr. Boggs saying? They are looking at this airplane only? The ERAU fleet needs to be grounded immediately and last that I heard from an employee there, it has been. He also doesn't seem to know that there is a corrosion issue on these aircraft.

    ReplyDelete
  15. There are rumors circulating that the airplane experienced a “hard landing” the day before, it was reported and put into the shop for maintenance/inspection, and was released as “good to go” for the flight that crashed. I cannot confirm this, but it would certainly make a lot more sense than other possibilities as it could have cracked a spar and not been found.

    ReplyDelete
  16. I think the cause of this accident will end up coming from over-stressing the airframe while performing maneuvers OR the results of a very "hard" landing OR repeated combinations of both. Given the relative age of a 2007 model I wouldn't think corrosion would be an issue but I'm no expert. I trust the NTSB and the FAA will make the right recommendations to keep all of us Piper PA-28 pilots safe. Hopefully something positive can come from such a tragedy.

    ReplyDelete
  17. What a tragic loss. I don't want minimize the loss of the student, but John Azma was a personal friend, and a fantastic trainer/Examiner. I got my first Type rating in a Citation with him. He is the most knowledgable, calming, inspiring instructor I have ever come across in the many years I have been flying. There will be a huge loss in the aviation world without him.
    I hope Isabelle can find comfort in knowing how many people John touched in a positive way.
    Prayers to her and the family.

    RL

    ReplyDelete
  18. Hardly the speed range to induce flutter, let us not judge things we don’t yet know about. The Commercial flight test doesn’t induce great stress on the airframe. Chandelles and Lazy 8’s are coordination maneuvers, not high stress aerobatics. I administered one in a 12,000+ hour Arrow today, the wings remained in place. Wait for the facts and look after of those who suffered from the loss.

    ReplyDelete
  19. Please.....
    Just because you have a pilots license with a bunch of hours or a CFI, doesn't mean you know squat about Engineering, stress, design or aero. Most of these comments don't even make sense to those of us that do this everyday. (37 years)
    So, out of respect for our fallen aviators please, just pay your respects and try to take away some perspective that accidents happen and the NTSB will find the cause.
    I don't say any of this to be pompous or arrogant, but have been flying for 40 years, have thousands of hours and worked for a major aircraft manufacturer (for 37 years) and still don't consider myself "the expert".
    Oh, I'm also an A&P and CFII

    ReplyDelete

  20. I'll bet the NTSB already has pretty good idea what caused the structural failure based on metal signature. I'm guessing it was either stress overload or corrosion. I like to think ERAU routinely inspects their aircraft for corrosion being in a coastal area so I'm going with unreported hard landing on previous flight.

    ReplyDelete
  21. Missing bolts will do this.

    ReplyDelete
  22. O Gina , your such a goddess, looks like you’ve done it all, well done

    ReplyDelete
  23. I am an ERAU Alum (aero eng) and live in the area. One of the first responders on the scene is a friend, and also well versed in aircraft and aircraft construction. He saw the wing spar, and estimates it was half gone due to corrosion, with corroded cracks thru spar bolts. ERAU is going to end up looking incompetent(to say the least) on this.

    ReplyDelete
  24. Wow, this new information is huge. Since no corrosion was found but cracks from metal fatigue were, I'm wondering was this an "isolated incident". I would feel more comfortable piloting one of these Pipers (Warrior, Archer, Arrow) if the FAA would make it mandatory that inspection panels be installed in the wing so that the suspect area of the spar can be visually inspected during annuals or 100 hr inspections. That could help catch corrosion issues on the older planes or possibly metal fatigue on the newer "trainers". Short of removing the wings on every Piper plane of similar design to check for issues, this might be the best way to insure something this like won't happen again. I feel very sorry for the families of the two deceased pilots as they drew the unlucky straw that day. R.I.P. fellow aviators.

    ReplyDelete
  25. NTSB report now out information also above everyone should be interested in this information.

    ReplyDelete
  26. the preliminary report is out.. WITH PHOTOS!

    Preliminary examination of the left wing main spar revealed that more than 80% of the lower spar cap and portions of the forward and aft spar web doublers exhibited fracture features consistent with metal fatigue (see figure 1).

    the remainder of the lower spar cap, spar web doublers, and upper spar cap displayed fracture features consistent with overstress fracture. The fatigue features originated at or near the outboard forward wing spar attachment bolt hole (see figure 2). None of the surfaces exhibited visible evidence of corrosion or other preexisting damage. The right wing also exhibited fatigue cracks in the lower spar cap at the same hole location extending up to 0.047-inch deep.

    NTSB Report is here: https://app.ntsb.gov/pdfgenerator/ReportGeneratorFile.ashx?EventID=20180404X13226&AKey=1&RType=Prelim&IType=FA

    ReplyDelete

  27. "Overstress" such as repeated hard landings, air loads or a combination?

    ReplyDelete

  28. We have two of these, a 1977 PA-28R-201T and a 1968 PA-28R-180. It makes us concerned.

    As of Monday evening the "201T" hit the 100hr mark and is getting an extensive annual.

