Aviation Accident Final Report - National Transportation Safety Board
Additional Participating Entities:
Federal Aviation Administration / Flight Standards District Office; Indianapolis, Indiana
Cessna; Wichita, Kansas
Investigation Docket - National Transportation Safety Board:
Location: Marion, Indiana
Accident Number: CEN18FA132
Date & Time: April 2, 2018, 15:09 Local
Registration: N5614E
Aircraft: Cessna 150
Aircraft Damage: Destroyed
Defining Event: Ground collision
Injuries: 2 Fatal
Flight Conducted Under: Part 91: General aviation - Personal
Analysis
A single-engine airplane was taking off from runway 15 about the same time that a multi-engine business jet landed on a nearly perpendicular runway (runway 22). The single-engine airplane, piloted by a private pilot, was departing on a local flight. The jet, piloted by an airline transport pilot, was rolling down the runway following a straight-in visual approach and landing. The single-engine airplane collided with the empennage of the jet at the intersection of the two runways. Witnesses in the airport lounge area heard the pilot of the single-engine airplane announce on the airport's universal communications (UNICOM) traffic advisory frequency a few minutes before the accident that the airplane was back-taxiing on the runway. The pilot of the jet did not recall making any radio transmissions on the UNICOM frequency and review of the jet's cockpit voice recorder did not reveal any incoming or outgoing calls on the frequency. The pilots of both airplanes were familiar with the airport, and the airport was not tower controlled.
The airport had signage posted on all runways indicating that traffic using the nearly perpendicular runway could not be seen and instructed pilots to monitor the UNICOM. A visibility assessment confirmed reduced visibility of traffic operating from the nearly perpendicular runways. The reported weather conditions about the time of the accident included clear skies with 4 miles visibility due to haze. Both airplanes were painted white.
It is likely that the pilot of the jet would have been aware of the departing traffic if he was monitoring the UNICOM frequency. Although the jet was equipped with a traffic collision avoidance system (TCAS), he reported that the system did not depict any conflicting traffic during the approach to the airport. Although the visibility assessment showed reduced visibility from the departing and arrival runways, it could not be determined if or at what point during their respective landing and takeoff the pilot of each airplane may have been able to see the other airplane. In addition to the known reduced visibility of the intersecting runways, both airplanes were painted white and there was reported haze in the area, which could have affected the pilots' ability to see each other.
Probable Cause and Findings
The National Transportation Safety Board determines the probable cause(s) of this accident to be:
The failure of both pilots to see and avoid the other airplane as they converged on intersecting runways. Contributing to the accident was the jet pilot's not monitoring the airport's traffic advisory frequency, known reduced visibility of the intersecting runways, and hazy weather condition.
Findings
Personnel issues Lack of action - Pilot
Personnel issues Lack of action - Pilot of other aircraft
Environmental issues (general) - Contributed to outcome
Environmental issues (general) - Contributed to outcome
Personnel issues Lack of communication - Pilot of other aircraft
Factual Information
History of Flight
Takeoff Ground collision (Defining event)
Pilot Information
Certificate: Private
Age: 31, Male
Airplane Rating(s): Single-engine land
Seat Occupied: Left
Other Aircraft Rating(s): None
Restraint Used: Lap only
Instrument Rating(s): None
Second Pilot Present: No
Instructor Rating(s): None
Toxicology Performed: Yes
Medical Certification: Class 3 With waivers/limitations
Last FAA Medical Exam: May 3, 2017
Occupational Pilot: No
Last Flight Review or Equivalent: October 18, 2017
Flight Time: 71.9 hours (Total, all aircraft), 10.6 hours (Total, this make and model), 23.7 hours (Pilot In Command, all aircraft), 10.6 hours (Last 90 days, all aircraft), 8.6 hours (Last 30 days, all aircraft)
Aircraft and Owner/Operator Information
Aircraft Make: Cessna
Registration: N5614E
