Bell 429 GlobalRanger, registered to and operated by a private individual, N598PB: Fatal accident occurred February 15, 2017 in Shreveport, Louisiana

Terry Glenn Bailey, 54, and Pamela Hitt Bailey, 57, of Center, Texas, passed away together in a helicopter accident on February 15th, 2017.




The National Transportation Safety Board traveled to the scene of this accident.

Additional Participating Entities:

Federal Aviation Administration / Flight Standards District Office; Baton Rouge, Louisiana
Federal Aviation Administration AVP-100; Washington, District of Columbia
Federal Aviation Administration Rotorcraft Directorate; Dallas, Texas

Aviation Accident Factual Report - National Transportation Safety Board: https://app.ntsb.gov/pdf

Investigation Docket - National Transportation Safety Board: https://dms.ntsb.gov/pubdms


http://registry.faa.gov/N598PB




Location: Shreveport, LA
Accident Number: CEN17FA103
Date & Time: 02/15/2017, 0023 CST
Registration: N598PB
Aircraft: BELL HELICOPTER TEXTRON CANADA 429
Aircraft Damage: Substantial
Defining Event: Controlled flight into terr/obj (CFIT)
Injuries: 2 Fatal
Flight Conducted Under: Part 91: General Aviation - Personal

On February 15, 2017, at 0023 central standard time, a Bell 429 helicopter, N598PB, impacted terrain and water at Wallace Lake near Shreveport, Louisiana. The private rated pilot and passenger were both fatally injured. The helicopter was substantially damaged. The helicopter was registered to and operated by a private individual under the provisions of 14 Code of Federal Regulations Part 91 as a personal flight. Dark night instrument meteorological conditions (IMC) prevailed for the flight, which operated without a flight plan. The flight originated from a field in Bossier City, Louisiana, and was en route to Center Municipal Airport (F17), Center, Texas.

The helicopter was in contact with air traffic control. When the helicopter disappeared from radar unexpectedly and did not respond to radio communications, it was the subject of an alert notice and was located on the afternoon of February 15. The wreckage was located at the southern end of Wallace Lake.


Terry and Pam Bailey

Pilot Information

Certificate: Private
Age: 54, Male
Airplane Rating(s): Multi-engine Land; Single-engine Land
Seat Occupied: Right
Other Aircraft Rating(s): Helicopter
Restraint Used:
Instrument Rating(s): Airplane
Second Pilot Present: No
Instructor Rating(s): None
Toxicology Performed: Yes
Medical Certification: Class 3 With Waivers/Limitations
Last FAA Medical Exam: 05/26/2015
Occupational Pilot: No
Last Flight Review or Equivalent:
Flight Time:  (Estimated) 900 hours (Total, all aircraft), 30 hours (Total, this make and model)

The pilot held a private pilot certificate with ratings for helicopter, airplane single-engine land, multi-engine land, and instrument airplane. His log books were not recovered during the investigation and the pilot's total time, and night experience is not known. While the pilot held a rating for instrument airplane, it is not known how much training the pilot obtained, if any, for an instrument helicopter rating.

On May 26, 2015, the pilot was issued a third-class medical certificate with the limitation that he "must wear correct lenses for near and distant vision." He reported no medication use.

The pilot attended the Bell Training Academy at the end of October 2016. During his training, he logged 9.2 hours of flight instruction of the Bell 429 to include operation of the auto pilot. In addition, he logged 5.2 hours of flight instruction in a flight training device which included Auto Pilot Operation, use of the on-board flight planning devices, and inadvertent flight into IMC. All maneuvers performed were evaluated to the Federal Aviation Administration (FAA) Practical Test Standards Test tolerances.

