Thursday, February 16, 2017

Beechcraft T-34A (A45) Mentor, Anderson Manufacturing, N3434G: Fatal accident occurred February 16, 2017 in Climax, Decatur County, Georgia

The National Transportation Safety Board traveled to the scene of this accident.

Additional Participating Entities:
Federal Aviation Administration / Flight Standards District Office: Atlanta, Georgia
Textron Aviation; Wichita, Kansas
Continental Motors Inc.; Mobile, Alabama

Aviation Accident Preliminary Report -  National Transportation Safety Board: https://app.ntsb.gov/pdf

Anderson Mfg Inc: http://registry.faa.gov/N3434G

NTSB Identification: ERA17FA107
14 CFR Part 91: General Aviation
Accident occurred Thursday, February 16, 2017 in Climax, GA
Aircraft: BEECH A45, registration: N3434G
Injuries: 1 Fatal.

This is preliminary information, subject to change, and may contain errors. Any errors in this report will be corrected when the final report has been completed. NTSB investigators either traveled in support of this investigation or conducted a significant amount of investigative work without any travel, and used data obtained from various sources to prepare this aircraft accident report.

On February 16, 2017, about 1852 eastern standard time, a Beech A45, N3434G, collided with trees and terrain during the final approach to landing at Anderson Airport (GE21), Climax, Georgia. The aerobatic-category airplane was substantially damaged. The private pilot was fatally injured. The airplane was registered to a private company and was operated by the pilot under the provisions of 14 Code of Federal Regulations Part 91. Night, visual meteorological conditions prevailed, and no flight plan was filed for the local, personal flight that originated about 1830.

According to a friend of the pilot, this was the pilot's first flight in the airplane since an annual inspection that was completed on February 9, 2017. The friend flew the airplane from Florida to Georgia immediately after the annual and reported that there were no mechanical anomalies during the flight.

There were no eyewitnesses to the accident. The airplane came to rest, inverted, on the approach end of runway 18. The unlit, grass runway was part of the pilot's personal property. Oak and pine trees were located at the northern boundary of the runway. An examination of the accident site revealed that the airplane collided with two oak trees on a southerly heading before contacting the ground. The airplane's tail cone remained lodged in one of the trees, and numerous broken tree limbs were found adjacent to the wreckage.

All structure and components of the airplane were accounted for at the accident site. The landing gear were found in the extended position and the wing flaps were retracted. Flight control continuity was confirmed from the ailerons, elevator, and rudder to the cockpit controls. The right wing was crushed and buckled; its bladder fuel tank was ruptured from impact forces and contained no quantifiable fuel. The left wing fuel tank contained about 11 gallons of blue-colored fuel. The cockpit fuel selector handle was found in the right tank position. The engine's two-blade propeller was minimally damaged, and there was no discernible bending or twisting of the blades.

The pilot, seated in the front cockpit seat, held an private pilot certificate with an airplane single engine land rating. He reported 1,200 hours of total flight time on his latest Federal Aviation Administration second-class medical certificate, dated June 17, 2015.

The single-engine, low wing, tandem-cockpit airplane incorporated a retractable, tricycle landing gear. It was equipped with a Continental IO-470-KCN reciprocating engine rated at 260 horsepower. Examination of maintenance logbooks revealed that the engine accumulated about 1,021 hours since its last major overhaul, which was accomplished in 1983. The airplane, which was stored outside on the pilot's property, has been operated a total of 40 hours during the 11 years prior to the accident.


According to sun and moon data for Climax, Georgia, sunset occurred at 1827 and the end of civil twilight occurred at 1851.

Those who may have information that might be relevant to the National Transportation Safety Board investigation may contact them by email eyewitnessreport@ntsb.gov, and any friends and family who want to contact investigators about the accident should email assistance@ntsb.gov.




DECATUR COUNTY, Ga. (WCTV) -- One person is dead following a small plane crash in Decatur County.

The Decatur County Sheriff Wiley Griffin says the crash occurred around 6:45 p.m. Thursday near Vada, Georgia.

Sheriff Griffin says the pilot, identified as 50-year-old Donald Royce Anderson, was the only person on board at the time and was killed in the crash.

Officials say the crash occurred at the end of Anderson's airstrip on Eula Mills Road near Boutwell Road.

The cause of the crash is not known at this time.


Source:  http://www.wctv.tv


DECATUR CO., GA (WALB) -

Officials have released the identity of the pilot who died in a plane crash in Decatur County Thursday night.

Donald Anderson, 50, died on impact after the single engine prop plane crashed at the end of his personal runway near Vada.

It happened just before 7 p.m. on Eula Mills Road.

Anderson's body has been sent to the GBI Crime Lab for an autopsy as a standard procedure.

The Federal Aviation Administration has been notified and will be in Decatur County Friday morning.

Source:   http://www.walb.com

Cessna 310Q, Florida Aircraft Marketing LLC, N69980: Accident occurred March 08, 2014 at Auglaize County Neil Armstrong Airport (KAXV), Wapakoneta, Ohio

Aviation Accident Final Report - National Transportation Safety Board: https://app.ntsb.gov/pdf

NTSB Identification: CEN14LA159
14 CFR Part 91: General Aviation
Accident occurred Saturday, March 08, 2014 in Wapakoneta, OH
Probable Cause Approval Date: 03/06/2017
Aircraft: CESSNA 310Q, registration: N69980
Injuries: 3 Uninjured.

NTSB investigators may not have traveled in support of this investigation and used data provided by various sources to prepare this aircraft accident report.

According to the private pilot, the cross-country flight was uneventful. As he parked the airplane on the ramp at the conclusion of the flight, a “puff of smoke” came from below the instrument panel. The pilot immediately shut down the electrical system, but the smoke continued to increase. He completed the airplane shutdown checklist, then he and the passengers exited the airplane. After exiting the airplane, the pilot stated he could hear fire in the nose compartment and saw paint on the nose compartment beginning to discolor. He removed the nose access panel and extinguished the fire with a fire extinguisher.

The heater had a history of fuel leaks, as evidenced by cracks found in the heater and fuel evaporation marks in the fuel pump box. Airplane maintenance manuals and manufacturer service bulletins recommended recurring inspections of the heater system and fuel lines, but there was no documentation in the airplane’s maintenance records that the inspections had been completed.

The National Transportation Safety Board determines the probable cause(s) of this accident as follows:
A fire due to a fuel leak of the cabin heater system. Contributing to the accident was the inadequate maintenance of the airplane, which failed to identify leaks in the heater system.

Additional Participating Entities:
Federal Aviation Administration/ Flight Standards District Office; Columbus, Ohio
Textron Aviation; Wichita, Kansas

Aviation Accident Factual Report -  National Transportation Safety Board:   https://app.ntsb.gov/pdf

Docket And Docket Items - National Transportation Safety Board: https://dms.ntsb.gov/pubdms

http://registry.faa.gov/N69980

NTSB Identification: CEN14LA159
14 CFR Part 91: General Aviation
Accident occurred Saturday, March 08, 2014 in Wapakoneta, OH
Aircraft: CESSNA 310Q, registration: N69980
Injuries: 3 Uninjured.

NTSB investigators may not have traveled in support of this investigation and used data provided by various sources to prepare this aircraft accident report.

On March 8, 2014, about 1120 eastern standard time (EST), a Cessna 310Q airplane, N69980, experienced fire in the nose compartment while taxiing to the ramp at Auglaize County Neil Armstrong Airport (AXV) in Wapakoneta, Ohio. The airplane was substantially damaged. The pilot and two passengers on-board were not injured. The airplane was registered to and operated by Fluid Process Automation, LLC, under the provisions of 14 Code of Federal Regulations Part 91 as a personal flight. Visual meteorological conditions prevailed for the instrument flight rules (IFR) flight, which originated at Akron-Canton Airport (CAK) in Akron, Ohio.

According to the pilot, the flight was uneventful. As he parked the airplane on the ramp at AXV, a "puff of smoke" came from below the instrument panel. Perceiving the electrical system was the sources of the smoke, the pilot immediately shut it down but the smoke continued to increase. The pilot completed the airplane shutdown checklist and exited the airplane with the passengers. After exiting the airplane, the pilot stated he could hear fire in the nose and noticed discolored paint on the nose compartment. He removed the nose access panel and extinguished the fire with a carbon dioxide fire extinguisher.

Wreckage

The airplane remained intact and the fire damage was limited to the nose compartment and the lower forward portion of the instrument panels and cockpit. Fire damage to the cabin area was limited to some thermal discoloration of the floor on the right side of the cockpit. The exterior damage was located on the upper portion and right side of the nose compartment. The upper section of the nose fuselage skin exhibited large areas of thermal discoloration of the exterior paint as well as bubbling and peeling of the outer layers of the paint. This damage continued down the right side of the nose compartment. The lower right exhaust louvers and the fuselage skin near the heater exhaust exhibited sooting and some thermal discoloration.

The interior of the nose compartment was heavily sooted and exhibited thermal damage particularly in the area of the cabin heater, which was located on the rear right side of the nose compartment. The left side of the compartment was heavily sooted with some generalized melting and sagging of wire insulation. On the right side, nonmetallic components (such as wire insulation, tubing and ducts) adjacent to the heater showed melting and thermal discoloration. Several rubber components of the heater assembly were missing and presumed destroyed by the fire. The exterior of the heater and adjacent metallic assembly components were sooted and had evidence of thermal discoloration. During the removal of the heater assembly, the heater assembly drain line was found blocked with a densely packed brownish-grey substance.

Heater Examination

The heater was a Southwind 8240E. According to maintenance/airplane logbooks and manufacturer information, the heater was installed when the airplane was manufactured and overhauled in 1997. A pressure decay test was performed on the combustion chamber in 2003. The current owner and pilot stated he had used the heater several times including the day of the accident.

The cabin heater assembly, including the vent and drain lines, the heater fuel pump box, and the light bulb from the heater annunciator light were removed from the airplane and sent to the NTSB Materials Laboratory for further examination.

The exterior case of the heater was removed and a pressure test of the combustion chamber and associated heat exchanger muff was performed. Four separate leaks were found. One leak was found in the igniter plug port weld. One leak was found in the heat muff end weld. Two leaks were found in the welds that attach the combustion chamber to the heat exchanger muff, and one of those leaks had a visible crack.

The blocked drain line was examined. It was determined that the material in the drain line was densely packed from the open (drain) end to the end. Approximately 0.4 grams of material was removed from the drain line using a thin wooden scraper. The material was brownish gray in color and had a powdery consistency. A sample of the material removed from the drain line was examined using a Fourier Transform Infrared (FTIR) spectrometer. The materials were consistent with lead oxide and aluminum oxides often found in aviation fuel combustion byproduct and other materials found within the aircraft engine compartment and fuel system.

There was evidence of fuel leakage in the fuel pump box, with evaporation marks where the fuel accumulated and evaporated off, leaving behind nonvolatile residue. There were several bands of evaporation marks consistent with multiple evaporation cycles. The fuel pump box had visible thermal discoloration, indicating it had been exposed to heat. Pressure testing of the fuel pump was not conducted due to the inability to recreate a pre-accident condition for the fuel pump.