Model/Series: 150 UNDESIGNATED
Aircraft Category: Airplane
Year of Manufacture: 1958
Amateur Built: No
Airworthiness Certificate: Normal
Serial Number: 17114
Landing Gear Type: Tricycle
Seats: 2
Date/Type of Last Inspection: January 1, 2018 Annual
Certified Max Gross Wt.: 1499 lbs
Time Since Last Inspection:
Engines: 1 Reciprocating
Airframe Total Time: 4035 Hrs as of last inspection
Engine Manufacturer: CONT MOTOR
ELT: Installed, not activated
Engine Model/Series: O-200 SERIES
Registered Owner: Rated Power: 100 Horsepower
Operator: On file
Operating Certificate(s) Held: None
Meteorological Information and Flight Plan
Conditions at Accident Site: Visual (VMC)
Condition of Light: Day
Observation Facility, Elevation: MZZ,858 ft msl
Distance from Accident Site: 0 Nautical Miles
Observation Time: 16:55 Local
Direction from Accident Site: 0°
Lowest Cloud Condition: Clear
Visibility: 4 miles
Lowest Ceiling: None
Visibility (RVR):
Wind Speed/Gusts: 9 knots /
Turbulence Type Forecast/Actual: /
Wind Direction: 140°
Turbulence Severity Forecast/Actual: /
Altimeter Setting: 30.01 inches Hg
Temperature/Dew Point: 5°C / -1°C
Precipitation and Obscuration:
Departure Point: Marion, IN (MZZ)
Type of Flight Plan Filed: None
Destination: Marion, IN (MZZ)
Type of Clearance: None
Departure Time: 15:08 Local
Type of Airspace: Class G
Airport Information
Airport: Marion Municipal Airport MZZ
Runway Surface Type: Asphalt
Airport Elevation: 858 ft msl
Runway Surface Condition: Dry
Runway Used: 15
IFR Approach: None
Runway Length/Width: 3456 ft / 100 ft
VFR Approach/Landing: None
Wreckage and Impact Information
Crew Injuries: 1 Fatal
Aircraft Damage: Destroyed
Passenger Injuries: 1 Fatal
Aircraft Fire: On-ground
Ground Injuries: N/A
Aircraft Explosion: None
Total Injuries: 2 Fatal
Latitude, Longitude: 40.490833,-85.679725
Location: Marion, Indiana
Accident Number: CEN18FA132
Date & Time: April 2, 2018, 15:09 Local
Registration: N511AC
Aircraft: Cessna 525C
Aircraft Damage: Substantial
Defining Event: Ground collision
Injuries: 5 None
Flight Conducted Under: Part 91: General aviation
Analysis
A single-engine airplane was taking off from runway 15 about the same time that a multi-engine business jet landed on a nearly perpendicular runway (runway 22). The single-engine airplane, piloted by a private pilot, was departing on a local flight. The jet, piloted by an airline transport pilot, was rolling down the runway following a straight-in visual approach and landing. The single-engine airplane collided with the empennage of the jet at the intersection of the two runways. Witnesses in the airport lounge area heard the pilot of the single-engine airplane announce on the airport's universal communications (UNICOM) traffic advisory frequency a few minutes before the accident that the airplane was back-taxiing on the runway. The pilot of the jet did not recall making any radio transmissions on the UNICOM frequency and review of the jet's cockpit voice recorder did not reveal any incoming or outgoing calls on the frequency. The pilots of both airplanes were familiar with the airport, and the airport was not tower controlled.
The airport had signage posted on all runways indicating that traffic using the nearly perpendicular runway could not be seen and instructed pilots to monitor the UNICOM. A visibility assessment confirmed reduced visibility of traffic operating from the nearly perpendicular runways. The reported weather conditions about the time of the accident included clear skies with 4 miles visibility due to haze. Both airplanes were painted white.
It is likely that the pilot of the jet would have been aware of the departing traffic if he was monitoring the UNICOM frequency. Although the jet was equipped with a traffic collision avoidance system (TCAS), he reported that the system did not depict any conflicting traffic during the approach to the airport. Although the visibility assessment showed reduced visibility from the departing and arrival runways, it could not be determined if or at what point during their respective landing and takeoff the pilot of each airplane may have been able to see the other airplane. In addition to the known reduced visibility of the intersecting runways, both airplanes were painted white and there was reported haze in the area, which could have affected the pilots' ability to see each other.