Aircraft and Owner/Operator Information

Aircraft Make: BELL HELICOPTER TEXTRON CANADA
Registration: N598PB
Model/Series: 429 NO SERIES
Aircraft Category: Helicopter
Year of Manufacture: 2014
Amateur Built: No
Airworthiness Certificate: Normal
Serial Number: 57249
Landing Gear Type: Skid
Seats: 5
Date/Type of Last Inspection: 10/27/2016, Annual
Certified Max Gross Wt.:
Time Since Last Inspection: 18 Hours
Engines: 2 Turbo Shaft
Airframe Total Time: 30 Hours at time of accident
Engine Manufacturer: P&W CANADA
ELT:  C126 installed, not activated
Engine Model/Series: PW207D1
Registered Owner: BAILEY TERRY
Rated Power: 710 hp
Operator: On file
Operating Certificate(s) Held: None

The Bell 429 intermediate helicopter is an eight-seat twin engine, Category A, single pilot IFR certified rotorcraft. It is equipped with autopilot and force trim systems. The force trim system uses a spring force to hold the flight controls to a detent position. The detent position can be moved anywhere in the control range by either releasing the fight control from the spring mechanism and re-engaging it in a different position, or by driving it to a new position using a motorized actuator. The pilot can also fly the controls without releasing the force trim, but in this case the pilot must work against the spring force to make control inputs. Force trim is required for the autopilot to couple to the flight director.

Complete maintenance logbooks were not recovered. Of the records located, a listing of scheduled maintenance inspections completed on October 31, 2016, reported the helicopter had accrued 12.1 total hours. The last annual inspection was performed on October 27, 2016, at a total time of 10.0 hours.

The pilot purchased the helicopter on July 1, 2016. The helicopter had accrued approximately 30 hours.



Meteorological Information and Flight Plan

Conditions at Accident Site: Instrument Conditions
Condition of Light: Night/Dark
Observation Facility, Elevation: KSHV, 259 ft msl
Distance from Accident Site: 10 Nautical Miles
Observation Time: 1249 CST
Direction from Accident Site: 324°
Lowest Cloud Condition: Thin Broken / 1000 ft agl
Visibility:  7 Miles
Lowest Ceiling: Broken / 1000 ft agl
Visibility (RVR):
Wind Speed/Gusts: 9 knots /
Turbulence Type Forecast/Actual: /
Wind Direction: 320°
Turbulence Severity Forecast/Actual: /
Altimeter Setting: 29.93 inches Hg
Temperature/Dew Point: 8°C / 7°C
Precipitation and Obscuration: No Obscuration; No Precipitation
Departure Point: Bossier City, LA
Type of Flight Plan Filed: None
Destination: Center, TX (F17)
Type of Clearance: None
Departure Time:
Type of Airspace:

A weather study was conducted by a National Transportation Safety Board (NTSB) Meteorologist. At 2356, an automated weather reporting station located at Shreveport Municipal Airport (KSHV), Shreveport, Louisiana, 10 nautical miles north of the accident site, reported wind from 320° at 11 knots, visibility 4 statute miles with light drizzle and mist, a broken ceiling at 700 ft, overcast at 1,300 ft, temperature 45° F, dew point 45° F, and a barometric pressure of 29.93 inches. There was a remark that drizzle began at 2251, and the ceiling varied between 500 ft and 900 ft.

At 0049, the same station reported a wind from 320° at 9 knots, visibility 7 miles, a broken ceiling at 1,000 ft, overcast at 1,400 ft. There was a remark that drizzle ended at 0047.

A review of data from the closest National Weather Service Surveillance Radar-1988, Doppler, located at KSHV, found that near the accident site at the accident time, conditions were conducive for IMC and drizzle. There were no lightning strikes around the accident site at the accident time.

Two Airmen's Meteorological Information (AIRMET) were issued at 2045 CST on February 14, for forecasted instrument flight rules (IFR) conditions due to precipitation and mist, and possible moderate turbulence below 8,000 ft. Both AIRMETs were valid until 0900 on February 15.

The phase of the Moon was waning gibbous with 78% of the Moon's visible disk illuminated. With the extensive cloud cover above the accident site at the accident time, the Moon would not have been visible.

A search of official weather briefings sources did not locate a pilot's request for weather prior to the accident flight.

The complete weather study report is located in the docket of this report.

Wreckage and Impact Information

Crew Injuries: 1 Fatal
Aircraft Damage: Substantial
Passenger Injuries: 1 Fatal
Aircraft Fire: On-Ground
Ground Injuries: N/A
Aircraft Explosion: None
Total Injuries: 2 Fatal
Latitude, Longitude: 32.311389, -93.705556

Damage to several trees and a large crater were consistent with the helicopter's impact with terrain. The debris field fanned out about 20° either side of a 320° magnetic heading for about 80 yards in a marshy area of Wallace Lake. There was evidence of a post-impact fire in the debris field. The helicopter was fragmented in multiple location and scattered throughout the debris field. The main wreckage consisted of the fuselage and main rotor hub which came to rest near the end of the debris field.