Cessna Aircraft Company issued service letter ME73-3 on February 23, 1973, identifying the need for a special one-time inspection of aircraft heaters that have not undergone the first 100-hour inspection. The service letter also states "Service manuals presently recommend a check of the nose compartment with respect to heater fuel system components at each 100 hours." Cessna issued Service Bulletin MEB95-9 on June 16, 1995. MEB95-5 stated "The cabin heater fuel line should be inspected for fuel leaks and corrosion. Leaking fuel lines should be repaired or replaced based on results of the inspection. Minor corrosion pitting can be repaired but line replacement is required if pitting exceeds the limit allowed by this service bulletin. Non-compliance with this service bulletin could result in failure of the cabin heater fuel line; which could subsequently result in a fire." "Compliance – Mandatory, shall be accomplished within the next 100 hours of operation or 12 months, whichever occurs first." A review of the airplane's maintenance showed the heater was installed in the airplane at the time of manufacture, and overhauled in 1997. A combustion test was performed on February 3, 2003. No record of any additional inspections of the heater and fuel lines was found.

Horse meat, genitals in juice boxes seized at Washington Dulles International Airport (KIAD)



STERLING, Va. — U.S. Customs and Border Protection agents have seen some strange things at Virginia’s busiest airport, but what they discovered hidden in juice boxes at Washington Dulles International Airport on Jan. 29 left them flummoxed.

Officials said two women from Mongolia were concealing 30 pounds of horse meat inside juice boxes. One of the woman also had 13 pounds of horse genitals she said were for medicinal purposes.

Agents also found three liters of yak milk in the women’s luggage.

Neither woman was criminally charged and the pair were allowed to continue their visit.

The confiscated items were incinerated.

Source: http://wtvr.com

McDonnell Douglas 600N, N606BP: Accident occurred April 27, 2014 at Adelanto Airport (52CL), San Bernardino County, California




Additional Participating Entities:
Federal Aviation Administration Flight Standards District Office; Riverside, California
MD Helicopters Inc.; Mesa, Arizona
Rolls-Royce; Indianapolis, Indiana

Aviation Accident Final Report -  National Transportation Safety Board:   https://app.ntsb.gov/pdf


Docket And Docket Items -   National Transportation Safety Board:

https://dms.ntsb.gov/pubdms

http://registry.faa.gov/N606BP

Aviation Accident Data Summary - National Transportation Safety Board: https://app.ntsb.gov/pdf

NTSB Identification: WPR14LA173
14 CFR Part 91: General Aviation
Accident occurred Sunday, April 27, 2014 in Adelanto, CA
Probable Cause Approval Date: 02/13/2017
Aircraft: MCDONNELL DOUGLAS HELICOPTER 600N, registration: N606BP
Injuries: 1 Serious, 2 Minor.

NTSB investigators may not have traveled in support of this investigation and used data provided by various sources to prepare this aircraft accident report.

The purpose of the flight was for the airline transport pilot (ATP) to evaluate and check out the commercial pilot in the helicopter. The commercial pilot reported that he was acting as pilot-in-command and at the controls. A witness reported that, as the helicopter lifted off, it initially tilted left. He added that he saw the commercial pilot increase pitch on the collective and that the helicopter then yawed right 90 degrees and tilted nose down. It left the ramp to the north of the property and then the whole fuselage continued banking left almost 90 degrees and spun nose right. The helicopter spun about three revolutions until it sounded like the engine power was reduced to flight idle. Once the power was reduced, the helicopter’s nose dropped, and the main rotor blade contacted a fence pole, which caused it to suddenly stop and the helicopter to land hard, during which the right skid collapsed.

The witness reported that he had flown the helicopter for 25 minutes before the accident and completed one takeoff and one landing. He stated that all of the controls responded as commanded during his flight. No evidence of preimpact mechanical malfunctions or failures were found during the examination of the recovered airframe and engine.

It is likely that the commercial pilot made improper control inputs and subsequently lost helicopter control immediately after liftoff. It could not be determined whether the ATP made corrective actions in an attempt to regain control because he was seriously injured and unable to make a statement.

The National Transportation Safety Board determines the probable cause(s) of this accident as follows:
The commercial pilot’s improper control inputs, which resulted in a loss of helicopter control during takeoff.


HISTORY OF FLIGHT

On April 27, 2014, about 1251 Pacific daylight time, a McDonnell Douglas Helicopters (MDHI) MD600N, N606BP, collided with terrain at Adelanto, California. Classic Rotors Museum was operating the helicopter under the provisions of 14 Code of Federal Regulations (CFR) Part 91. The airline transport pilot (ATP) in the right seat sustained serious injuries, the commercial rated pilot in the left seat and one passenger in a rear seat sustained minor injuries. The helicopter sustained substantial damage during the accident sequence. The cross-country personal flight was departing when the accident occurred with a planned destination of Ramona, California. Visual meteorological conditions prevailed, and no flight plan had been filed.

Due to the nature of injuries to the ATP, he was unable to provide a statement as to the circumstances of the accident.

A Federal Aviation Administration (FAA) inspector interviewed the commercial pilot shortly after the accident. The pilot stated that he was getting evaluated in order to be able to fly the helicopter for the museum and at the controls during the accident as pilot-in-command (PIC). Prior to the checkout, he informed the ATP that he had 10,000 hours of flight time, primarily working off fishing boats in Guam. The commercial pilot could not provide the inspector with records that validated the flight time, or that he was a current, active pilot. The last medical dated December 15, 1993, indicated a total flight time of 3,300 hours. Attempts to locate and contact the commercial pilot for more information related to the circumstances of the accident were unsuccessful.

A witness reported that he had flown the helicopter with the ATP for 25 minutes prior to the accident flight, and completed one takeoff and one landing. He stated that all controls responded as commanded during his flight. The commercial pilot and a passenger then boarded for the next flight. The winds were from the west, and the helicopter was on a heading of 250 degrees. When it lifted off the ground, it initially tilted to the left looking like it was going to dynamically roll over. He saw the commercial pilot increase pitch on the collective; the helicopter yawed to the right 90 degrees, and tilted nose down. It left the ramp to the north of the property; the whole fuselage continued to have a left bank angle of almost 90 degrees, and it spun nose right. The helicopter spun approximately three revolutions until it sounded like the power to the engine was reduced to flight idle. Once the power was reduced to flight idle, the nose of the helicopter went down, the main rotor blade came in contact with a fence pole causing sudden stoppage, and a hard landing collapsed the right gear.

TESTS AND RESEARCH

The National Transportation Safety Board (NTSB) investigator-in-charge, an FAA inspector, and investigators from MD Helicopters and Rolls-Royce examined the recovered airframe and engine on May 28, 2014, at the facilities of Flight Trail Helicopters, Mesa, Arizona.

Control continuity for the collective, cyclic, pedals and throttle were established. There was crush damage to the airframe with more damage on the right side than the left side.

Continuity of the drive train was established from the rotor hub through the transmission out to the NOTAR fan. The NOTAR gearbox chip detector was clean. The NOTAR rotated freely by hand.

The throttle moved freely from stop to stop, and followed movement of the throttle control in the cockpit.

The engine was left installed in the helicopter, and the engine was securely mounted. All external lines and connections were secure when checked by hand.

The compressor impeller displayed some leading edge foreign object damage (FOD), but it could not be determined if the FOD damage occurred prior to or during the event sequence.

The fourth stage turbine wheel turned freely. The rotor head rotated when turned one direction; it did not rotate when the wheel was turned the opposite direction. The first stage turbine blades were examined with a lighted videoscope. The wheel turned freely, and there was no evidence of damage on the blades.

The oil level for the engine was above the line. The oil was drained and the oil filter was clean.

The upper and lower magnetic chip detectors were clean.

The oil scavenge filter was clean.

Fuel was drained from the airframe low pressure fuel filter; it appeared clear.

N1 turned freely and was continuous from the compressor to the starter generator.

The fuel nozzle was normal in appearance.

No evidence of preimpact mechanical malfunction was noted during the examination. A detailed report is in the public docket for this accident.



NTSB Identification: WPR14LA173
14 CFR Part 91: General Aviation
Accident occurred Sunday, April 27, 2014 in Adelanto, CA
Aircraft: MCDONNELL DOUGLAS HELICOPTER 600N, registration: N606BP
Injuries: 1 Serious,2 Minor.

This is preliminary information, subject to change, and may contain errors. Any errors in this report will be corrected when the final report has been completed. NTSB investigators may not have traveled in support of this investigation and used data provided by various sources to prepare this aircraft accident report.

On April 27, 2014, about 1251 Pacific daylight time, a McDonnell Douglas Helicopter (MDHI) MD600N, N606BP, collided with terrain at Adelanto, California. Classic Rotors Museum was operating the helicopter under the provisions of 14 Code of Federal Regulations (CFR) Part 91. The airline transport pilot sustained serious injuries; the commercial rated second pilot and one passenger sustained minor injuries. The helicopter sustained substantial damage during the accident sequence. The cross-country personal flight was departing when the accident occurred with a planned destination of Ramona, California. Visual (VMC) meteorological conditions prevailed, and no flight plan had been filed.

A witness reported that winds were from the west, and the helicopter was on a heading of 250 degrees. When it lifted off the ground, it initially tilted to the left looking like it was going to dynamically roll over. He saw the co-pilot increase pitch on the collective; the helicopter yawed to the right 90 degrees and tilted nose down. It left the ramp to the north of the property; the whole fuselage continued to have a left bank angle of almost 90 degrees, and it spun nose right. The helicopter spun approximately three revolutions until it sounded like the pilot got rid of the power bringing the engine to flight idle. Once the crew cut power to flight idle, the nose of the helicopter went down, the main rotor blade came in contact with a fence pole causing sudden stoppage, and a hard landing collapsed the right gear. Personnel on the ground assisted the crew getting out of helicopter. The pilot was unconscious inside of the helicopter, and one of the ground personnel assisted the pilot by supporting him. The witness called for emergency services, and the pilot was airlifted to a hospital.

Mystery of low-flying plane over Alden and Clarence, New York, solved



CLARENCE, N.Y. (WIVB) — News 4 has found out what caused a loud noise that jarred people in the Clarence and Alden areas Wednesday evening.

Calls and emails flooded into our newsroom around 6:45 p.m. from people who said they heard a low-flying plane.

One man in the Alden told us he was brushing off his car when he saw the low-flying plane. He estimated it was only flying at about 300 feet. “(Flight) 3407 came to my mind real fast,” Alden resident Paul Werner told News 4. “I thought for sure I was going to hear and see a big explosion. And thank God nothing happened like that.”

On Thursday morning, public affairs representatives with the Niagara Falls Air Reserve Station confirmed the plane that was seen Wednesday evening was one of their C-130s on a routine low-altitude training flight.

Those cargo planes are designed for low level missions and can fly as low as 300 feet, but usually cruise between 500 and 1,000 feet up. And, they’re flying over Western New York all the time, with training missions every week.

Usually the crews try to fly the C-130s over less populated areas, so people don’t notice. But, the one spotted over Alden and Clarence last night was a little different.

We’re told the crew saw a minor warning light go off as they were flying, so they turned to take the most direct route back to the base. They were still on an approved route, still working with air control, but this flight took the plane over the Clarence area, where, understandably, people are on edge about low flying planes.

The eighth anniversary of the tragic crash of Flight 3407 was only last weekend. That crash in Clarence Center killed 50 people, including one person on the ground.

In the dark Wednesday night, and in the few seconds the plane was seen, at least some people mistook it for a commercial airliner flying below the normal altitude.

Niagara Falls Air Reserve Station reps say they understand people’s sensitivity to the situation, but they point out, unless you live right by the base, most people in Western New York are used to seeing commercial airplanes like the ones flown out of Buffalo Niagara International. Anything out of the ordinary generally catches people’s attention.