Probable Cause and Findings
The National Transportation Safety Board determines the probable cause(s) of this accident to be:
The failure of both pilots to see and avoid the other airplane as they converged on intersecting runways. Contributing to the accident was the jet pilot's not monitoring the airport's traffic advisory frequency, known reduced visibility of the intersecting runways, and hazy weather condition.
Findings
Personnel issues Lack of action - Pilot
Personnel issues Lack of action - Pilot of other aircraft
Environmental issues (general) - Contributed to outcome
Environmental issues (general) - Contributed to outcome
Personnel issues Lack of communication - Pilot
Factual Information
History of Flight
Landing-landing roll Collision during takeoff/land
Pilot Information
Certificate: Airline transport Age: 70,Male
Airplane Rating(s): Single-engine land; Multi-engine land
Seat Occupied: Left
Other Aircraft Rating(s): None
Restraint Used: 5-point
Instrument Rating(s): Airplane
Second Pilot Present: No
Instructor Rating(s): Airplane multi-engine; Airplane single-engine
Toxicology Performed: No
Medical Certification: Class 2 With waivers/limitations
Last FAA Medical Exam: May 1, 2017
Occupational Pilot: Yes
Last Flight Review or Equivalent: June 24, 2017
Flight Time: 35437 hours (Total, all aircraft), 2537 hours (Total, this make and model), 35237 hours (Pilot In Command, all aircraft), 67 hours (Last 90 days, all aircraft), 12 hours (Last 30 days, all aircraft), 1 hours (Last 24 hours, all aircraft)
Aircraft and Owner/Operator Information
Aircraft Make: Cessna
Registration: N511AC
Model/Series: 525C C
Aircraft Category: Airplane
Year of Manufacture: 2012
Amateur Built: No
Airworthiness Certificate: Normal
Serial Number: 525C0081
Landing Gear Type: Retractable - Tricycle
Seats: 10
Date/Type of Last Inspection: March 9, 2018 Annual
Certified Max Gross Wt.: 17100 lbs
Time Since Last Inspection: 13 Hrs
Engines: Turbo jet
Airframe Total Time: 2537 Hrs at time of accident
Engine Manufacturer: Williams
ELT: C126 installed, not activated
Engine Model/Series: FJ44-4A
Registered Owner:
Rated Power: 3621 Lbs thrust
Operator: On file
Operating Certificate(s) Held: None
Meteorological Information and Flight Plan
Conditions at Accident Site: Visual (VMC)
Condition of Light: Day
Observation Facility, Elevation: MZZ,858 ft msl
Distance from Accident Site: 0 Nautical Miles
Observation Time: 16:55 Local
Direction from Accident Site: 0°
Lowest Cloud Condition: Clear Visibility 4 miles
Lowest Ceiling: None
Visibility (RVR):
Wind Speed/Gusts: 9 knots /
Turbulence Type Forecast/Actual: /
Wind Direction: 140°
Turbulence Severity Forecast/Actual: /
Altimeter Setting: 30.01 inches Hg
Temperature/Dew Point: 5°C / -1°C
Precipitation and Obscuration:
Departure Point: Jackson, MI (JXN)
Type of Flight Plan Filed: IFR
Destination: Marion, IN (MZZ)
Type of Clearance: IFR
Departure Time: 16:30 Local
Type of Airspace: Class G
Airport Information
Airport: Marion Municipal Airport MZZ
Runway Surface Type: Asphalt
Airport Elevation: 858 ft msl
Runway Surface Condition: Dry
Runway Used: 15
IFR Approach: None
Runway Length/Width: 3456 ft / 100 ft
VFR Approach/Landing: None
Wreckage and Impact Information
Crew Injuries: 1 None
Aircraft Damage: Substantial
Passenger Injuries: 4 None
Aircraft Fire: None
Ground Injuries: N/A
Aircraft Explosion: None
Total Injuries: 5 None
Latitude, Longitude: 40.490833,-85.679725