The helicopter was removed from the marsh and transported to the shore for documentation and examination. The examination did not reveal any preimpact anomalies with the helicopter. The helicopter's display unit (DU) retains non-volatile memory and was sent to Bell Helicopter, Fort Worth, Texas, for download.



Display Unit Download

Under the auspices of the NTSB and Federal Aviation Administration (FAA), the DU was downloaded and the information plotted. A review of the information revealed that the helicopter lifted off and departed a field near the Horseshoe Casino, Bossier City, Louisiana, at 0015. The helicopter departed to the southwest and then flew near the Red River, as it headed to the southeast, and maintained an altitude between 800 to 1,000 ft mean sea level (msl). At 0019, the helicopter made a right turn and flew to the southwest. As the helicopter tracked southwest on a 230° heading, the altitude dropped to about 600 ft msl or 500 ft above ground level (agl). At 0022, the helicopter turned 30° bank left turn. The helicopter descended in the turn to about 420 ft agl, before it pitched up to 40° nose high, resulting in 2,500 ft per minute (fpm) climb to 1,470 msl (1,386 agl). The helicopter momentarily stabilized on a 055° heading. At 0023:00 then exceeded a 45° left bank and the pitch exceeded 40° nose low. The time of the last capture was 0023:13, with the helicopter traveling 167 knots and descending more than 8,800 fpm. Control inputs were performed by the pilot up to and including the last capture.

During the flight, no problems with airframe or engine control inputs were detected. Data captured revealed that the pilot flew a majority of the accident with the Force Trim off. He also did not select any flight director modes. At 0022:46 (27 seconds prior to impact), the pilot armed the airspeed hold mode. The pilot's action would have presented him flight director commands, but due to the Force Trim being off, the autopilot could not engage to hold this mode. At 0022:56 (18 seconds prior to impact), the pilot turned on the Force Trim. However, the pilot did not reselect an attitude mode for the autopilot to engage to a mode. The manufacturer recommends turning on Force Trim shortly after takeoff.

Communications

About 0017, an air traffic controller from KSHV contacted the pilot since the helicopter had entered Class C airspace. The controller informed the pilot of the Class C airspace and the pilot proceeded on course to F17. No radar services were provided, and no distress call was recorded.

Medical And Pathological Information

Due to the condition of the remains, the De Soto Parish Coroner's Office, Mansfield, Louisiana, was not able to perform an autopsy.

The FAA's Bioaeronautical Sciences Research Laboratory, Oklahoma City, Oklahoma, performed toxicology testing on samples from the pilot. Testing was negative for ethanol. Testing detected amphetamine, dihydrododeine, nordiazepam, oxazepam, and temazepam.

Amphetamine is a Schedule II controlled substance available by prescription that stimulates the central nervous system available by prescription for the treatment of attention deficit disorder (ADD) and narcolepsy. Dihydrocodeine is an active metabolite of hydrocodone, a Schedule II opioid medication.

According to records obtained from the pilot's primary care physician, he had a longstanding diagnosis of attention deficit disorder and had been treated with Vyvanse since before April 2015, (the first available visit record). He also had a history of joint pain for which he intermittently used hydrocodone. In 2015, he had an obstructing kidney stone and had been given a prescription for diazepam. His last visit was on January 24, 2017, for a review of his attention deficit disorder and mildly elevated blood pressure. No comment was made in the physician's record regarding any symptoms from the ADD or the effectiveness of the medication.

Additional Information

Spatial Disorientation

The FAA Pilot's Handbook of Aeronautical Knowledge, chapter 16, "Aeromedical Factors," stated, "Under normal flight conditions, when there is a visual reference to the horizon and ground, the sensory system in the inner ear helps to identify the pitch, roll, and yaw movements of the aircraft. When visual contact with the horizon is lost, the vestibular system becomes unreliable. Without visual references outside the aircraft, there are many situations in which normal motions and forces create convincing illusions that are difficult to overcome…Unless a pilot has many hours of training in instrument flight, flight should be avoided in reduced visibility or at night when the horizon is not visible. A pilot can reduce susceptibility to disorienting illusions through training and awareness and learning to rely totally on flight instruments."