Case in point: According to NFARS Public Affairs reps, on Thursday morning, during a separate training flight, another plane was put in a holding pattern and had to circle over Amherst. The Air Base also fielded several calls about that.

The 914th Airlift Wing started flying C-130s out of the Niagara Falls Air Reserve Station several years ago, but will soon transition to an Air Refueling Wing mission, as more KC-135 stratotankers arrive.

Airmen from the 914th Airlift Wing departed on their final deployment as a C-130 Air Reserve Station last May, but training flights on the C-130s continue.

Story and video:   http://wivb.com

Robinson R-44 II, Quicksilver Air, N74713: Accident occurred June 18, 2014 in Coldfoot, Alaska

Aviation Accident Final Report  -  National Transportation Safety Board: https://app.ntsb.gov/pdf

Docket And Docket Items - National Transportation Safety Board: https://dms.ntsb.gov/pubdms

Aviation Accident Data Summary -  National Transportation Safety Board:  https://app.ntsb.gov/pdf

Quicksilver Air Inc: http://registry.faa.gov/N74713

Additional Participating Entities:

Federal Aviation Administration Fairbanks Flight Standards District Office; Fairbanks, Alaska

NTSB Identification: ANC14CA042
Nonscheduled 14 CFR Part 135: Air Taxi & Commuter
Accident occurred Wednesday, June 18, 2014 in Coldfoot, AK
Probable Cause Approval Date: 08/14/2014
Aircraft: ROBINSON HELICOPTER COMPANY R44 II, registration: N74713
Injuries: 3 Uninjured.

NTSB investigators used data provided by various entities, including, but not limited to, the Federal Aviation Administration and/or the operator and did not travel in support of this investigation to prepare this aircraft accident report.

The commercial helicopter pilot reported that the purpose of the flight was to transport two technicians to a remote site in an area of mountainous terrain. The pilot fueled the helicopter and flew approximately 30 minutes to a staging area. After loading the two passengers and their gear, he flew to the planned landing zone (LZ), in a narrow box-valley at about 2,550 feet MSL. The proposed LZ was evaluated while performing an out-of-ground-effect hover, but the pilot determined the LZ was unsuitable. A second LZ was evaluated using the same process and also found unsuitable.

While hovering out of ground effect, above a third potential LZ, the helicopter began to descend and the pilot added collective pitch to stop the descent. He said the low rotor annunciator horn then sounded and the helicopter continued to descend. In an attempt to avoid landing in an area of uneven terrain, the pilot said he opted to turn the helicopter to the right and downslope, while trying to override the engine governor to attain additional engine power. The helicopter's skids subsequently struck an area of uneven, down sloping terrain. During touchdown, the helicopter nosed down, pivoted to the left, and rolled onto its left side. The helicopter sustained substantial damage to the fuselage, tail boom and main rotor drive system. The pilot reported no preaccident mechanical anomalies with the helicopter that would have precluded normal operation.

The pilot characterized the down sloping wind conditions as light and variable.

The National Transportation Safety Board determines the probable cause(s) of this accident as follows:
The pilot's failure to maintain adequate main rotor rpm while maneuvering at a low altitude, which resulted in an emergency landing on uneven terrain.

Palm Beach International Airport (KPBI) wants more international flights



Palm Beach International Airport wants to offer more flights abroad, seeking to open new routes to Europe for travelers looking to avoid the crowds at busier South Florida terminals.

Palm Beach International’s only flights abroad are to Canada and the Bahamas.

Palm Beach County Commissioner Steven Abrams said people want more options. Travelers can use nearby airports in Fort Lauderdale and Miami, but they must also deal with the traffic and lines that come with those terminals, he said.

“It is inconvenient if your final destination is Palm Beach County,” Abrams said. “We want them to land here.”

The airport comprises a minuscule slice of international travel in South Florida with only 154,500 international passengers in 2016.  Miami International Airport, one of the busiest in the country for international travel, had 21 million international passengers. Fort Lauderdale-Hollywood International Airport recorded 6 million international passengers.

Palm Beach County’s marketers have met with airlines in Europe about launching new routes to West Palm Beach, according to a report reviewed by county commissioners. Lacy Larson, a spokeswoman for Palm Beach International, declined to say which routes the airport is hoping to launch.

But those efforts have been grounded because U.S. Customs and Border Protection officers end their shifts at 4 p.m., county officials say.

Expanding international service will be “difficult if not impossible” if customs won’t operate later than 4 p.m., according to the report presented by county lobbyists.

The limited coverage at Palm Beach International is because only a few international flights land there, said Rachel Torres, a Florida-based spokeswoman for U.S. Customs. The airport could apply for a program in which local government or businesses reimburse the agency for extended hours, she said.

Larson said the airport is working with its Congressional representatives to expand the hours of customs.

Competing airports have been aggressive in launching new routes. Last year, Fort Lauderdale-Hollywood International Airport started nonstop service to Dubai, which airport officials say will generate a regional economic impact of $100 million per year. International traffic there nearly doubled from 2010 to 2016.

The new routes can be lucrative for both airlines and airports, said Dawna Rhoades, professor of international aviation management at Embry-Riddle Aeronautical University.

International travelers are more likely to upgrade to first-class and pay extra for amenities, a key source of revenue for airlines, she said. Airports make money on everything from landing fees to increased business at terminal restaurants and bars.

Palm Beach International is underutilized, said Joe Rooney, acting president and CEO of the Economic Council of Palm Beach Council. He said he doesn’t mind if he has to pay more to fly out of West Palm Beach.

“If you can get a flight, it is absolutely preferred," he said.

Source:  http://www.sun-sentinel.com

AĆ©rospatiale AS 350BA Ecureuil, Sunshine Helicopters, N6094H: Accident occurred June 17, 2014 in Wailuku, Hawaii

Aviation Accident Final Report - National Transportation Safety Board: https://app.ntsb.gov/pdf

NTSB Identification: WPR14LA251
Nonscheduled 14 CFR Part 135: Air Taxi & Commuter
Accident occurred Tuesday, June 17, 2014 in Wailuku, HI
Probable Cause Approval Date: 03/23/2017
Aircraft: AIRBUS AS 350 BA FX1, registration: N6094H
Injuries: 7 Uninjured.

NTSB investigators may not have traveled in support of this investigation and used data provided by various sources to prepare this aircraft accident report.

The commercial pilot of the helicopter was conducting the third local tour flight of the day when, about 10 minutes after departure, the main rotor speed (rpm) started to decrease and the low rotor warning alarm sounded. The pilot lowered the collective pitch control to increase rotor rpm, and the helicopter started to descend. He then raised the collective pitch control, and the main rotor rpm started to decrease again. The pilot entered an autorotation, and the helicopter landed hard in tall grass, resulting in substantial damage to the fuselage and tailboom.

A test run of the engine revealed that, when power was applied, the engine would not achieve a speed above about 78% Ng (engine gas generator speed). Fuel flow indications during the test run were between 125 and 140 pounds per hour (pph); the required value was 300 pph. A leak test of the pneumatic controls revealed that the fitting for the input line to the pneumatic pressure (Pc) filter housing was fractured. A second test run of the engine, following replacement of the Pc filter assembly, was successful. Thus, the fractured fitting rendered the control system incapable of modulating Pc pressure to the fuel control, which resulted in a loss of engine power.

Further examination of the fitting revealed fracture features consistent with fatigue and overload. The Pc filter requires continuous recurring inspections. The filter housing is hard-mounted to the side of the engine plenum and connected to the system via hard pneumatic lines with torqued fittings. Each time that the filter is inspected, the filter housing fittings are subjected to mechanical loosening and re-torqueing. It is likely that the repeated loosening and re-torqueing of the fitting during required maintenance and inspection contributed to the fitting’s failure. Following the accident, the manufacturer issued a service bulletin regarding the service and inspection of Pc filter fittings.

The National Transportation Safety Board determines the probable cause(s) of this accident as follows:
The failure of the engine’s pneumatic fuel control line fitting, resulting in a loss of engine power. Contributing to the failure was the repeated loosening and re-torqueing of the fitting during required maintenance and inspection.

Additional Participating Entities:
Federal Aviation Administration Flight Standards District Office; Honolulu, Hawaii
Honeywell Aerospace; Phoenix, Arizona

Aviation Accident Factual Report -  National Transportation Safety Board:  https://app.ntsb.gov/pdf

Docket And Docket Items - National Transportation Safety Board: https://dms.ntsb.gov/pubdms

Sunshine Helicopters Inc: http://registry.faa.gov/N6094H

NTSB Identification: WPR14LA251
Nonscheduled 14 CFR Part 135: Air Taxi & Commuter
Accident occurred Tuesday, June 17, 2014 in Wailuku, HI
Aircraft: AIRBUS AS 350 BA FX1, registration: N6094H
Injuries: 7 Uninjured.

NTSB investigators may not have traveled in support of this investigation and used data provided by various sources to prepare this aircraft accident report.

On June 17, 2014, about 1330 Hawaii standard time, an Airbus AS 350 BA helicopter, N6094H, sustained substantial damage during a hard landing following a loss of engine power and off-airport auto rotation. The helicopter was registered to and being operated by Sunshine Helicopters Inc., Puunene, Hawaii, as a visual flight rules (VFR) scenic tour flight under 14 Code of Federal Regulations (CFR) Part 135. Visual meteorological conditions prevailed; the pilot and the five passengers were not injured. The flight departed Kalului Airport (PHOG), Kalului, Hawaii, about 1300, and company flight following procedures were in effect.

During a telephone conversation with the National Transportation Safety Board (NTSB) investigator-in-charge (IIC) on June 26, a representative for Sunshine Helicopters said the pilot reported that he was 10 minutes out on his third flight of the day, when during cruise flight the main rotor speed (RPM) started to decrease and the low rotor warning alarm sounded. He lowered the collective pitch control to increase rotor RPM, and the helicopter started to descend. He raised the collective pitch control and the main rotor RPM started to decrease again; he entered an autorotation, and landed the helicopter.

The helicopter landed hard in tall grass, structurally damaging the fuselage and tailboom.

After recovery, the helicopter's engine (Model LTS101-600A-3A) was removed, and was shipped to the engine manufacturer's facility for further examination under the supervision of the NTSB.

On August 7, 2014, an examination of the engine was conducted.

The examination was conducted under the supervision of the NTSB IIC. In attendance were representatives of the FAA, the operator, and the engine manufacturer. The engine was received in secure packaging and remained unopened until commencing the examination.

ENGINE

Honeywell LTS101-600A-3A Serial # ADCC40239400315

Total Time Since New 8,917

Total Time Since Major Overhaul 547

Total Since Last Inspection (100 hour) 3

ENGINE CONDITION

The engine did not appear to have sustained any physical damage during the autorotation and hard landing. The decision was made to attempt to run the engine in a test cell prior to any disassembly. The engine was installed in an engine test cell and an exterior examination completed.

FUEL SYSTEM DESCRIPTION ENGINE MODEL LTS101-600A-3A

The fuel system consists of an airframe-mounted fuel filter, an engine control system, a fuel manifold with integral flow divider and associated lines. A pressure-operated drain valve at the bottom of the combustor housing drains fuel from the combustor when the engine is shut down. The engine control system consists of a gas generator fuel control (which includes fuel pump), an ambient temperature compensator, a PT governor and, if incorporated, a starting assist fuel system. The fuel system on engine LTS101-600A-3A includes components of the mechanical overspeed protection system and the power turbine retention system. Fuel flow control of the fuel system is controlled through pneumatic pressure (Pc) as generated by the compressor discharge and routed to the various control systems. The PC filter/housing is used to filter the pneumatic compressor discharge air prior to entering the engine control system.