    So far our mechanics have not spotted any significant corrosion other than normal surface oxidatoin or indications of over-stress in the wing box or root cap. Metal, unlike composites will show indications of yield stress before fracture.

    We will pull the fuel tanks too later this week to expose more of the spar and re-verify the AD. They are using a bore-sight camera for the hard to see places.

    As in all aircraft wing internals these collect dirt and fine grit with time. We found a light accumulation of this and thus has been cleaned out. Dirt, when wet can form a pasty electrolyte between the aluminum skin and steel spar.

    The only other thing I can think of is folks should use mild pH soaps when cleaning aircraft surfaces. Caustic soaps like Purple Power (TM) have a high sodium hydroxide (lye) content and are great de-greasers but have no place being used for cleaning aircraft aluminium, and especially areas of dissimilar metals.

    The wing-to-fuselage seal must be good to minimize moisture intrusion. Water always gets in somehow, but a good seal should at least minimize the amount.


    ReplyDelete
  29. Interesting that less than 30 days after this accident, the FAA just yesterday removed the requirement to utilize a complex aircraft during the practical exams for the Comm ASEL and CFI Initial. This change should have been implemented years ago, when many in the aviation community warned the FAA that exactly this sort of thing might happen because of the age of the available airplanes. ER is an exceedingly busy flight training school. How many landings did this plane have between the time ER obtained it and this crash? I am guessing many thousands. All that repetitive concussion on that aluminum had to be very detrimental to the structural integrity of the metal and mounting hardware. So many FAA regulations are outdated and need revision. Its a shame it seems to always take deaths to facilitate the FAA into action. RIP pilots. So sad and yet so preventable.

    ReplyDelete
  30. There are 2 Service Bulletins for Piper Spars.

    1- SB1304 INSPECTION OF MAIN WING SPAR
    2- SB1244B INSPECTION OF AFT WING ATTACHMENT FITTINGS

    LIKELY ONE OR BOTH SB's WILL BECOME AN AD VISITED AT ANNUAL AND PERHAPS MANDATORY FOR 100 HR INSPECTIONS FOR AIRCRAFT FOR HIRE.

    EARLY PA-28s HAD HERSHEY BAR WINGS AND MAY NOT HAVE AN INSPECTION PLATE FOR SPAR TO AIRCRAFT ATTACHMENT AREA. TAPERED WING IN LATER MODELS MAY HAVE THIS PLATE.

    INSPECTION PLATE ACCESS KIT PIPER # 765-106 MAY ALSO BE REQUIRED.

    YOU TUBE VIDEO ON KATHRYN'S REPORT ON NTSB ERAFA120 PA-28 LOSS OF WING IN DAB.

    COMMENT. MANY HRS 7,000 + LOTS OF LANDING CYCLES, TRAINING AIRCRAFT INITIALLY AT DANBURY, CT. IF I REMEMBER CORRECTLY YOU HAVE TO AVOID MOUNTAINS, NOT SURE DOING SO IN A TRAINING ENVIRONMENT WOULD CAUSE STEEP DECENT AND CLIMBS PUTTING MORE LOAD
    ON THE AIRCRAFT. SLIGHT CRACK MENTIONED ON RIGHT WING MAKES THIS INCIDENT EVEN MORE INTERESTING.

    HOPE FOR VERY DETAILED ANALYSIS BY FAA, SO A POTENTIALLY UNIQUE OCCURRENCE IS NOT BLOWN OUT OF PROPORTION, BUT ALSO PROTECTS US FROM AN OCCURRENCE IN THE FUTURE.

    mz

    ReplyDelete
  31. An endurance limit of 69,000 hrs was claimed to be for the PA-28 Aircraft? The 2007 PA-28 Piper Arrow III with tapered wing has contains~72 gals. of usable fuel. The earlier Piper Arrow II s had ~48 gals. of usable fuel. The spar and attachment(s) are likely the same for both models. The Piper Arrow in the April 4, 2018 crash has approx. 7,690 hrs on it. To calculate stress vs. cycle the following needs to be done. Stress = An average stress, or to be conservative give a max. stress seen per each landing or “bounce” (a bounce needs to be included as a cycle). Cycles= # of landings and bounces/hour.

    For a training aircraft (worst case application due to it usage) likely near full fuel and the later model “tapered Wing” PA-28s will have more weight (stress) due to the 72 gals. useable.

    Question what is the worst case or 95% ile # of Cycles per/hr.? Close pattern touch and bounce goes for one whole hour with initially full fuel in both tanks. Say it is a short strip. 3,4,5,6, 7, 8 or more ?

    Example #___6___ bounces-landings/hr X # of hrs. __7,690_____ = 46,140 Cycles.

    * This example does not include any stress/partial or whole cycles due to turbulence or flight maneuvers.

    For the given stress you have given for each bounce and landing event, locate the number of cycles.
    If cycles are exceed for the given material’s stress per the stress vs. cycles curve. You have a problem.