At the time of this report's creation, the FAA's Helicopter Flying Handbook, FAA-H-8083-21A, dated 2017, does not contain a section on spatial disorientation.

Inadvertent Entry into IMC

The FAA's Helicopter Flying Handbook, FAA-H-8083-21A, dated 2017, chapter 12, page 4, states, "Deteriorating weather is even harder to detect at night…". In addition, 5 basic steps "that every pilot should be ultimately familiar with and should be executed immediately after inadvertently entering IMC.

1. Attitude—level the wings on the attitude indicator, both pitch and bank.
2. Heading—pick a heading that is known to be free of obstacles and maintain it. This may be 180° from your current heading.
3. Power—adjust to a climb power setting.
4. Airspeed—adjust to a climb airspeed.
5. Trim—maintain coordinated flight so that an unusual attitude will not develop.

Workload Management

The FAA's Helicopter Flying Handbook, FAA-H-8083-21A, dated 2017, chapter 14, "Effective Aeronautical Decision-Making," states, "Another important part of managing workload is recognizing a work overload situation. The first effect of high workload is that a pilot begins to work faster. As workload increases, attention cannot be devoted to several tasks at one time, and a pilot may begin to focus on one item. When a pilot becomes task saturated, there is no awareness of additional inputs from various sources, so decisions may be made on incomplete information, and the possibility of error increases. A very good example of this is inadvertent IMC. Once entering into bad weather, work overload becomes immediate. Mentally, the pilot must transition from flying outside of the aircraft to flying inside the aircraft. Losing all visual references can cause sensory overload and the ability to think rationally is gone. Instead of trusting the aircrafts instruments, pilots try to hang on to the little visual references that they have and forget all about the other factors surrounding them. Instead of slowing the helicopter down they increase airspeed. Because they are looking down for visual references they forget about the hazards in front of them and finally, because they are not looking at the flight instruments, the aircraft is not level. All of this can be avoided by proper training and proper planning. If going inadvertent IMC is your only course of action, pilots must commit to it and fly the helicopter using only the flight instruments and not trying to follow what little visual references they have."











NTSB Identification: CEN17FA103
14 CFR Part 91: General Aviation
Accident occurred Wednesday, February 15, 2017 in Shreveport, LA
Aircraft: BELL HELICOPTER TEXTRON CANADA 429, registration: N598PB
Injuries: 2 Fatal.

This is preliminary information, subject to change, and may contain errors. Any errors in this report will be corrected when the final report has been completed. NTSB investigators either traveled in support of this investigation or conducted a significant amount of investigative work without any travel, and used data obtained from various sources to prepare this aircraft accident report.

On February 15, 2017, about 0025 central standard time, a Bell 429 helicopter, N598PB, impacted terrain and water at Wallace Lake near Shreveport, Louisiana. The private rated pilot and passenger were both fatally injured, and the helicopter was substantially damaged. The helicopter was registered to and operated by a private individual under the provisions of 14 Code of Federal Regulations Part 91 as a personal flight. Instrument metrological conditions prevailed for the flight, which operated without a flight plan. The flight originated from a field in Bossier City, Louisiana, about 0015 and was en route to Center Municipal Airport (F17), Center, Texas.

The helicopter was the subject of an alert notice and was located the afternoon of February 15. The wreckage was located at the southern end of Wallace Lake. The first impact point consisted of tree strikes followed by an impact crater in a muddy area just prior to the lake. The debris field generally followed a 320° heading and was about 200 feet long in a muddy area of the lake. The main wreckage consisted of the engines, top of the fuselage and the main rotor blades. All major helicopter components were located at the accident site.

The helicopter was documented on-scene and recovered to a secure facility.

At 0049, an automated weather reporting facility at Shreveport Regional Airport, about 10 miles northwest of the accident site, recorded a wind from 320° at 9 knots, visibility 7 miles, a broken ceiling at 1,000 ft, an overcast ceiling at 1,400 ft, temperature 46° F, dew point 45° F, a barometric pressure of 29.93 inches, and a remark for a variable ceiling from 600 ft to 1,400 ft.