EXAMINATION SUMMARY

8/7/2014:

The engine (LTS101-600A-3A) was removed from the standard shipping container and prepared for installation into the test cell.

The initial test to be performed was the power turbine governor check per the manufacturer's test instruction TI-8114.

Initially the engine was hard to start, but eventually was successfully started.

The engine was brought up to ground idle and stabilized appropriately.

The engine was advanced to flight idle and stabilized appropriately.

The power lever input to the engine was advanced above flight idle but the engine would not achieve a speed above approximately 78% NG. Fuel flow was approximately 125-140 pph.

The test requires 300 pph in order to successfully complete the test. The engine appeared to be sluggish and slow to respond to power lever inputs.

During the testing, vibration in the axial direction was measured on the forward flange of the compressor housing. The measurement exceeded the allowable limit of 0.7 in/sec. A maximum value of approximately 1.3 in/sec was observed with the test cell measurement equipment in the axial direction.

After shutting down the engine, a leak test of the pneumatic controls was initiated.

While removing the input line to the Pc filter housing (the filter and housing are located on the side of the compressor plenum housing) the fitting was found broken. This fitting sends compressor discharge air to the pneumatic system which is used for control of the engine by the various controls components.

A decision was made to replace the Pc filter assembly with a known good one and re-run the previous test.

A re-run of the engine, following the same PT governor check test, was successful with a 300 pph fuel flow achieved. The engine response was appropriately reactive to power lever angle changes and settings.

8/8/2014:

The fracture surface of the broken Pc filter housing inlet fitting was examined at Honeywell's materials analysis lab using a scanning electron microscope (SEM). Evidence of course fatigue striations were identified.

Additional vibration recording equipment was attached to the accident engine and a subsequent test run (with the known good Pc filter assembly) was performed. Vibration data was captured and recorded for future analysis.

The engine was removed from the test cell and sealed back into the approved shipping container.

PCD FILTER HOUSING EXAMINATION

In an effort to identify the failure mode of the lower fitting into the PC filter housing, the failed fracture surface was analyzed. SEM (Scanning Electron Microscope) documentation of the submitted failed parts was completed. SEM images and Energy Dispersive X-ray analyses (EDX) were captured of the fracture surface and material of the part. The following findings and conclusions were made:

• The tube separation at one end of the PC filter housing was a result of a high-strain fatigue fracture mode.

• The fatigue appeared to initiate from multiple locations around the OD of the tube. No defects or anomalies were observed on the fracture surface.

• The fatigue was observed around most of the fracture surface. The final separation exhibited fracture features indicative of fatigue/overload mixed fracture modes.

• Damage was noted on the hexagonal end of the housing where tooling is used to tighten the fittings.

Fuel is delivered through an airframe-mounted fuel filter to the pump section of the fuel control. The pump, driven by gearing from the gas generator spool, delivers fuel to the metering section of the fuel control. During engine start, metered fuel flow from the fuel control is initially directed to primary orifices of the fuel nozzles by the flow divider. Combustion is initiated by the igniter plug, and as the gas generator speed (Ng) and fuel pressure increases, the flow divider begins to direct fuel through secondary orifices of fuel nozzles. When the gas generator reaches 48 to 52 percent Ng, ignition and starter are manually de-energized. The PT governor is the principal controlling unit in a steady state power range between the flight detent and maximum power. Maximum power and ground idle are controlled by the gas generator fuel control. Maximum and minimum fuel flows are limited by stops within the fuel control.

ADDITIONAL INFORMATION

Note: the pneumatic filter involved in the accident requires continuous recurring inspections as described below. The filter housing which failed is hard mounted to the side of the engine plenum, and connected to the system via hard pneumatic lines with torqued fittings. Each time that the filter is inspected, the filter housing fittings are subjected to mechanical loosening and re-torqueing.

Pneumatic Control System Filter (Pc)

Pc filter servicing will be accomplished at each 150 hour periodic inspection. Service interval may be adapted to a specific operating environment.

A. Pc filter servicing will be accomplished at each 150 hour periodic inspection or service interval may be adapted to a specific operating environment.

B. Service Pc filter by any one of the following steps:

(1) Remove and replace Pc filter element.

(2) Remove, clean and reinstall Pc filter element.

(3) Perform Pc filter differential pressure check.

C. Establish Pc filter service interval as follows:

(2) Perform Pc filter differential pressure check at each 150 hour periodic inspection.

(a) If the Pc filter does not require cleaning or replacement after five 150 hour periodic inspections (700 engine operating hours since step (1)), 600 engine operating hours may be established as the Pc filter service interval and the performance of the Pc filter differential pressure check may be discontinued.

(b) If the PC filter requires cleaning or replacement prior to the fourth 150 hour periodic inspection, the total number of engine operating hours since step (1) minus 150 engine operating hours may be established as the Pc filter service interval and the performance of the Pc filter differential pressure check may be discontinued.

Following the examination, the manufacturer took the following steps;

1. On December 8, 2015, the manufacturer released a category 1 safety service bulletin (LT 101-73-10-0278) to the field affecting all LTS101 engines removing specific versions of the Pc Filter with minimal wall thickness at the inlet fitting making them more susceptible to over stress during removal and installation of the attachment fittings if not properly torqued or supported. (Note: there are 3 versions of the Pc filter in the field.)

2. In addition, this same service bulletin provided instructions to perform PC filter fitting crack inspections; provided torqueing instructions for the PC filter pneumatic tubing B nuts requiring the use of a backup wrench on the attachment fittings while torqueing the B nut; Perform a pneumatic leak check of the pneumatic control system.

3. New Pc filter assemblies are being made available to the field with an increased wall thickness at the fitting attachment point to provide a higher margin of safety in the event the inlet fitting is over torqued or is not properly supported during torqueing. An update to the service bulletin from December of 2015 is about to be released alerting the field to the new PC filter assemblies that are available.

The manufacturer felt that with the use of proper torqueing values and proper torqueing techniques as defined in the engine maintenance manual, an issue like this should not occur. However, in order to add an additional significant safety margin to the assembly in the event that the proper torque or technique is not used, the manufacturer also increased the part's strength with a thicker wall thickness at the fitting inlet.

Charleston International Airport to add kiosks for small businesses throughout terminal

Charleston International Airport officials hope to offer new vendor options to the nearly 4 million people who travel through the state's busiest terminal each year.

The Charleston County Aviation Authority board unanimously signed off on the plan Thursday to install five kiosks operated by small business owners over the next year.

The first two movable carts or set-in-place vendors in the $50,000 program could be set up in the spring, with others to follow, according to Shelby Scales, vice president of Jacobsen|Daniels, a planning and management firm hired by the airport for guidance on the project.

The program is aimed at small businesses in the region who might one day be successful enough to have their products carried in one of the shops already at the airport.

Applicants must submit a detailed business plan showing company background, product concept, financial objectives and how the business will be managed, among other criteria. They also must not compete with existing concessionaires at the airport.

"We want to compliment what you already have with regional brands," Scales said.

Not every applicant will be accepted or be right for the market, she added.

"We don't want a flea market appearance," Scales said.

The Aviation Authority will own the kiosks. Vendors will pay 10 percent to 13 percent of gross revenue or a minimum of $500 to $1,000 a month to lease the spaces. Leasing terms could run from six months to three years, and a vendor's success will be evaluated at different intervals.

She also assured Aviation Authority members that correctly selected vendors are revenue producers and cited other airports such as Denver and Minneapolis that have similar programs.

"I think you have a great opportunity here," Scales said.

Airport officials lauded her presentation and welcomed the concept.

"I think it will be a great program to expand what we already have," said Hernan Pena, airport vice president of engineering.

"It's a great opportunity to help small businesses succeed," board vice chairman Walter Hundley said.

Source:  http://www.postandcourier.com

Parts of Thomson, Georgia, plane crash lawsuit settled: Hawker Beechcraft 390 Premier IA, The Vein Guys, N777VG, fatal accident occurred February 20, 2013

THOMSON, Ga. (WRDW/WAGT) -- A plane crashed in Thomson back in February 2013 and parts of a lawsuit filed after that crash have been settled.

The plane crashed deep in the woods behind the Milliken plant on property owned by a couple who have lived there for 45 years. They were both home when the whole thing happened on Feb. 20, 2013.

The crash, which killed five employees from The Vein Guys, happened as a plane was returning to the Thomson-McDuffie Regional Airport from Nashville.

In October 2014, the National Transportation Safety Board blamed the pilot for not knowing the aircraft well enough and also points out his fatigue during the flight.

"As a result, five people died who did not have to. Just as pilots should not take off without enough fuel, they should not operate an aircraft without enough rest," said NTSB Acting Chairman Christopher A. Hart.

A factual report released in July 2014 showed one of the plane's wings clipped a utility pole while trying to land. That report can be found here.

NTSB said the copilot verbally acknowledged the illuminated antiskid fail light, but the pilot continued to try and land. The Federal Aviation Administration-approved Abbreviated Pilot Checklist said the antiskid failure light would mean the plane needed a longer runway than the one at Thomson-McDuffie Country Airport. NTSB suggested the pilot should have found another airport to land the plane.

In September 2013, families of the fatal plane crash victims filed civil suits in Fulton County Superior Court over the crash.

Some of the defendants named are the estate of Vein Guys co-owner Dr. Mary Anne Roth, wife of Dr. Steven Roth who died in the crash, city of Thomson, McDuffie County, the Thomson-McDuffie Regional Airport, Georgia Power Company.

The Vein Guys' attorney, Jim Ellison, said a portion of the lawsuit involving the city and the county has been resolved. It was resolved in a confidential settlement. They resolved and decided the insurance carrier would contribute a dollar amount to airport coverage for the 2013 incident. It's under $4 million. The city agreed to the policy coverage as understood by the carrier that it would just cover a gas pipeline operation belonging to the city, according to city attorney James Westberry.

The policy was not written that way according to the city. They wanted it to cover all of the city's operations, including the airport. The court denied both motions.

The part of the suit involving Georgia Power and Milliken is still pending.

Source:  http://www.wrdw.com

Aviation Accident Final Report -  National Transportation Safety Board: https://app.ntsb.gov/pdf

Additional Participating Entities:
FAA; Washington, DC
Beechcraft; Wichita, Kansas
Williams International; Commerce Township, Michigan

http://registry.faa.gov/N777VG

Docket And Docket Items - National Transportation Safety Board:   https://dms.ntsb.gov/pubdms

NTSB Identification: ERA13MA139
14 CFR Part 91: General Aviation
Accident occurred Wednesday, February 20, 2013 in Thomson, GA
Probable Cause Approval Date: 10/21/2014
Aircraft: BEECH 390, registration: N777VG
Injuries: 5 Fatal, 2 Serious.
NTSB investigators traveled in support of this investigation and used data obtained from various sources to prepare this aircraft accident report.