    It is often the case that for a 1 hr training flight you do not switch tanks. So one wing sees full fuel (max. weight) for all these bounce and landing events. Contemplate alternating every hr of flight which tank you will first draw from first. (Hopefully not exceed the fuel selector cycle life). You are sharing the stress cycles.

    A personal aircraft not used as a trainer, will not see this level of cycles. So 100 hr inspection for hire for trainers is where the focus should be on and their annuals. Some personal aircraft have been trainers an awareness of its past usage needs to be contemplated.

    mz

    ReplyDelete
  32. An endurance limit of 69,000 hrs was claimed to be for the PA-28 Aircraft? The 2007 PA-28 Piper Arrow III with tapered wing has contains 72 gals. of usable fuel. The earlier Piper Arrow II s had 48 gals. of usable fuel. The spar and attachment(s) are likely the same for both models. The Piper Arrow in the April 4, 2018 crash has approx. 7,690 hrs on it. To calculate stress vs. cycle the following needs to be done. Stress = An average stress, or to be conservative give a max. stress seen per each landing or “bounce” (a bounce needs to be included as a cycle). Cycles= # of landings and bounces/hour.

    For a training aircraft (worst case application due to it usage) likely near full fuel and the later model “tapered Wing” PA-28s will have more weight (stress) due to the 72 gals. useable.

    Question what is the worst case or 95% ile # of Cycles per/hr.? Close pattern touch and bounce goes for one whole hour with initially full fuel in both tanks. Say it is a short strip. 3,4,5,6, 7, 8 or more ?

    Example #___6___ bounces/landings/hr X # of hrs. __7,690_____ = 46,140 Cycles.

    This example does not include any stress/partial or whole cycles due to turbulence or flight maneuvers.

    For the given stress you have given for each bounce and landing event, locate the number of cycles.
    If cycles are exceed for the given material’s stress per the stress vs. cycles curve. You have a problem.

    It is often the case that for a 1 hr training flight you do not switch tanks. So one wing sees full fuel (max. weight) for all these bounce and landing events. Contemplate alternating every hr of flight which tank you will first draw from first. (Hopefully not exceed the fuel selector cycle life).

    A personal aircraft not used as a trainer, will not see this level of cycles. So 100 hr inspection for hire for trainers is where the focus should be on and their annuals. Some personal aircraft have been trainers
    an awareness of its past usage needs to be contemplated.

    mz

    ReplyDelete
  33. I just watched a Youtube video of supposedly a 1977 Piper Arrow with the right wing coming loose at the wing root by pushing back and forth on the leading edge out at the wingtip! This was discovered during preflight and if it real this is extremely shocking. The video claims the aircraft is located in south Florida but no "N" is shown and not enough of the plane is shown to tell if it's an Arrow. It was posted on 4-20-18. Here is a link to view the video: https://youtu.be/GFYf42UE9gk

    ReplyDelete

  34. Previous post -

    "Interesting that less than 30 days after this accident, the FAA just yesterday removed the requirement to utilize a complex aircraft during the practical exams for the Comm ASEL and CFI Initial."

    A CFI mentioned to me this is because the FAA gave in to lobbying by Cirrus. It had nothing to do with crashes, etc.

    The Cirrus is high performance, but not complex with the fixed gear.

    Quite frankly if my CFI or Comm ASEL did not demonstrate in a complex aircraft I would think I was short-changed.

    Your choice.

    ReplyDelete

  35. I had a conversation with someone who knows a little history on the ER bird.

    The NTSB is on to it and they are not missing so much as a speck of dust.

    Wait for the report.

    I have taken to the habit of wiggling the Piper wings now rather vigorously. I have always done it (up and down movement) on the Cessnas, but the fore-aft movement on a Piper seems to be a reasonable check even with the wheel bearing a ground load (based on the well-appreciated video).

    Our 201T did not have any cracks or corrosion in spar cap in the annual this week. Other than some oily dust/dirt accumulation at the joint that is now cleaned up the 77' bird looks pretty good.


    ReplyDelete
  36. I hope to get the thoughts and recommendations from others here.My son is a student at ERAU in Daytona and we own a 1973 PA-28-235 which has 42 gallons of fuel in each wing. I am having all the related service bulletins completed. Wouldn’t it be a good idea to have eddy current NDT completed while I am having these service bulletins completed?

    ReplyDelete
  37. I would ask that on the Piper Forum. If you don't know the complete history of the airplane or have doubts whether everything was 'disclosed' in the "complete logs" and you can afford it, I would say yes. My understanding is it might be possible to remove one bolt at a time and use ultrasound or eddy current to check that one area, reinstall and move to the next one (18 per side). This would avoid wing removal per Piper SB886 and SB997. The big issue with wing removal is its involved, expensive and spar damage can occur if the bolts are forcibly removed or installed. If bolt can't be removed or reinstalled with finger pressure its not aligned and damage could occur that would turn into a crack.

    ReplyDelete
  38. That "wing wiggle" video is alarming! Since not all APs are up on their stuff, good to do your own very thorough pre-flight. I've got a BRS on my aircraft, but still, a wing falling off is a dramatic event in any situation. RIP these pilots and condolences to their family and friends.

    ReplyDelete