The purpose of the flight was to return employees of a vein care practice to their home base at Thomson-McDuffie County Airport (HQU), Thomson, Georgia. The pilot was the pilot flying, and the copilot was the pilot not flying. (The National Transportation Safety Board [NTSB] notes that although the copilot is referred to as such in this report, his role in the cockpit is not required by federal regulations.) The departure from John C. Tune Airport, Nashville, Tennessee, and en route portions of the flight were uneventful. During the flight, the copilot reminded the pilot about a speed restriction and also reminded the pilot to adjust his altimeter. The pilot responded to the altimeter reminder by stating, "say, I'm kinda out of the loop or something. I don't know what happened to me there but I appreciate you lookin' after me there." About 4 minutes later, on approach to HQU, the pilot lowered the landing gear, and the ANTI SKID FAIL message illuminated in the cockpit; the copilot commented on the illumination. The pilot continued the approach; he did not respond to the copilot and did not refer to the Abnormal Procedures section of the Federal Aviation Administration (FAA)-approved Abbreviated Pilot Checklist to address the antiskid system failure message. The airplane touched down on runway 10 about 2005, and about 7 seconds later, the pilot initiated a go-around. (In postaccident interviews, neither the pilot nor the copilot recalled the reason for the go-around.) The airplane lifted off near the departure end of the 5,503 ft-long runway. According to enhanced ground proximity warning system (EGPWS) data, when the airplane was about 63 ft above ground level, the left wing struck a utility pole, which was 72 ft high and about 1,835 ft from the runway threshold, severing the outboard portion of the wing. The airplane continued another 925 ft before crashing in a wooded area.

Examination of the wreckage revealed no evidence of any preimpact failures or malfunctions of the engines or flight controls. The reason for the antiskid system malfunction could not be determined due to the general destruction of the wreckage.

For an antiskid inoperative condition, the Abbreviated Pilot Checklist only provides landing distance values for flaps up and flaps 10 degrees. The pilot should have selected one of those two flap settings for landing and determined the landing distance required. The first data recorded by the EGPWS showed that the airplane was configured at flaps 30. The flaps were transitioning through flaps 15 at the time of impact.

When the antiskid system fails, the landing distance required for full stop increases greatly: according to the Abbreviated Pilot Checklist, the landing distance would increase about 130 percent with flaps up and 89 percent with flaps 10. Thus, the required landing distance for the weather conditions that prevailed at HQU at the time of the accident with flaps up was 7,066 ft, and the required landing distance with flaps 10 was 5,806 ft. HQU runway 10's available runway length for landing was 5,208 ft, which did not meet the flaps up or flaps 10 performance penalty requirements with an antiskid system failure, thus requiring a diversion to a longer runway. It is likely that after touchdown, the pilot recognized that the airplane was not slowing as he expected and might not stop before the end of the runway. Rather than risk a high-speed overrun, he elected to conduct a go-around.

The NTSB determined that at the time the airplane struck the utility pole, the landing gear was extended, the flaps were in transit (retracting) toward the 10-degree position, and the lift dump system was deployed. Lift dump is a critical system to assist in stopping the Beechcraft 390 Premier (Premier 1A) during landing. Section 3A of the airplane flight manual (AFM) (Abnormal Procedures) included the following warning: "Extending lift dump in flight could result in loss of airplane control leading to airplane damage and injury to personnel. Continued safe flight with lift dump extended has not been demonstrated." The wreckage examination as well as drag estimates based on recovered EGPWS data indicate that the lift dump remained extended during the airplane's go-around attempt. The airplane drag associated with lift dump, flaps, and landing gear likely resulted in only marginal climb performance. While Beechcraft does not publish a procedure for a go-around after touchdown, aerodynamic data for the 390 Premier (Premier IA) suggest that if the airplane were configured with lift dump retracted and flaps 10 degrees or less, it would have been capable of a significantly higher climb rate after the failed landing attempt.

The pilot displayed a lack of systems knowledge of the accident airplane. First, the pilot demonstrated a lack of understanding of the antiskid system. Although the pilot had received antiskid system failure training during his recurrent simulator training on January 4, 2013, he stated in postaccident interviews that he did not think they needed the antiskid system for the landing at HQU and that the performance penalty would only apply if you were "trying to make your numbers." Because of this faulty belief, when the antiskid failure illumination occurred, the pilot did not take action. Second, the pilot selected a flap position (flaps 30) that was prohibited by the antiskid failure procedures in the AFM. Third, he performed a go-around with the lift dump extended. Both the AFM and a placard in the cockpit warned against extending the lift dump in flight. When the pilot decided to go around, he should have immediately retracted the lift dump per the AFM restriction for lift dump extension in flight.

The utility pole (Pole 48) that was struck was erected, along with several others, in 1989 by Georgia Power. The FAA was not notified before the construction of the utility poles in 1989; accordingly, no obstruction evaluation was done, and no depictions or mention of possible obstructions in the area were included on associated aeronautical charts. After the accident, Georgia Power submitted FAA Forms 7460-1 for four utility poles east of the airport, including Pole 48. The FAA conducted aeronautical studies on the poles and, on May 31, 2013, determined in its initial findings that Pole 48 did not comply with FAA obstruction standards and was "presumed to be a hazard to air navigation." The study also stated that if the pole were lowered to a height of 46 ft or less, it would comply with obstruction standards. After the FAA issued the preliminary obstruction determinations, Georgia Power requested that the FAA conduct further study on the four obstructions to determine if a favorable determination could be achieved. On August 12, 2013, the FAA published public notices announcing the four aeronautical studies and invited interested parties to submit relevant comments before September 18, 2013. According to an FAA official, the final determinations for the four obstructions were not completed at the time of this report. Since the initial aeronautical studies were conducted, the FAA Flight Data Center issued several notices to airmen to alert pilots about obstructions and also to amend the approach and departure procedures at HQU accordingly. In addition, the FAA increased the glideslope angle for the runway 28 precision approach path indicator from 3.00 to 3.50 degrees. Although the FAA has deemed the pole a presumed hazard, the pilot's attempted flight with the extended lift dump made airplane control and continued safe flight unlikely.

In evaluating the pilot's performance, the NTSB considered that the pilot experienced a sleep restriction, a circadian disruption the night before the accident, and long duty hours and extended wakefulness. The pilot normally slept about 8 hours per night; however, he only slept 5 hours the night before the accident (February 19). Further, the pilot awoke about 0200 on the morning of the accident, which was significantly earlier than his normal waking time of about 0600. On the day of the accident, he reported that upon arrival in Nashville, he slept for about 4 hours in a chair in the pilot lounge. However, his cell phone activity indicated outgoing calls during that time, suggesting interruptions to his sleep, which would have fragmented any sleep the pilot did obtain and degrade its restorative quality. Additionally, the accident took place about 2006, indicating an extended period of wakefulness based on the early awakening. Based on the available evidence, the pilot was likely suffering from fatigue at the time of the accident. Research indicates that fatigue associated with sleep loss, circadian disruption, and long duty hours can lead to increased difficulty in sustaining and directing attention, memory errors, and resultant lapses in performance. An NTSB safety study found that flight crewmembers who were awake for more than 12 hours made more procedural errors, tactical decision errors, and errors of omission than those awake less than 12 hours (NTSB. 1994. A Review of Flightcrew-Involved Major Accidents of U.S. Air Carriers, 1978 through 1990. SS-94/01. Washington, DC). Twice during the accident flight, the copilot gave the pilot reminders (one about the speed restriction and one about the altimeter). The pilot responded by indicating that he was "out of the loop." Further, the pilot did not refer to the Abbreviated Pilot Checklist for the antiskid system failure (for which the copilot commented on the illuminated light) or retract the lift dump when he elected to go around. Had the pilot not been fatigued, he likely would have paid closer attention to the flight and not had lapses in performance.

Both pilots survived, with serious injuries, and all five passengers, who were seated in the back, died. Postaccident examination showed that the seat buckles in the back were not fastened and the shoulder harnesses were not attached or pulled out. According to the copilot, the "fasten seatbelt" sign was on (the seatbelt chime was recorded by the cockpit voice recorder), but he did not remember giving a briefing on seatbelts. The pilot indicated that he did not remember seeing if the passengers had their seatbelts on. All six of the passenger seats had been forcibly detached from the airplane fuselage, and three were consumed by fire. All of the passengers sustained multiple traumatic injuries. Although proper use of restraint systems in survivable accidents can dramatically lessen or prevent serious injuries to occupants, due to the high impact forces and fragmentation of the cabin in this accident, it is unknown whether the use of restraints would have affected the survivability of the passengers.

Member Sumwalt filed a concurring statement that can be found in the public docket for this accident. Member Weener joined the statement.

The National Transportation Safety Board determines the probable cause(s) of this accident as follows:
The pilot's failure to follow airplane flight manual procedures for an antiskid failure in flight and his failure to immediately retract the lift dump after he elected to attempt a go-around on the runway. Contributing to the accident were the pilot's lack of systems knowledge and his fatigue due to acute sleep loss and his ineffective use of time between flights to obtain sleep.

Member Sumwalt filed a concurring statement that can be found in the public docket for this accident. Member Weener joined the statement.

***This report was modified on August 25, 2014, and October 21, 2014. Please see the docket for this accident to view the original report.***

HISTORY OF FLIGHT

On February 20, 2013, about 2006 eastern standard time (EST), a Beechcraft Corporation 390 Premier (Premier IA), N777VG, collided with a utility pole, trees, and terrain following a go around at Thomson-McDuffie County Airport (HQU), Thomson, Georgia. The airline transport-rated pilot and copilot were seriously injured, and the five passengers were fatally injured. The airplane was registered to the Pavilion Group, LLC, and was operated under the provisions of 14 Code of Federal Regulations (CFR) Part 91 as a business flight. Night visual meteorological conditions prevailed, and an instrument flight rules (IFR) flight plan was filed. The flight originated at John C. Tune Airport (JWN), Nashville, Tennessee, about 1827 central standard time (1927 EST).

On the morning of the accident, the pilot and copilot left their respective homes in South Carolina about 0230 for the 1-hour drive to HQU (where the airplane was based) to fly five passengers, who were employees of Vein Guys®, to JWN. (The National Transportation Safety Board [NTSB] notes that while the copilot is referred to as such in this report, his role in the cockpit is not required by federal regulations.) The airplane departed HQU about 0406 and arrived at JWN about 0459. (Although JWN is located in the central time zone, all subsequent times in this report are in EST unless otherwise noted.) Both pilots stated in postaccident interviews that the flight to JWN was uneventful and the weather was good. They reported that at the JWN terminal, they slept in the crew break room, completed paperwork, and worked on the computer. They left for a late lunch about 1500 and returned to the airport about 1630.

According to security camera footage from the JWN terminal, both pilots were observed walking toward the airplane about 1913, and about 1918, the five passengers were seen walking toward the airplane while one crewmember performed an external walk-around inspection. About 1923, the airplane taxied from the parking area and departed JWN at 1927. The pilot was the pilot flying and was in the left cockpit seat.

About 1927, the flight crew contacted departure control while climbing through 3,500 ft mean sea level (msl) and requested an IFR clearance to HQU. About 1930, the flight crew contacted the Memphis air route traffic control center (ARTCC) while climbing through 14,000 ft msl, and about 1933, the flight was cleared to climb and maintain a cruising altitude of flight level (FL) 270. According to flight crew interviews, the en route weather was good, and a tailwind in excess of 70 knots was observed.

About 1948, the flight crew contacted the Atlanta ARTCC and was cleared to descend to FL240. About 1953, the flight crew was given a further descent clearance to 11,000 ft msl along with the Athens, Georgia, altimeter setting. About the same time, the copilot tuned in the HQU automated weather observation system (AWOS) to receive the most current weather at the destination airport. The AWOS at 1935 reported calm wind, temperature 10 degrees C, 10 statute miles visibility or greater, scattered clouds at 12,000 ft, and an altimeter setting of 30.13 inches of mercury. The pilot then set up the flight management guidance system for a visual approach to runway 10 at HQU with a 3.4-degree descent to the runway from a 5-mile final approach. The copilot tuned the instrument landing system for runway 10 as a backup.

About 1956, the flight crew advised the Atlanta ARTCC that they were descending through 18,500 ft, and 2 minutes later, they cancelled their IFR flight plan. About 1958, the copilot stated to the pilot, "ten thousand comin' up captain and you blowin' through." About 1959, the copilot told the pilot to adjust his altimeter. The pilot responded, "say, I'm kinda out of the loop or something. I don't know what happened to me there but I appreciate you lookin' after me there." The flight crew was then directed to contact Augusta approach control, and about 2000, the flight crew contacted Augusta approach control and advised that they were descending out of 8,400 ft and had HQU in sight. About 2002, the flight crew advised Augusta approach control that they would switch to the local HQU advisory frequency.

Concurrently, the pilot began to perform an "S" turn along the final approach path to the runway. About 1 minute later, the enhanced ground proximity warning system (EGPWS) aural alert announced that the airplane was 1,000 ft above the ground, and the pilot lowered the landing gear. According to the cockpit voice recorder (CVR), after the landing gear was lowered, about 2004, the copilot noted that the "ANTI SKID FAIL" annunciator light illuminated. The pilot continued the approach, and, about 2005, the airplane touched down on runway 10. Witnesses reported that after the airplane touched down, they heard or saw it go around. According to the CVR, the takeoff warning horn sounded about 0.3 seconds before the pilot stated that he was performing a go-around. The airplane lifted off near the departure end of the runway. The copilot directed the pilot to increase pitch. According to EGPWS data, as the airplane climbed to an altitude of about 63 ft above the ground, about 9 seconds after liftoff, the left wing struck a utility pole located about 0.25 miles east of the departure end of the runway. The airplane continued about 925 ft before colliding with trees and terrain. It was destroyed by impact forces and a postcrash fire.

During a postaccident interview, when asked about the approach, landing, and go-around at HQU, the pilot recalled checking the airplane's landing light switches to prepare for the landing. The next thing he remembered was waking up in the hospital on February 24, 2013. He did not recall any additional details about the approach, landing, or go-around or any airplane system anomalies, including any antiskid problems, during the flight.

In postaccident interviews, the copilot did not recall anything unusual about the glidepath and recalled being about 1 or 2 knots above reference speed. The copilot thought that the airplane touched down on runway 10 within 200 ft of the 1,000-ft runway marker. As he began to reference the after landing checklist, he heard the pilot announce a go-around, but the copilot did not know the reason for the go-around. He stated that he began to monitor the airspeed indicator, saw that they were at 105 knots approaching the end of the runway, and thought "it was going to be close." The engines sounded like they always did on a normal takeoff. He thought something hit the airplane on his side and recalled seeing trees in the windshield. The next thing he remembered was seeing someone with a flashlight at the accident scene. He did not recall any alarm or aural caution before the go-around and indicated that everything looked normal.

PERSONNEL INFORMATION

The Pilot

The pilot, age 56, held an airline transport pilot (ATP) certificate with a single pilot type rating on the Premier IA. (The 390 Premier is the same as the Premier I/IA series.) He also held a flight instructor certificate with airplane single engine land, airplane multiengine land, and instrument airplane privileges. He was the director of operations for Sky's the Limit, doing business as Executive Shuttle, a 14 CFR Part 135 operator based in Greenwood, South Carolina. He was hired by the Pavilion Group to provide private pilot services for their Premier IA under the provisions of 14 CFR Part 91. The pilot reported 13,319 hours total flying time, including 12,609 hours as pilot-in-command (PIC). He reported 198 hours, all as PIC, in the Premier IA. The pilot held a second-class Federal Aviation Administration (FAA) medical certificate, issued October 29, 2012, with a limitation to possess glasses for near/intermediate vision.

According to interviews and training records, the pilot attended the FlightSafety Premier I Series (RA-390) initial training course at the FlightSafety Wichita Learning Center, Wichita, Kansas, from June 7, 2012, through June 22, 2012. The ground instruction consisted of 58 hours of ground training and 11.5 hours of briefing/debriefing. The pilot also attended flight simulator training, which consisted of 15 hours of simulator training. He was type rated on the Premier IA on June 22, 2012, following a 2.2-hour simulator session and a 2.5-hour oral/written examination.

The pilot also attended the FlightSafety Premier I Series (RA-390) recurrent PIC course at the FlightSafety Greater Philadelphia/Wilmington Learning Center, Wilmington, Delaware, from January 3, 2013, through January 5, 2013. The ground instruction consisted of 12 hours of training and 4.5 hours of briefing/debriefing. The simulator portion of the training consisted of 7 hours of simulator time.

A copilot who previously flew with the pilot stated that the pilot was experienced, professional, and possessed good flying skills. Both copilots who flew with the pilot, including the accident copilot, stated that they did not have a specific role on the flights they flew with him in the Premier IA.

On February 15, the pilot flew the owner of Vein Guys® and his family to Orlando, Florida, and remained in Orlando until Monday, February 18. He did not use a copilot for the Orlando trip. On February 18, he flew the family to HQU and then drove to his residence, going to bed about 2100. On February 19, he awoke about 0500 for a 0930 flight to Olive Branch, Mississippi, with the accident copilot and Vein Guys® staff. The return flight landed at HQU about 1700 that evening. He arrived at his residence about 1820 and went to bed about 2100.

On the day of the accident, the pilot awoke about 0200 and arrived at HQU about 0330 for the 0400 flight to JWN. He described February 20 as a "tough, tough day" because of the early departure time. After arriving at JWN, he slept for about 4 hours in a chair in the pilot lounge. He did not sleep again that day. A review of the pilot's cell phone records revealed three outgoing calls were made during his 4-hour sleep break. The pilot indicated that he normally slept about 8 hours per night and that he typically awoke about 0600.

The Copilot

The copilot, age 40, held an ATP certificate. He possessed no type ratings. He was employed by and flew charters for Executive Shuttle, which was owned by the accident pilot. He accompanied the accident pilot on the Premier IA flights at the pilot's request and estimated that he had about 45 flight hours in the Premier IA. He reported 2,932 hours total time, including 2,613 hours as PIC. The copilot held a second-class FAA medical certificate, issued February 12, 2013, with no limitations.

The copilot received no simulator training in the Premier IA before the accident and did not complete formal training courses in the Premier IA. He received a 14 CFR 61.55 logbook endorsement on October 10, 2012, from the accident pilot, stating that he demonstrated the skill and knowledge required for safe operation of the Premier IA as second-in-command.

On Monday, February 18, the copilot was at home and awoke between 0600 and 0630 and went to bed about 2200. On Tuesday, February 19, he awoke between about 0530 and 0600 and flew with the captain to Olive Branch. After returning to HQU, the copilot made the 1-hour drive to his home but was not certain what time he went to bed or fell asleep. The last cell phone activity that day occurred about 2148. On Wednesday, February 20, the copilot awoke between about 0200 and 0215 and drove with the accident captain to HQU for the flight to JWN. The copilot told investigators he was able to sleep for about 4 to 5 hours in the pilot lounge (awakening about 1000 central time).

AIRCRAFT INFORMATION

The Premier IA was a carbon fiber composite fuselage, metal low-wing airplane powered by two Williams FJ44-2A turbofan engines mounted on the aft fuselage each rated at 2,300 lbs of thrust.

The Premier IA was not equipped with reverse thrust, and wheel braking was the primary means of stopping the airplane after landing. (The lift dump assists in putting weight on the wheels, which makes braking more effective.) The airplane was equipped with an electrically controlled antiskid system. According to the manufacturer, the system offered protection from skids and could provide consistently shorter landing rolls for all runway conditions. The ANTI SKID FAIL annunciator would illuminate if a malfunction existed in the system when the ANTI SKID switch was in the NORM (normal) position.

Activation of the lift dump switch extended the three spoiler panels on each wing and overrode normal spoiler operation. A placard was located on the cockpit pedestal immediately aft of the lift dump switch that read, "WARNING DO NOT EXTEND IN FLIGHT." In addition, the Hawker Beechcraft Premier I/IA Model 390 Airplane Flight Manual (AFM), Section 3A—Abnormal Procedures, page A-25, states, "Do not extend lift dump in flight." Section 3A of the AFM (Abnormal Procedures) included the following warning: "Extending lift dump in flight could result in loss of airplane control leading to airplane damage and injury to personnel. Continued safe flight with lift dump extended has not been demonstrated."

The airframe and engine maintenance logbooks were not located after the accident. Pavilion Group used CAMP Systems as their maintenance management provider, and the Hawker Beechcraft Service Center, Atlanta, Georgia, also provided maintenance services.

The most recent record of maintenance performed on the airplane occurred on January 29, 2013, at Aeronautical Services, Greenwood, South Carolina. The maintenance included replacement of the left and right main tires, touching up exterior paint, and a battery capacity check. The total time on the airplane was not recorded at that time.

The most recent maintenance record indicating aircraft total time was on January 4, 2013, when the airframe total time was 635.4 hours. The most recent comprehensive airframe and engine inspection was recorded on June 15, 2012. The 600-hour Schedule A inspection was accomplished at 503.3 hours total time and 565 total airframe cycles.

METEOROLOGICAL INFORMATION

The National Weather Service (NWS) reported no significant weather and no precipitation over the region. The area forecast applicable for HQU expected light wind and scattered to broken high cirrus clouds, with visibility unrestricted. The NWS also issued an airmen's meteorological information that was current at the time of the accident for moderate turbulence below 8,000 ft over the area.

HQU was equipped with an AWOS that issued observations every 20 minutes. The HQU 1955 observation reported calm wind, visibility 10 miles or greater, sky clear, temperature 9 degrees C, dew point -4 degrees C, and altimeter setting 30.12 inches of mercury. The HQU 2015 observation reported wind from 240 degrees at 6 knots, visibility 10 miles or greater, broken ceiling at 12,000 ft above ground level (agl), temperature 11 degrees C, dew point -3 degrees C, and altimeter setting 30.15 inches of mercury.

AIRPORT INFORMATION

General

HQU was a general aviation airport with one asphalt runway (runway 10-28) measuring 5,503 ft long and 100 ft wide, with precision instrument markings on both ends. The runway had high-intensity runway edge lights that changed from white to amber for the last 2,000 ft in both directions. Both ends had red threshold lights and green approach lights. Adjacent to the touchdown zone for both ends of the runway was a two-unit precision approach path indicator (PAPI) system set at 3 degrees. (As later discussed, following an aeronautical study after the accident, the FAA changed the glidepath angle for the runway 28 PAPI to 3.5 degrees.) Postaccident tests and inspections of the airport lighting systems indicated that the lighting system was operating normally at the time of the tests.

The runway and taxiway lights were pilot-adjustable to low, medium, and high settings and would remain on for 15 minutes after activation. The PAPIs would not activate when the runway lights were set to the low setting. A City of Thomson administrator managed the airport with the help of an on-site airport manager who also managed a local fixed base operation (Spirit Aviation). The airport manager did not prepare or keep any logs about airport self-inspections, regular maintenance, wildlife strikes, lighting activation, or periodic inspection/calibration of the PAPI units. According to the airport manager, a local electrical contractor accomplished all preventative and repair work on the airport's lights and navigational aids on an as needed basis. After the accident, the airport began keeping weekly logs of lighting outages, maintenance, and general field conditions.

The Georgia Department of Transportation (GDOT) inspected HQU biennially to ensure compliance with the requirements set out in GDOT's Rules and Regulations for Licensing of Certain Open-to-the-Public Airports. The GDOT inspections also included an airport inspection for the FAA's Airport Safety Data Program. The two most recent inspection reports from 2010 and 2012 determined that HQU met the minimum state licensing requirements but failed to meet federal requirements for precision and visual approaches. Specifically, runway 10 failed to meet FAA Part 77 reporting requirements for a 50:1 obstruction-free, precision instrument approach to 200 ft from the runway end. Similarly, runway 28 failed to meet the FAA Part 77 reporting requirements for a 34:1 obstruction-free, nonprecision instrument approach to 200 ft from the runway end. The obstructions listed for both approaches were trees, left and right of centerline. The 2012 inspection report for the runway 28 approach included an obstruction characterized as a power line, 66 ft high, and 2,200 ft from the displaced threshold, extending from the centerline to 400 ft right of centerline, which provided a 27:1 approach to 200 ft from the runway end and a 33:1 approach to the displaced threshold.

The Thomson city administrator stated that before 2012, no GDOT inspection report had identified the power line east of the airport as a potential obstruction. To determine whether the power line was an obstruction and to provide data in support of an official airport layout plan, the city administrator authorized a formal survey of the airport. The survey had not been completed at the time of the accident or at the time of this report.

Airport Obstructions

During the accident sequence, the airplane struck a concrete electrical utility pole (Pole 48) that was about 1,835 ft east of the runway 28 threshold and 50 ft left of the extended runway centerline. Pole 48 was 72 ft high, and the airplane struck the pole about 58 ft agl. The pole was not equipped with lights, but orange visibility balls were on the adjacent wires.

The pole was owned and maintained by Georgia Power, a regional utility that supplied electric power to local businesses and residents. Pole 48 was erected in 1989, along with similar poles and electrical utility lines, to provide electrical power to the Milliken and Company textile plant adjacent to HQU. Thomson McDuffie County entered into an "aviation easement" agreement with Deering Milliken, the owner of the Milliken Kingsley textile factory adjacent to HQU, in September 1973. The provisions of the easement were designed to protect the approach surface east of the airport. The text of the easement stated that Deering Milliken "…will not hereafter erect or permit the erection or growth of any structure, trees, or other object within or upon said parcel, which lies within the approach area of the 9-27 [now 10-28] runway to a height above the approach surface. Said approach surface being an inclined plane with a slope of 34:1, i.e. one ft of elevation for each 34 ft of horizontal distance, located directly over the center of said parcel." Milliken and Company entered into easement agreements with Georgia Power in May 1977 and again in August 1989 to grant the right to construct, erect, install, operate, and maintain "poles, wires, transformers, service pedestals, and other necessary apparatus" to supply electrical power to the Milliken Kingsley textile plant.

Title 14 CFR Part 77 establishes standards for approach surfaces to runways of various types and requires notice to the FAA of any proposed construction or alteration of existing structures that may affect the national airspace system. FAA Advisory Circular 70-7460-1K, "Obstruction Marking and Lighting," provides guidance on compliance with 14 CFR Part 77 and procedures for notifying the FAA of proposed construction or alteration. Specifically, a Notice of Proposed Construction or Alteration Form (FAA Form 7460-1) is required for notification. Upon receipt of Form 7460-1, the FAA will conduct an aeronautical study to determine the effects of the construction or alteration on navigable airspace. Then, the FAA will determine if the construction or alteration constitutes a hazard to air navigation.

Georgia Power did not notify the FAA before constructing the utility poles in 1989; therefore, the FAA had no knowledge of the poles as potential obstructions. Accordingly, there were no depictions or mention of possible obstructions on associated aeronautical charts.

After the accident, Georgia Power submitted FAA Forms 7460-1 for four utility poles east of the airport, including Pole 48. The FAA conducted aeronautical studies on the poles and, on May 31, 2013, issued initial findings from the studies. Regarding Pole 48, the FAA determined in its initial findings that "…the structure as described exceeds obstruction standards and/or would have an adverse physical or electromagnetic interference effect upon navigable airspace or air navigation facilities. Pending resolution of the issues described below, the structure is presumed to be a hazard to air navigation." The study also stated that if the pole were lowered to a height of 46 ft or less it would not exceed obstruction standards, and a favorable determination could subsequently be issued. The FAA reported similar findings on the other three structures. The FAA stated in its findings that to pursue a favorable determination at the originally submitted height, further study would be necessary, and a formal request would be required within 60 days.

After the FAA issued the preliminary obstruction determinations, Georgia Power requested that the FAA conduct further study on the four obstructions to determine if a favorable determination could be achieved. On August 12, 2013, the FAA published public notices announcing the four aeronautical studies and invited interested parties to submit relevant comments before September 18, 2013. According to an FAA official, the final determinations for the four obstructions were not completed at the time of this report. Since the aeronautical studies were conducted, the FAA Flight Data Center issued several notices to airmen to alert pilots about obstructions and also to amend the approach and departure procedures at HQU accordingly. In addition, the FAA increased the glideslope angle for the runway 28 PAPI from 3.00 to 3.50 degrees.

FLIGHT RECORDERS

Although not required, the airplane was equipped with an L-3/Fairchild FA2100-1010 CVR. The CVR recording contained the last 30 minutes of digital audio, which was stored in solid-state memory modules. The CVR sustained significant heat and structural damage as a result of the accident. Despite the damage to the unit, three channels of recorded audio were available, ranging from good to excellent quality. The recording began at 1935:13 as the flight was at FL240, and the recording stopped about 2006 during the crash sequence. The airplane was not equipped with a flight data recorder, nor was it required to be so equipped.

WRECKAGE AND IMPACT INFORMATION

The airplane struck Pole 48, and sections of the pole and attached power lines were found along the wreckage debris path, which was oriented from west to east on an approximate magnetic heading of 085 degrees. The left wing was completely severed about 13 ft inboard from the wing tip and exhibited no fire damage. The severed wing was located about 320 ft east of Pole 48.

Various fragments of the airplane structure were found along the debris path leading to the main wreckage site, which was located about 925 ft east of Pole 48. Multiple trees, up to 2 ft in diameter, were severed or toppled in the main wreckage impact zone. The main wreckage consisted of the center wing section, a portion of the right wing, the main landing gear, the baggage compartment, the emergency locator transmitter rack, and the empennage. The main wreckage was damaged by a postcrash fire and contained melted aluminum and burnt composite material. The forward fuselage was about 60 ft east of the main wreckage and was damaged by a postcrash fire.

The right engine was separated from the fuselage and was on the south side of the debris path between the main wreckage and the forward fuselage shell. The left engine was severed into two main sections with the compressor and the turbine and exhaust section located in a shallow pond on the north side of the debris path. A large portion of the ground in the vicinity of the accident site was charred and burned by a postcrash fire.

All three landing gear assemblies were located on scene. The left and right main landing gear actuators separated from the landing gear but remained attached to the wing structure. Measurements of the actuator positions, as found, corresponded to the "gear extended" or "down" position.

An examination of the nose landing gear actuator piston revealed that its extension was at an intermediate position. The nose landing gear had an external downlock mechanism to secure the gear in the down-and-locked position. The mating side of the external downlock mechanism was not observed and therefore precluded determination of the position of the nose landing gear. Fire and impact damage to the antiskid system components (antiskid control unit, power brake/antiskid control valve, and wheel speed transducers) prevented their functional testing.

The wreckage was transported to a storage facility where additional examinations of the wreckage were performed. The landing gear switch, which was cockpit-mounted, was found with the instrument subpanel attached to electrical wire. The switch exhibited heat and thermal damage consistent with a postcrash fire. The metal part of the switch handle was found in the down (extended) detent, and the J-hook was engaged on the handle. The lift dump switch assembly, which was mounted on the cockpit center console, was not located.

The electrically controlled and operated wing flap system was examined. The four flap positions available to the pilot were UP (0 degrees), 10, 20, and DN (30 degrees/full down). While the flap handle was found in the 10-degree detent, measurements of the flap actuator positions revealed that the flaps were at approximately the 15-degree position (a nonselectable, in-transit position) at the time of impact.

MEDICAL AND PATHOLOGICAL INFORMATION

Both the pilot and copilot sustained serious injuries. Drug and alcohol testing on the pilot and copilot was conducted by the FAA Civil Aerospace Medical Institute after the accident. Toxicology results were negative for both pilots on a wide range of drugs, including major drugs of abuse.

The Georgia Bureau of Investigation Division of Forensic Science listed the cause of death for all passengers as blunt force injuries.

SURVIVAL ASPECTS

The pilot's seat was found with the seatback and seat pan cushions attached to the frame, which was severely damaged with broken tubes in the seatback and seat bottom. The upper shoulder area of the seat was crushed forward and to the right. The seat, which was located near the remains of the cockpit, appeared to be forcefully detached from the cockpit floor track rails with small floor track pieces attached to the seat post. First responders removed the pilot from his 4-point restraint by cutting the belt webbing.

The copilot's seat was found attached to the floor structure in the remains of the cockpit. The seatback, seat pan cushions, and the 4-point restraint were consumed by the postcrash fire. The seat frame was severely damaged with broken tubes in the seatback and seat bottom. First responders found the copilot out of his seat and walking along an access road near the main wreckage area.

All six passenger seats were found scattered among the wreckage and were detached from the airplane floor structure. The seat backs and bottoms of all seats exhibited severe damage, including breakage of the structural tubing framework. The restraint systems on the passenger seats were attached to their respective seat frames, and all six buckles were unlatched. The belt webbing was intact on three of the seats, and the remaining three passenger seat restraints were consumed by fire. One of the six shoulder harnesses was found attached to the lap portion of the female buckle. The other five shoulder harnesses were found retracted in the seatback frame. None of the six passenger seat belt buckles or associated fittings were damaged.

TESTS AND RESEARCH

Enhanced Ground Proximity Warning System

The airplane was equipped with a Honeywell Mark V EGPWS. The nonvolatile memory (NVM) was downloaded, and, by design, the EGPWS recorded airplane performance data based on a parameter exceedance, which was, in this event, an excessive bank angle, most likely the result of the separation of the left wing after impact with Pole 48. The unit captured the data during the 20 seconds before the exceedance. The unit was designed to record for 10 seconds after the exceedance; however, only 2 seconds were recorded because electrical power to the unit ceased during the crash sequence.

The data indicated that during the go-around attempt, the airplane lifted off near the departure end of runway 10 (consistent with the copilot's statement). Per the EGPWS data, the landing gear remained in the down position until impact. The calibrated airspeed was about 125 knots when the airplane lifted off. The airplane continued straight ahead and slowly accelerated and gradually climbed, until a rapid pitch up was recorded, from 10.5 to 27.4 degrees within 1 second. One second later, the roll increased from 2.1 degrees left to 71.7 degrees left.

The first data recorded by the EGPWS showed that the airplane was configured at flaps 30. The flaps were transitioning through flaps 15 at the time of impact.

Engines

During postaccident examination, the No. 1 (left) engine exhibited extensive impact deformation and was split at the interstage case flange, aft of the axial low pressure compressor (LPC). The fan blades exhibited tip bending opposite the direction of rotation, and the low pressure turbine (LPT) shaft was twisted consistent with a sudden stoppage due to impact.

The No. 2 (right) engine was intact; however, some components, including the LPC, high pressure compressor, high pressure turbine, and LPT all exhibited blade tip rubs with corresponding case rubs. The accessory gearbox tower shaft was sheared, and damage consistent with impact was noted to the fuel pump, oil lube, and scavenge pump.

Wing Spoiler System Actuators

Examination and disassembly of the lift dump actuators revealed that one unit was 0.457 inch from full extension (panel extended), and the other unit was 0.221 inch from full extension. A determination of left or right could not be made due to fire and impact damage.

Examination and disassembly of the left blow-down actuator revealed that the unit was seized at the fully extended position. Damage to the clevis at the end of the actuator was consistent with the roll/speedbrake/spoiler panel in the fully extended position at impact. The right blow-down actuator had minimal damage and was fully functional when tested. Its position at impact could not be determined.

Examination and disassembly of the left roll control actuator revealed that the unit was 0.022 inch from the fully extended position. The right roll control actuator had minimal damage and was found to be fully functional when tested. Its position at impact was 0.201 inch from the fully extended position.

Spoiler Control Unit

The spoiler control unit (SCU) interfaced with the hydraulics and controlled hydraulic actuation of the six spoiler panels across the wings. The SCU was responsible for providing surface position commands and monitoring hydraulic components for malfunction detection and protection.

Exterior examination of the SCU revealed major fire and impact damage to the unit's housing. The bit and diagnostic card was also fire damaged. The data on the NVM chip were downloaded but were inconclusive; therefore, a determination of the actuation of the spoilers before and during the accident could not be made based on SCU data.

Flight Management Computer (FMC-3000)

The airplane was equipped with a Rockwell Collins FMC-3000 flight management computer. The unit was tested and operated normally on a test bench. NVM analysis indicated that no internal faults occurred on the FMC-3000 near the time of accident.

Air Data Computers (ADC-3000)

The airplane was equipped with two Rockwell Collins ADC-3000 air data computers (ADC). Examination revealed that the mounts on both ADCs were damaged from impact, indicative of forces during impact in excess of 20g. Both units operated normally on a test bench. The first unit showed a final power cycle with weight coming off wheels at 4 minutes after power on and weight on wheels again at 44 minutes after power on. Following the weight on wheels, within the 44th minute after power on, 3 faults were indicated in the NVM. In order, they were for a faulty Ps (static pressure) counter, a faulty Qc (impact pressure) counter, and an unexpected interruption. According to Rockwell Collins, these faults were most likely due to extreme acceleration causing electrical connections between the circuit cards within the ADC to fail. The second unit showed a final power cycle with weight coming off wheels at 4 minutes after power on and a return to weight on wheels at 44 minutes after power on. No faults were observed in the NVM.

Airplane Performance Study

The NTSB produced an airplane performance study of the landing and go-around phases of the accident flight largely based on information from the CVR and the EGPWS, as well as the physical evidence documented at the accident site. To attain the unfactored landing distance performance numbers contained in the AFM, the following conditions had to be met: thrust as required to maintain a 3-degree approach angle, retarding thrust to idle at 50 ft agl; approach speed at VREF; flaps down; antiskid normal; maximum braking; and lift dump extended after touchdown.

Beechcraft calculated stopping performance for several scenarios related to the accident flight. Beechcraft indicated that with the estimated stopping distance for the accident airplane with no antiskid system operative and the lowest braking action recorded during the flight test, the airplane would require about 1,560 ft to stop from the first speed recorded by the EGPWS (83 kts). This estimate decreases to 1,350 ft when moderate braking is applied. Based on EGPWS data, after touching down, the pilot did not stop the airplane within the first 2,900 ft beyond the runway 10 threshold and initiated a go-around with more than 2,400 ft of hard surface remaining; the first speed was recorded at this point. (The actual touchdown point was not recorded and could not be determined.) The wreckage examination, as well as drag estimates based on recovered EGPWS data, indicated that the lift dump remained extended during the go-around attempt. The airplane drag associated with the lift dump, flaps, and landing gear extended resulted in only marginal climb performance.

ORGANIZATIONAL AND MANAGEMENT INFORMATION

According to its website, Vein Guys® was a group of four physicians that operated several vein care centers in the southeastern United States, with offices in Augusta, Georgia; Atlanta, Georgia; Nashville, Tennessee; and Raleigh, North Carolina. According to interviews, the Pavilion Group was a subsidiary established by the owners of Vein Guys® to handle all business activities associated with the ownership and operation of its private airplane, which it used to shuttle physicians and staff between their offices in Georgia, Tennessee, and North Carolina and also for private flights to vacation destinations.

Before owning the accident airplane, the Pavilion Group owned a King Air 300 (N401BL) and used the pilot services of Executive Shuttle (owned by the accident pilot). The Pavilion Group sold the King Air and, in June 2012, purchased the accident airplane and continued to use the pilot services of Executive Shuttle. The Pavilion Group's airplanes were operated under the provisions of 14 CFR Part 91. According to the accident pilot, the Pavilion Group paid for the pilot's initial and recurrent Premier IA ground and simulator training at FlightSafety. Although Executive Shuttle operated as Sky's the Limit, a 14 CFR Part 135 certificate holder, the pilot stated in interviews that there was no signed contract between Executive Shuttle and the Pavilion Group (or Vein Guys®) for pilot services on the Pavilion Group's airplane, and all Premier IA flights Executive Shuttle operated for the Pavilion Group were conducted under 14 CFR Part 91.

ADDITIONAL INFORMATION

Takeoff Warning System

The airplane was equipped with a takeoff configuration warning system that provided an automatic aural warning to the flight crew during the initial portion of takeoff if the airplane was in a configuration that would not allow for a safe takeoff. The aural warning would continue until the airplane's configuration was changed to allow for safe takeoff, until action was taken by the pilot to abandon the takeoff roll, or until weight was off of the wheels. If either lift dump surface was not retracted, the speed brake/lift dump lever sensors were in the extended range, either flap position was greater than 22 degrees, or the pitch trim was outside of a predetermined range for takeoff, the aural warning would activate in the cockpit.

Antiskid System Failure and Pilot's Corrective Action

Pilots receiving training at FlightSafety on the Premier IA were taught to use the FAA approved Abbreviated Pilot Checklist to handle system malfunctions. A failure of the antiskid system was included in the Abnormal Procedures section of the checklist. According to the checklist, the pilot should move the antiskid switch to OFF and plan for a flaps 10 or flaps up landing. The antiskid failure procedure also provided a note stating that landing distance would increase about 130 percent with flaps up and 89 percent with flaps 10.

According to the Antiskid Failure Checklist (which is within the Abbreviated Pilot Checklist), the pilot was required to account for the loss of the antiskid system by applying a performance penalty to the normal landing distance, depending on the flap setting selected (flaps 10 or flaps up). Using weather conditions that prevailed at HQU at the time of the accident, the required landing distance with flaps up was 7,066 ft, and the required landing distance with flaps 10 was 5,806 ft. HQU runway 10's available runway length for landing was 5,208 ft, which did not meet the flaps up or flaps 10 performance penalty requirements, and a diversion to a longer runway would have been required. The Premier IA AFM Antiskid Fail procedure included a note that stated, "Use of flaps 20 or DN (30) for landing, with anti-skid failed, is prohibited."

The simulator instructor who provided the pilot's initial training stated in a postaccident interview that he would expect the pilot to use the written checklist for a systems failure, determine the proper flap setting for landing, and then apply the performance penalty for the landing, adding that the Antiskid Failure Checklist emphasized that the landing must be made with only flaps 10 or UP. According to the pilot's FlightSafety training records, he received antiskid system failure training during his recurrent simulator training on January 4, 2013.

On June 17, 2013, both pilots listened to the CVR recording for the accident flight, and according to subsequent interviews, neither pilot recalled seeing the ANTI SKID FAIL annunciator light illuminated on the approach. According to interviews with both pilots and a review of the CVR recording, the ANTI SKID FAIL abnormal checklist as outlined in the Abbreviated Pilot Checklist for the Premier IA was not conducted by the accident crew before landing at HQU. Further, the pilot stated that he did not think they needed the antiskid system on the landing at HQU and said the performance penalty would only apply if you were "trying to make your numbers" in the book made by the test pilots by applying maximum braking.

Balked Landing/Go-Around

According to recorded data and witness statements, the flight crew attempted a go-around after landing at HQU. The pilot did not recall the event during interviews, while the copilot stated that they conducted a go-around after the airplane touched down. Procedures for the Premier IA (AFM and Pilot Checklist) referred to the discontinuation of a landing approach as a "balked landing."

According to the FAA's Airplane Flying Handbook (FAA-H-8083, page G-2), a balked landing was synonymous with a go-around. Per the FAA Pilot/Controller Glossary, a go around was a situation when a pilot abandons his/her approach to land. The Airplane Flying Handbook (chapter 8), "Approaches and Landings," states the following: "The go around is not strictly an emergency procedure. It is a normal maneuver that may at times be used in an emergency situation.…Although the need to discontinue a landing may arise at any point in the landing process, the most critical go-around will be one started when very close to the ground. Therefore, the earlier a condition that warrants a go-around is recognized, the safer the go around/rejected landing will be."

According to the FAA's Aeronautical Information Manual (page PCG T-4), a touchdown was the point at which an aircraft first made contact with the landing surfaces. The Airplane Flying Handbook (FAA-H-8083-3A, page 8-7) explained that the landing process was not over until the airplane decelerated to a normal taxi speed or came to a complete stop. The FAA indicated in its May 14, 2013, response to NTSB Information Request 13-267 that a pilot may execute a balked landing/go-around if he/she determined that, after first contact with the landing surface, positive control had not been maintained or if continuing the landing process may expose the aircraft to unsafe conditions such as an unexpected appearance of hazards on the runway.

FlightSafety Premier IA instructors and evaluators in Wichita, Kansas, and Wilmington, Delaware, stated during postaccident interviews that a balked landing was an airborne maneuver typically taught to be performed at an altitude of 50 ft on the approach, and Premier pilots were not taught to execute a balked landing in the Premier IA following touchdown on the runway. The FlightSafety instructors and evaluators also stated that they discouraged students from executing a balked landing after touchdown. Beechcraft Premier IA manuals and FlightSafety training guidance for the Premier IA do not contain language prohibiting a balked landing procedure after touchdown.

The pilot told investigators that he did not recall if anyone at FlightSafety told him not to conduct a go-around or balked landing after touching down during his training. The pilot also stated that the only balked landings he conducted in training were while airborne. When asked by investigators if he recalled anyone at FlightSafety telling him not to conduct a go-around or balked landing after touching down, the pilot said "no." The pilot further stated that a balked landing was something that occurred in the air, and on the ground it was called a "touch and go." The pilot did not remember ever doing a touch and-go in the simulator and had never done one in a Premier.

On March 29, 2011, the NTSB issued Safety Recommendation A-11-18, asking the FAA to "require manufacturers of newly certificated and in-service turbine-powered aircraft to incorporate in their Aircraft Flight Manuals a committed-to-stop point in the landing sequence (for example, in the case of the Hawker Beechcraft 125-800A airplane, once lift dump is deployed) beyond which a go-around should not be attempted." On June 10, 2013, the FAA indicated that it was impractical to fully implement the recommendation but that it would address the NTSB's concerns by issuing an Information for Operators (InFO). Pending the issuance of the InFO and the NTSB's review of an acceptable plan of action to ensure that all operators incorporate the guidance, the NTSB classified Safety Recommendation A-11-18 "Open—Acceptable Alternate Response."
